Cooper Lighting 22CZ2-34HE-UNV-L835-CD1-U Cruze ST LED Troffer, 2'x2', 3500K, Ribbed Lens

The Cooper Lighting Metalux Cruze ST is a 2'x2' recessed LED troffer engineered for commercial ceiling grids that demand a clean, architectural look. Featuring a ribbed frosted acrylic lens, this fixture delivers 3400 lumens at 3500K with an 80 CRI minimum, drawing just 25.8W at 120-277V UNV input with 0-10V dimming to 5 percent. Measuring 24.0 IN Length x 24.0 IN Width x 3.5 IN Height, the recessed troffer is finished with a corner-to-corner matte white enamel paint applied after fabrication for a refined, uniform appearance suited to offices, schools, and healthcare corridors.

Key Features

  • Trade Size: 2'x2' recessed troffer measuring 24.0 IN Length x 24.0 IN Width x 3.5 IN Height for standard ceiling grid installation.
  • Light Output: 3400 lumens at 3500K color temperature with a minimum 80 CRI for accurate color rendering.
  • Lens Design: Ribbed frosted acrylic lens for uniform, glare-controlled light distribution.
  • Electrical Rating: 25.8W at 120-277V UNV input, .093A at 277V, with 0-10V dimming down to 5 percent for flexible lighting control.
  • High Performance Efficacy: Up to 157 lumens per watt for energy-efficient illumination.
  • Finish: Corner-to-corner matte white paint applied after fabrication for a refined finish.
  • Latch-less Design: Provides a clean architectural look without visible hardware.
  • Mounting: Recessed installation in standard 2'x2' ceiling grid systems.

Technical Specifications

  • Lamp Type: LED
  • Lumens: 3400
  • Color Temperature: 3500K
  • Wattage: 25.8W
  • Voltage Rating: 120-277V
  • Amperage Rating: .093 at 277V
  • Mounting: Recessed
  • Case Quantity: 1
  • Pallet Quantity: 56
  • Country of Origin: MX
  • ARRA Compliant: No

Typical Applications

  • Commercial Office Lighting
  • Educational Facilities and Classrooms
  • Healthcare Corridors and Common Areas
  • Retail and Institutional Ceiling Grid Retrofits
  • New Construction Recessed Lighting Layouts

Why Cooper Lighting?

Cooper Lighting's Metalux Cruze ST troffer combines high-efficacy LED performance up to 157 lumens per watt with a refined matte white enamel finish applied corner-to-corner for a consistently clean appearance across every fixture. The latch-less architectural design, ribbed frosted acrylic lens, and 0-10V dimming to 5 percent make it a dependable choice for professional electrical contractors specifying reliable, code-compliant commercial lighting.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
COO-20260923
Product Type:
Troffer & Flat Panel
Configuration:
2'x2' Recessed
Light Temperature:
3500K
Lumens:
3400
Product Wattage:
25.8W
Voltage Rating:
120-277V
Amperage Rating:
.093A at 277V
Product Finish:
Matte White
Department:
Electrical
Product Subgroup:
Light Fixtures
Product Group:
Lighting
Product Height:
3.5 in
Product Width:
24 in
Product Length:
24 in
Product Weight:
12.5 lb

Cooper Lighting 22CZ2-34HE-UNV-L835-CD1-U – Frequently Asked Questions

1) Will the Cooper Cruze ST 22CZ2 troffer drop into a standard 2x2 ceiling grid?
Yes. The Cruze ST 22CZ2-34HE is built as a 2'x2' recessed troffer measuring 24.0 in length x 24.0 in width x 3.5 in height, so it lays into a standard 2x2 lay-in grid opening. The 3.5 in depth is what to check above the ceiling, since you need that much clear plenum plus room for the whip and driver access.
2) Does this Cooper troffer run on 120V or 277V?
Both. The 22CZ2-34HE is a universal-voltage fixture rated 120-277V, so the same part works on 120, 208, 240 or 277 volt circuits. Draw is 25.8W, and .093A at 277V, which is what you use for circuit loading when you are ganging a row of them on one 20A branch.
3) Will 3500K match the fixtures already in my building?
Only if the existing fixtures are also 3500K. This Cruze ST is fixed at 3500K, a neutral white that reads warmer than 4000K and noticeably cooler than 3000K. If the rest of the floor is 4000K, a 3500K fixture will look yellow beside it, so for a partial relamp match the existing color temperature rather than mixing. CRI is 80 minimum.
4) What kind of dimmer do I need for the Cooper 22CZ2-34HE troffer?
It takes a 0-10V control, not a line-voltage wall dimmer. The driver dims to 5 percent, so you need a low-voltage 0-10V dimming control plus a separate pair of low-voltage control conductors run to the fixture. A standard forward-phase or ELV incandescent-style dimmer will not work with it.
5) Does the Cooper Cruze ST 22CZ2 qualify as a Buy American / ARRA product?
No. The 22CZ2-34HE-UNV-L835-CD1-U is listed as not ARRA compliant, with country of origin Mexico. If your project has a Buy American or ARRA domestic-content requirement, this fixture will not satisfy it and you need a domestically manufactured alternative.
6) Is the lens on this troffer going to cause glare in a computer office?
The Cruze ST uses a ribbed frosted acrylic lens, which diffuses the LED source rather than leaving visible dots, so it is aimed at glare-controlled uniform output for offices, classrooms and healthcare corridors. If your spec calls for a specific UGR or a parabolic louver for screen-heavy space, that is a different optic and this ribbed diffuser is not it.
7) How do I read the 22CZ2-34HE-UNV-L835-CD1-U part number when ordering?
The catalog number breaks down to the fixture and options: 22CZ2 is the 2x2 Cruze ST, 34HE is the 3400 lumen high-efficacy package, UNV is the 120-277V universal driver, L835 is 80 CRI at 3500K, and CD1 is the 0-10V dim-to-5-percent driver. Order it exactly as 22CZ2-34HE-UNV-L835-CD1-U, since changing any segment changes lumens, color, or control type.
8) Why does this troffer have no visible latches, and does that affect relamping access?
It is a latch-less design, chosen for a clean architectural ceiling line with no exposed hardware. The lens still comes down for access to the driver compartment; there is simply no visible latch hardware on the face. The matte white enamel is applied corner to corner after fabrication, so the trim edge stays uniform fixture to fixture in a long run.
9) How many of these troffers come in a case, and how many per pallet?
Each Cruze ST 22CZ2 ships as a single fixture per case, with 56 to a pallet. For a full-floor grid job that means counting your fixture schedule one for one, and a pallet quantity of 56 is the planning figure for freight and staging.
