CL180 Series
Electrified Cylindrical Complete Lock Low Energy, 11-30 VDC
- The Command Access CL180-LE series is a low energy, cost effective cylindrical lock that is ideal for any continuous duty application or condition requiring low surge and hold current. Its unique electronics allow the CL180LE to function much like a motor-driven lockset without the potental problems inherent in motors. The CL180LE will operate with an input voltage between 11-30 volts, eliminating the need to inventory 12 and 24V models. The CL180LE features a standard Built in Request to Exit (REX/AE) switch.
Features:
- Low maximum current draw 400 mA (12V): use more locks on a single power supply. Additional savings for the owner
- Low holding current 30 mA: reliable operation and meets sustainable consideration
- Fail Safe (EL) & Fail Secure (EU) available not field selectable
- Multiple lever styles available
- Available SFIC or LFIC (Schlage) Cylinger not included
- Available with Schlage C Type keyway standard
Options
- Available Fail Safe (Electrically locked) or Fail Secure (Electrically Unlocked)
- Voltage option - 12V or 24V (AC/DC)
- REX - Request to Exit or AE switch available (on all functions)
Specifications:
Voltage:
- Operating voltage - 11-30 VDC
- Surge Current - 400 mA @12V, 200 mA @24V
- Holding Current - 30 mA
- Specify Fail Safe (EL) or Fail Secure (EU)
Accessories:
- 2-3/8 Backset available
Model Applications Available
- CL180LE-EL - Outside lever locked (EL) electronically. Latchbolt retracted by key outside or lever inside. Switched power allows outside lever to retract latchbolt. Inside lever is always free for immediate egress.
- CL180LE-EU - Outside lever unlocked (EU) electronically. Latchbolt retracted by key out-side or lever
inside. Switched power allows outside lever to retract latchbolt. Inside lever is always free for immediate egress
Manufacturer Resources
Product Specs
- Category:
- Mechanical Locks
- Product Group:
- Mechanical Locks
- Series:
- CL180 Series
- Product Subgroup:
- Bored Locksets
- Product Type:
- Electrified Cylindrical Locks
- Subcategory:
- Cylindrical
- Commercial/Residential:
- Commercial
- Electronic:
- Yes
- Lock Type:
- Cylindrical
- Warranty:
- 3 Year Warranty
- Function:
- LE Storeroom
- Duty Level:
- Heavy-Duty
