CU TP 1HL LUG SHRTBRL 4/0 1/2B PUR
Manufacturer Resources
Product Specs
- Cable Size:
- 4/0 AWG
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Standard Barrel
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- 1/2 in
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Purple
- Product Material:
- Copper
Blackburn CTL40-12 – Frequently Asked Questions
1) What wire size does the Blackburn CTL40-12 compression lug take?
The CTL40-12 is sized for 4/0 AWG copper conductor. It is a copper compression lug, so it terminates copper cable only, not aluminum. The purple color code on the barrel is the die/size identifier crimpers use to confirm they are on the right conductor size before compressing.
2) Will the Blackburn CTL40-12 lug bolt to a 1/2 inch stud on my panel bus?
Yes. The CTL40-12 has a single bolt hole sized for a 1/2 inch stud, and it is a one-hole tongue, so it lands on a single 1/2 inch stud or bolt on a bus bar, breaker pad or ground bar.
3) Can I use the Blackburn CTL40-12 on aluminum cable?
No. This is a copper-bodied lug rated for copper conductor only. Putting aluminum cable in a copper-only barrel is not an approved termination. For aluminum feeders you need a lug marked AL9CU or aluminum-rated.
4) Is the CTL40-12 a mechanical set screw lug or a crimp lug?
It is a compression (crimp) lug with a short barrel, not a set screw mechanical connector. You install it with a hydraulic or battery crimp tool and the die matched to the purple 4/0 copper code. If you need a lug you can install with a hex key and no tooling, a mechanical set screw lug is the type to look for instead.
5) Does the CTL40-12 come as a single lug or in a bag of multiples?
It sells individually, one lug per unit. For a three-phase feeder plus neutral you would order four, and add one more for the ground if it is also 4/0.
6) Where is the Blackburn CTL40-12 made?
The CTL40-12 is manufactured in Mexico. Buyers working to domestic-content or country-of-origin requirements on a public project will want that on record before submittal.
