Eaton Commercial Specification Grade Duplex Receptacle 20A 125V Side Wire Light Almond

Cooper Wiring Devices CR20LA Commercial Specification Grade Duplex Receptacle, 20A 125V Light Almond

(No reviews yet) Write a Review

Model: CR20LA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3.00
$2.45
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Cooper Wiring Devices CR20LA Commercial Specification Grade Duplex Receptacle, 20A 125V Light Almond

The Cooper Wiring Devices CR20LA Commercial Specification Grade Duplex Receptacle delivers reliable 20A 125V power distribution with a side wire configuration in an attractive Light Almond finish. Built to specification grade standards, this receptacle is engineered for commercial environments where durability and consistent performance are essential, and it carries cULus Listing for code-compliant electrical work. The compact, professional design makes it well suited for offices, retail spaces, and other commercial installations requiring dependable connections.

Key Features

  • 20A 125V Rating: Provides robust power capacity for commercial equipment and high-demand applications.
  • Side Wire Configuration: Enables efficient installation with convenient wiring access and secure connections.
  • Specification Grade Construction: Built to commercial standards for enhanced durability and long-term reliability.
  • Light Almond Finish: Professional appearance that complements modern commercial interiors.
  • Compact Profile: Space-efficient design at 4" x 1.24" x 0.79" for versatile mounting applications.
  • cULus Listed: Meets rigorous safety standards for commercial electrical installations.
  • RoHS Compliant: Environmentally responsible construction meeting international standards.

Certifications & Compliance

  • cULus Listed
  • RoHS Compliant

Technical Specifications

  • Product Type: Receptacles
  • Certifications: cULus Listed
  • Compliances: RoHS Compliant
  • Product Height: 4 in
  • Product Length Depth: 1.24 in
  • Product Weight: .15 lb
  • Product Width: .79 in

Typical Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Professional Services Facilities
  • Educational Institutions
  • Healthcare Facilities
  • Light Industrial Applications
  • Multi-Unit Commercial Properties

Why Cooper Wiring Devices?

Cooper Wiring Devices delivers proven reliability through specification grade construction and comprehensive safety certifications, including cULus Listing. The RoHS compliant design demonstrates environmental responsibility, while the robust 20A 125V rating ensures dependable performance in demanding commercial applications. Trust Cooper Wiring Devices' commitment to quality electrical solutions for offices, retail spaces, and other professional installations.

Manufacturer Resources

Product Specs

Certifications:
cULus Listed
Compliances:
RoHS Compliant
Product Height:
4 in
Product Length Depth:
1.24 in
Product Weight:
.15 lb
Product Width:
.79 in
Product Type:
Duplex Receptacle
Product Group:
Wiring Devices
Department:
Electrical
Product Subgroup:
Receptacles & Outlets
Number Of Poles:
Two-pole
Nema Configuration:
5-20R
Amperage Rating:
20A
Allowable Wire Size:
#14-10 AWG
Special Features:
Auto-grounding, screw-catch
Wiring Method:
Side
Product Material:
PVC
Number Of Wires:
Three-wire
Connection Type:
Screw
Contact Material:
Brass
Voltage Rating:
125V
Product Color:
Light Almond
Design Type:
Straight blade
Device Type:
Receptacle
Style Type:
Standard
Product Length:
1.24 in
Application:
Commercial
Receptacle Type:
Duplex

Cooper Wiring Devices CR20LA – Frequently Asked Questions

1) Will a light almond receptacle match the ivory or white devices already in my building?
No, it will not. Light almond is a distinct warmer off-white tone and sits apart from both white and ivory when you look at two devices side by side on the same wall. The CR20LA is light almond only, so if your other openings are white or ivory, order the matching color in that series instead and keep light almond for rooms where the existing devices and plates are already light almond. Property managers standardizing a fleet should pick one color and stay with it.
2) Is the Cooper CR20LA tamper resistant or GFCI?
Neither. The CR20LA is a straight 20A 125V duplex receptacle, so it has no shutters and no ground fault protection built in. If your area requires tamper resistant receptacles, such as patient care areas or child occupied spaces, specify a TR device. For GFCI locations, kitchens, bathrooms, rooftops, outdoors, use a GFCI receptacle or protect the circuit upstream with a GFCI breaker and feed this device downstream.
3) Is the CR20LA a side wire receptacle or does it have back wire clamps?
Side wire. The CR20LA uses binding head screws on the sides of the device, so you form a loop on the conductor and tighten under the screw. If your installer standard calls for back-wired clamp terminals or push-in terminals, this is not that device. Side wire is the common spec grade arrangement and gives you straightforward access when you are feeding through a box with several devices.
4) Does the CR20LA accept a standard duplex wall plate, or do I need a decorator plate?
It takes a standard duplex wall plate, the one with two round openings. The CR20LA is a conventional duplex receptacle, not a decorator or rocker style device, so a screwless or screw-mount decorator plate with a single rectangular opening will not fit it. Order the plate in light almond if you want the finish to carry through.
5) How is specification grade different from a residential grade outlet, and is it worth it for an apartment turn?
Spec grade devices like the CR20LA are built for repeated plug cycles and tighter blade retention than a residential grade device, which is why they go in corridors, offices, retail and common areas where the outlet gets used daily. For a low traffic bedroom wall in a rental, a residential grade device will do. For anything a tenant, vendor or cleaning crew plugs into constantly, spec grade is the one that keeps a plug from falling out in a year.
6) What is the exact part number to reorder this light almond 20 amp outlet?
Order Cooper Wiring Devices CR20LA. That single catalog number covers the 20A 125V side wire duplex in light almond, and it is the number to put on a standardization list so every reorder lands the same device and the same color.
7) Does the CR20LA meet RoHS for a project with sustainability requirements?
Yes, the CR20LA is RoHS compliant, which covers restricted substances in the device construction. That is the item a sustainable distributor or a specifier working to a materials standard usually needs documented. It is also cULus Listed for the safety side.
