Corbin Russwin 563F98- Lock Lever, ED8000 Pushpad Exit Device, CL3300 Cylindrical Lock Series, AZD

Corbin Russwin 563F98- Grade 1 Lock Lever, ED8000 Pushpad Exit Device, CL3300 Cylindrical Lock Series, AZD

(No reviews yet) Write a Review

Model: 563F885 626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$180.18
$145.02
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Corbin Russwin 563F98 Lock Lever for ED8000 Pushpad Exit Device and CL3300 Cylindrical Lock Series, AZD Plain Finish

Commercial-Grade Replacement Lock Lever for Pushpad Exit Device Applications

The Corbin Russwin 563F98 is a professional-grade Lock Lever designed for use with the ED8000 Pushpad Exit Device and the CL3300 Cylindrical Lock Series. Featuring an A6 Design in an AZD Plain finish, this lever is engineered to accommodate standard door thickness ranges of 1-3/8" to 2-1/4", with lever operation specifically suited for doors ranging from 1-3/4" to 2" in thickness. Intended for commercial applications, this replacement lever integrates seamlessly with Cylinder/Button configurations on compatible exit device and cylindrical lock hardware.

Professional Features & Benefits

  • Grade 1 cylindrical lockset per ANSI/BHMA A156.2 Series 4000, Grade 1
  • Lever Release™ design for vandal resistance — outside lever rotates freely when locked
  • EZ-Install components significantly reduce installation time
  • Independent return springs prevent lever sag
  • 4 solid cast lever options (Armstrong, Newport, Princeton, Frascati)
  • Anti-rotational through-bolts at 6 and 12 o'clock positions
  • Accommodates 6 or 7-pin conventional cylinders and all keying levels
  • CL3352 Classroom Intruder function: double-cylinder lockset, always-free egress
  • Available with MicroShield® antimicrobial coating (suffix option code "C")
  • CL33900 electrified option: fail safe and fail secure, 12 or 24VAC/VDC
  • ElectroLynx® 8-pin connector on all electrified products
  • Seven-year limited warranty (two-year for electrified)

Technical Specifications

  • Grade: ANSI/BHMA A156.2 Series 4000, Grade 1
  • Handing: Non-handed (except FZD trim)
  • Door Thickness: 1-3/4" (44mm) 2" (51mm) standard; optional over 2" 2-1/4" (57mm)
  • Backset: 2-3/4" (70mm) standard; optional 3-3/4" (95mm) and 5" (127mm)
  • Latchbolt: Stainless steel, 1/2" (13mm) throw; optional 3/4" (19mm) fire latch
  • Auxiliary Latchbolt: Deadlocking — prevents manipulation when door is closed
  • Lock Chassis: Steel, zinc dichromated for corrosion resistance
  • Front: Wrought brass, bronze, or stainless steel, 2-1/4" x 1-1/8"
  • Strike: Wrought brass or stainless steel ANSI curved lip, 4-7/8" x 1-1/4" x 1-1/4" lip to center
  • Cylinder: Brass, 6-pin L4 keyway, 0-bitted standard
  • Electrified Voltage: 12VAC/DC or 24VAC/DC (CL33900 Series)
  • Electrified Current: 250mA @ 12VAC/VDC; 150mA @ 24VAC/VDC, continuous duty solenoid
  • Certifications: ANSI/BHMA A156.2 Grade 1; UL-cUL listed; ANSI A117.1 Accessibility; California State Fire Marshal
  • Warranty: Seven-year limited (two-year for CL33900 electrified)

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin lock lever components are engineered to commercial-grade standards, delivering reliable performance in demanding door hardware applications. The 563F98 lever is purpose-built for compatibility with the ED8000 Pushpad Exit Device and CL3300 Cylindrical Lock Series, ensuring consistent mechanical integration across supported door thickness ranges of 1-3/8" to 2-1/4". Designed for commercial environments where dependable hardware performance and straightforward maintenance are essential priorities.

Manufacturer Resources

Corbin Russwin Condensed Catalog

Product Specs

Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Lever
Commercial/Residential:
Commercial
Subcategory:
Parts and Accessories
Product Attribute:
Parts and Accessories
Product Model:
563F8
Product Category:
Mechanical Locks
Department:
Door Hardware
For Use With:
CL3300 Cylindrical Lock; ED8000 Pushpad Exit Devices; Cylinder/Button
Door Thickness Range:
1-3/4" to 2"

Corbin Russwin 563F885 626 – Frequently Asked Questions

1) Will the Corbin Russwin 563F98 lever work on a 1-3/4 inch door?
Yes. The 563F98 lever is specified for doors 1-3/4 inch to 2 inch thick, which covers standard commercial door thickness. The CL3300 chassis family itself will go up to 2-1/4 inch (57mm) with the optional over-2-inch kit, but the lever trim itself is rated for the 1-3/4 to 2 inch range.
2) Is the Corbin Russwin 563F98 lever ADA compliant and Grade 1?
The CL3300 cylindrical lockset the lever serves is ANSI/BHMA A156.2 Series 4000, Grade 1, UL-cUL listed, meets ANSI A117.1 accessibility, and is listed by the California State Fire Marshal. The lever design is what satisfies the A117.1 operable-hardware requirement, so it suits schools, healthcare and government work where accessibility is specified.
3) Do I need to order the 563F98 lever handed for a left or right hand door?
No handing to specify. The CL3300 trim is non-handed, with the single exception of FZD trim. The 563F98 is an A6 design lever, so one part covers either swing.
4) What is the difference between the plain and the cylinder/button versions of the 563F98 lever?
Two versions are made in A6 design: plain, and cylinder or button. The plain lever has no prep in it, so it is the free-turning or non-keyed side. The cylinder-or-button lever is bored to take a key cylinder or a pushbutton for locking functions. Match it to what the function on your ED8000 or CL3300 calls for, because the two are not interchangeable once the door is prepped.
5) Will this lever resist being wrenched or kicked when the door is locked?
The CL3300 uses a Lever Release design: when the lockset is secured the outside lever rotates freely instead of transmitting force into the chassis. That is the vandal-resistance feature, and it is why this trim holds up in schools, dorms and multi-tenant corridors. Independent return springs also keep the lever from sagging over time.
6) What cylinder does the cylinder/button 563F98 lever take?
The CL3300 series accepts 6 or 7-pin conventional cylinders and all keying levels, with a brass 6-pin L4 keyway cylinder 0-bitted as standard. If you are keying into an existing Corbin Russwin system, the lever prep will take your cylinder as long as it is a conventional 6 or 7-pin.
7) Will the CL3300 lockset this lever fits latch into my existing ANSI strike and standard 2-3/4 backset prep?
Standard backset is 2-3/4 inch (70mm), with 3-3/4 inch (95mm) and 5 inch (127mm) optional, so it drops into the usual commercial cross-bore layout. The latchbolt is stainless steel with a 1/2 inch (13mm) throw, and a 3/4 inch (19mm) fire latch is optional. The strike is an ANSI curved lip, 4-7/8 x 1-1/4 inch with 1-1/4 inch lip to center, and the front measures 2-1/4 x 1-1/8 inch, so it matches standard ANSI door and frame prep.
8) If I need an electrified access control lock instead of a mechanical one, what do I order in this series?
Step up to the CL33900 electrified option rather than the standard mechanical CL3300. It comes fail safe or fail secure at 12 or 24VAC/VDC, drawing 250mA at 12V and 150mA at 24V on a continuous duty solenoid, and all electrified products use the ElectroLynx 8-pin connector for a plug-in door harness. Mechanical trim like this lever does not convert to electrified after the fact.
9) Is the A6 lever the only lever style in this Corbin Russwin series?
No. The CL3300 series offers four solid cast lever designs: Armstrong, Newport, Princeton and Frascati. The 563F98 is the A6 design. If the rest of your openings carry a different lever profile, order the matching design rather than mixing shapes down a corridor.
10) Does this series offer a classroom intruder function for a school lockdown spec?
Yes, the CL3352 Classroom Intruder function is a double-cylinder lockset that can be locked from inside the room while keeping egress always free. Specify that function on the lockset; this lever is the trim that goes with a cylinder or button prep.
11) Can I get this lever with an antimicrobial coating for a hospital?
MicroShield antimicrobial coating is available on the CL3300 series under suffix option code C. For patient rooms, clinics and food service areas that is the option to call out on the order.
12) How is this lever fastened to the door, and will it loosen up?
The CL3300 uses anti-rotational through-bolts at the 6 and 12 o'clock positions, which is what keeps the trim from working loose under traffic. EZ-Install components cut the install time, so swapping a damaged lever on an ED8000 or CL3300 is a short job for a maintenance tech.
