Cooper Lighting 22GR-LD5-32-F1-UNV-L840-CD1-U GR Series 2x2 LED Recessed Troffer, 4000K, 3200 Lumen

Cooper Lighting 22GR-LD5-32-F1-UNV-L840-CD1-U GR Series 2x2 LED Recessed Troffer, 4000K, 3200 Lumen

(No reviews yet) Write a Review

Model: 22GR-LD5-32-F1-UNV-L840-CD1-U

In Stock (leaves warehouse same day if ordered before 3pm ET)

$225.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
"

Cooper Lighting 22GR-LD5-32-F1-UNV-L840-CD1-U GR Series 2x2 LED Recessed Troffer, 4000K, 3200 Lumen

The Cooper Lighting Metalux GRLED Series is a 2' x 2' LED recessed troffer engineered to deliver a strong balance between leading-edge LED performance and value-based lighting. This 3200 lumen, 4000K unit operates on a 120/277V voltage rating with a 28W wattage draw and an amperage rating of 0.119A at 277V, and it features a Class 2 constant driver with standard 0-10V dimming for flexible light-level control. Built on a shallow, low-profile housing, the GRLED is compatible with restrictive plenums and today's most common ceiling systems, making it a strong fit for commercial offices, schools, hospitals, retail merchandising and similar general purpose lighting applications.

Key Features

  • Light Output: 3200 lumens at 4000K color temperature for bright, consistent illumination.
  • Efficiency: Up to 140LPW for maximum energy savings versus fluorescent troffers.
  • Dimming Control: Class 2, constant driver with standard 0-10V dimming for adjustable light output.
  • Electrical Rating: 120/277V voltage rating, 28W wattage, 0.119A at 277V.
  • Color Rendering: CRI greater than 80 for accurate, natural color rendering.
  • Dimensions: 24.901 IN Length x 24.001 IN Width x 3.701 IN Height, sized for a 2' x 2' recessed ceiling opening.
  • Lumen Maintenance: L70 rated at 193,000 hours; TM21 rated L90 at 60,000 hours for long-term reliability.
  • Mounting: Recessed mounting for a clean, integrated ceiling appearance.

Certifications & Compliance

  • DLC and DLC Premium qualified

Technical Specifications

  • Pallet Quantity: 48
  • Country of Origin: MX
  • Case Quantity: 1
  • MarketPro US Flag: No
  • Lamp Type: LED
  • ARRA Compliant: No

Typical Applications

  • Commercial Office Lighting
  • Schools and Educational Facilities
  • Hospitals and Healthcare Facilities
  • Retail Merchandising Spaces
  • General Purpose Ceiling Lighting Retrofits

Why Cooper Lighting?

Cooper Lighting's Metalux GRLED Series pairs a low-profile, plenum-friendly housing with a Class 2 constant driver and standard 0-10V dimming to deliver dependable, code-compliant performance for professional lighting installations. With DLC and DLC Premium qualification, a CRI greater than 80, and lumen maintenance rated at L70 for 193,000 hours, the GRLED Series is built to provide consistent, energy-efficient illumination backed by a five-year warranty.

"

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
COO-20260923
Product Type:
LED Troffer
Lamp Type:
LED
Configuration:
2' x 2' Recessed
Voltage Rating:
120/277V
Amperage Rating:
0.119A
Product Wattage:
28W
Light Temperature:
4000K
Lumens:
3200
CRI:
>80
Dimmable:
0-10V
Listing:
DLC Premium
Department:
Electrical
Product Subgroup:
Recessed Lighting
Product Group:
Lighting
Product Length:
24.901 in
Product Weight:
11.71 lb
Product Height:
3.701 in
Product Width:
24.001 in

Cooper Lighting 22GR-LD5-32-F1-UNV-L840-CD1-U – Frequently Asked Questions

1) Will the Cooper Lighting GR Series 2x2 LED troffer drop into a standard grid ceiling with a shallow plenum?
Yes. The Metalux GRLED 2x2 troffer is sized for a 2' x 2' recessed ceiling opening, measuring 24.901 x 24.001 x 3.701 inches, and the housing is a shallow low-profile design the manufacturer calls compatible with restrictive plenums and today's most common ceiling systems. The 3.701 inch height is the number to check against your plenum depth above the grid.
2) Can I run this troffer on 120V or do I need 277V?
Either. The driver is universal voltage, rated 120/277V, so the same fixture works on a 120V branch circuit or a 277V commercial lighting circuit without ordering a different part. Draw is 28W, with an amperage rating of 0.119A at 277V, which is what you use for circuit loading on a multi-fixture run.
3) What dimming control does this Metalux GRLED troffer need?
It takes a 0-10V analog dimming signal, standard on the Class 2 constant driver. That means a low-voltage 0-10V control wire pair pulled to the fixture plus a compatible 0-10V dimmer or room controller. It is not a line-voltage phase dimming fixture, so a residential-style TRIAC wall dimmer will not control it.
4) Does this troffer qualify for utility rebates?
The GRLED 2x2 is DLC qualified and DLC Premium listed, which is the tier most utility rebate programs require for commercial interior LED. Keep the model number 22GR-LD5-32-F1-UNV-L840-CD1-U on the rebate paperwork, since programs verify the exact DLC-listed model.
5) Is 3200 lumens at 28W enough to replace a 2x2 fluorescent troffer in an office?
For general office and classroom ambient lighting, yes. The GRLED 2x2 puts out 3200 lumens at 28W, which is in the range of a two or three lamp 2x2 fluorescent troffer at roughly a third of the load. Cooper rates the series up to 140 lumens per watt. For high-bay or task-critical spaces you would step up to a higher lumen package rather than this one.
6) Will 4000K match the fixtures already in my building?
This one is 4000K neutral white, the most common commercial spec and what most offices, schools and healthcare corridors are lit at. If your existing troffers are 3500K or 5000K the difference will be visible side by side in the same room, so match the existing color temperature or relamp a whole space at once. CRI is greater than 80.
7) Is this troffer ARRA compliant for a federally funded project?
No. The GRLED 2x2 is listed as not ARRA compliant, and it is made in Mexico. If your project carries a Buy American or ARRA domestic sourcing requirement, this fixture will not satisfy it and you need a domestically manufactured troffer instead.
8) How many of these 2x2 troffers come in a carton?
Each carton holds one fixture, and a full pallet is 48. Country of origin is Mexico. For a floor full of grid ceilings, order by the piece and count on 48 to a pallet when you are planning staging and freight on site.
