OATEY 800-17-1 Dearborn® 1-1/2" x 6" Flanged Strainer Tailpiece -17 Ga.

The flange is the flared top end that seats up inside the sink strainer body and is held by the strainer's coupling nut. That is the Hi-Line (flanged) connection style. If your strainer takes a flanged tailpiece, this is the right part. If the strainer instead threads directly to a straight, threaded tailpiece, a flanged piece will not seal there.

Brass tube with a chrome-plated finish, which is why it is specified where the trap assembly is exposed under an open-front cabinet or a wall-hung sink. Wall thickness is 17 gauge, the lighter of the two common tubular brass gauges, so it is intended for residential and light commercial waste work rather than heavy-duty 17-gauge-plus institutional runs.

Yes, that is normal practice with tubular brass. The 6 inch length is cut from the plain bottom end to suit the distance between the strainer and the trap inlet; the flanged end stays intact because it seats in the strainer. Cut square and deburr so the slip nut washer seals.

100 degrees Fahrenheit maximum working temperature. That is a drain-side rating, fine for normal sink discharge, but it rules the part out anywhere a dishwasher or commercial warewasher dumps near-boiling water into the tailpiece. For that duty spec a tailpiece rated for higher temperature.

Order it as the tailpiece itself, model 800-17-1 from Oatey's Dearborn line. Plan on having the strainer coupling nut and gasket at the strainer end and a slip nut and washer at the trap end, sized 1-1/2 inch to match.

About 0.36 lb each, with a volume of 0.013, so a box of them for a multi-family unit turn stays light. Useful if you are kitting trap assemblies per apartment.
