OATEY A9123A Dearborn® 1-1/2" x 16" Center to Center, Hi-Line/Slip Joint Combination w/ Baffle Tee

The A9123A kit comes with 2 waste arms, 2 Hi-Line nipples, 4 slip nuts and 4 washers, plus the baffle tee. That covers the horizontal run between the two bowls on 16 inch centers. You still supply the tailpieces/strainers at each bowl and the P-trap and trap arm downstream, since those are not part of the kit.

Measure between the centers of the two sink drain openings. The A9123A is built for 16 inch center-to-center spacing; the Dearborn combination waste is also offered in a 21 inch length for wider bowl spacing. Slip joints give you a little adjustment, but going from 16 to 21 inches is a different part, not a slide adjustment.

Yes. It is a 1-1/2 inch slip joint combination waste, which is the standard kitchen sink drain size. The slip nuts and washers seal over 1-1/2 inch OD tubular drain pipe, so it mates with standard 1-1/2 inch tailpieces and traps without adapters.

The baffle inside the tee restricts crossflow, so water draining from one bowl is directed down the trap instead of surging up into the second bowl. If you have a double-bowl sink, especially one where a disposer or a heavy dump of water goes down one side, the baffle tee is the version you want. A plain (non-baffled) tee lets water backflow into the other basin.

Polypropylene plastic, in black. The Dearborn combination waste line is offered in white or black polypropylene; the A9123A as supplied is the black finish. Polypropylene resists the hot water and household drain cleaners typical in a kitchen sink waste, and it cuts cleanly with a tubing cutter or fine-tooth saw if you need to shorten an arm.

The A9123A ships with 4 standard washers and 4 slip nuts. Dearborn also offers these combination wastes with True Blue Premium Washers as an option if you want the upgraded sealing version, so specify that option at order time rather than trying to retrofit later.

Order Oatey Dearborn A9123A, the 1-1/2 inch by 16 inch center-to-center Hi-Line slip joint combination waste with baffle tee.

About 0.642 lb, with a listed volume of 0.126. It's a light plastic tubular assembly, so property maintenance crews and plumbers commonly carry several on the van.
