Delaney Brookhaven Entry Knobset

Both. The Brookhaven knob ships with an adjustable latch that fits 2-3/8 inch and 2-3/4 inch backsets, so you don't have to know which prep is in the door before you order. The cross bore is the standard 2-1/8 inch and the edge bore is 1 inch, which is the same prep most residential knobs and levers already use.

Either. The Brookhaven entrance knob comes standard with a 5 pin KW1 (Kwikset) cylinder, and an SC1 5-pin (Schlage) keyway is selectable when you order. If you're adding doors to a building already on one keyway, pick the matching one and you can key the new knobs into the existing system.

Yes. Keying is a required selection on the Brookhaven entrance knob, and keyed alike is one of the options alongside keyed different. Keyed alike gets every exterior door in a unit on a single key, which is what most property managers want on a turnover. Choose the keyway (KW1 or SC1) to match whatever the rest of the building already runs.

Four: entrance (keyed, single cylinder), privacy for bed and bath, passage for halls and closets, and dummy for a fixed pull on a closet or inactive leaf. All four are offered in both finishes and both trim shapes, so you can do a whole house or a whole unit in one look and only pay for the key cylinder on the doors that need it.

The Brookhaven has a 1/2 inch latch throw with a 1 inch x 2.25 inch round corner faceplate, and it includes a 1-3/4 inch x 2-1/4 inch full lip round corner strike. If your jamb already has a round corner strike cut to that size, the new strike drops straight in. Square corner preps will need the corners squared off or the mortise touched up.

The Delaney Brookhaven knobset is classified as residential door hardware. For a commercial opening, the comparable set offers graded cylindrical knob locks: the BEST 8K Series is a Grade 1 heavy duty entrance function single cylinder knob lock, the Corbin Russwin CK4851 is an entrance/office cylindrical lock with a Global knob and conventional cylinder for doors 1-3/8 inch to 2 inch, and the Dexter C2000 entry/office knob is Grade 2 for doors 1-3/8 inch to 1-3/4 inch. For storeroom function, the Sargent 8XG04 is a Grade 1 heavy duty single cylinder knob lock with 2-3/4 inch backset.

The Delaney Brookhaven entry knobset ships with a 5-pin KW1 cylinder as standard and is also offered with an SC1 5-pin keyway, so it keys into either a Kwikset or Schlage residential system. Two peers cover the same keyed entry ground: the Cal-Royal BER00 is a Grade 3 entrance/office knob lock built around a Kwikset keyway for doors 1-3/8 inch to 1-3/4 inch thick, and the Kwikset 400P Polo is a keyed entry knob supplied with a 6AL latch and RCS strike. The Brookhaven's 1-3/8 inch to 1-3/4 inch door thickness range matches the BER00's.

The Delaney Brookhaven entry knobset covers standard doors from 1-3/8 inch to 1-3/4 inch thick. For a 2 inch door, look at the Deltana knobs, which cover 1-3/8 inch to 2 inch - the 3381 Egg Knob and 6171 Round Knob in entry function, and the 6112 St. Thomas in privacy. On the commercial side, the Corbin Russwin CK4851 entrance/office and CK4310 passage locks also cover 1-3/8 inch to 2 inch, and the Falcon X101 Grade 1 passage knobset goes to 2-1/4 inch.

The Delaney Brookhaven is built in entrance, privacy, passage and dummy functions. For classroom or storeroom keying, look at other lines: the Dexter C2000 classroom ball knob is Grade 2, keyed and non-clutching, for doors 1-3/8 inch to 1-3/4 inch; the Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with a single cylinder; and the Sargent 8XG04 is the Grade 1 heavy duty storeroom equivalent with a 2-3/4 inch backset.

For a fire rated opening the comparable set points to the Falcon W Series and X Series. The Falcon W101 is a Grade 2 medium duty passage/closet knob lock with a 2-3/4 inch backset carrying a fire rating, and the Falcon X101 is a Grade 1 heavy duty cylindrical passage knobset with an interchangeable core, also fire rated, for doors 1-3/8 inch to 2-1/4 inch. Those are the two in the set that state a fire rating.

Yes. Combination screws are included that work for wood or metal door mounting, so the same knobset covers a hollow metal unit door and a wood interior door as long as the hole prep is 2-1/8 inch cross bore, 1 inch edge bore, and the door is 1-3/8 to 1-3/4 inches thick.

Trim comes in round or square rose, and both are offered in US32D stainless steel and US19 black. Square trim tends to go on newer flat-panel and transitional doors, round on traditional. The choice is cosmetic only, the bore prep is identical either way at 2-1/8 inch cross bore.

Both are residential keyed entry knobs on a KW1 Kwikset keyway. The Kwikset 400P-CP is listed Grade 3 for 1-3/8 to 1-3/4 inch doors with a round corner adjustable latch and round corner strike, which is the same fit envelope as the Brookhaven. The practical difference is options: the Brookhaven lets you specify SC1 instead of KW1 and order keyed alike, and it's offered in matching privacy, passage and dummy so the whole opening set matches.

Single cylinder. Key on the outside, thumbturn or button on the inside, so nobody is locked in without a key. That's the function required by most residential codes on a unit entry door, and it's the only keyed configuration the Brookhaven is built in.

The Delaney Brookhaven is built in privacy function as well as entrance, in US32D Stainless Steel and US19 Black with round or square trim, so you can match the same knob across a unit. If you need a different brand in privacy, the Cal-Royal BER20 is a Grade 3 privacy knob lock with brass trim for doors 1-3/8 inch to 1-3/4 inch, the Pamex FTF Baron is a Grade 3 privacy knob lockset over the same door thickness range, and the Dexter C2000 privacy ball knob is Grade 2 non-clutching over 1-3/8 inch to 1-3/4 inch.

Both are dummy trim, meaning no latch and no turning action - they mount to the face of the door as a pull. The Delaney Brookhaven dummy comes in US32D Stainless Steel and US19 Black with round or square trim. The Schlage A170 is a Grade 2 heavy duty cylindrical non-keyed dummy trim rated for doors 1-3/8 inch to 1-7/8 inch, and the BEST 6K Series single dummy trim is Grade 2 medium duty. The Cal-Royal BA40 is a dummy knob in the Barrington BA series for 1-3/8 inch to 1-3/4 inch doors. All are dummies - the differences are the grade and duty classification each carries.

The Delaney Brookhaven is available in passage function in both finishes and both trim shapes. Alternatives in the same non-keyed passage role include the Pamex FTF Baron passage knob lockset, Grade 3 for doors 1-3/8 inch to 1-3/4 inch; the Arrow MK01 and RK01 passage cylindrical knob locks, both Grade 2 over the same door range, with the RK01 using a ball knob; the Falcon W101, a Grade 2 medium duty passage/closet knob lock with a 2-3/4 inch backset and a fire rating; and the Schlage D10S, a Grade 1 heavy duty passage latch with an Orbit knob.

The Delaney Brookhaven is a cylindrical bored knobset with an adjustable backset fitting 2-3/8 inch and 2-3/4 inch, a 2-1/8 inch cross bore and a 1/2 inch throw latch, offered in US32D Stainless Steel and US19 Black. The decorative lines take a different approach: the Emtek Porcelain knobs are supplied as two knobs per set with a threaded rod, and the Emtek Classic Brass Crystal Georgetown and Providence knobs are sold as dummy pairs. Baldwin's Estate 5000 Baltimore passage knob is preconfigured with a 2-3/8 inch backset and full lip strike, and the Estate 5011 Colonial is a passage knob with a 5058 rose.

The Delaney Brookhaven fits both 2-3/8 inch and 2-3/4 inch backsets out of the box, which is what lets one part number cover mixed openings. Comparable adjustable options include the Sure-Loc Bergen round knob, sold as a 6-pack with adjustable backset, the Schlage Residential F500 Plymouth with Georgian knob combo pack with adjustable backsets and dual strikes, and the Kwikset 200P-CP Polo passage knob with a round corner adjustable latch and round corner strike. The Brookhaven's strike is a 1-3/4 inch by 2-1/4 inch full lip round corner.

The Delaney Brookhaven entry knobset is a single cylinder cylindrical knob lock with a 5-pin KW1 cylinder. In the same entry-knob role, Callan offers the Canova and Santo in Grade 3 and the Edgewood and Roland in Grade 2, all entrance function; Bravura's Dallas, Albany and Lynchburg are Grade 2 knobsets with rectangle or round trim; Master Lock's BC Series biscuit knob is a Grade 3 keyed entry; and the Pamex FTF Baron is Grade 3 entrance/office for 1-3/8 inch to 1-3/4 inch doors. The Brookhaven's distinguishing points are its square or round trim choice and the choice of KW1 or SC1 keyway.

No - those are different parts. The Delaney Brookhaven is a complete bored cylindrical knobset with its own latch, 1 inch edge bore and 2-1/8 inch cross bore prep. The Sargent 28C-KNOB is exit device trim with a knob and rose in entrance function for 1-3/4 inch doors, the Sargent 78-2875 is an outside knob only in B design, and the Imperial USA ED-BKL580 is knob trim in storeroom function from the ED-500 series. Those mount to an exit device and do not latch on their own, so they are not a substitute for a bored lockset on a standard door.

The Delaney Brookhaven entry knob is key operated, with a choice of KW1 or SC1 5-pin cylinder and keyed alike or keyed different ordering. If you would rather avoid keys entirely, the Lockey 3830 is a mechanical keyless combination knob lock with auto-locking passage function for doors 1 3/16 inch to 2 inch thick, so it covers a wider door range and needs no cylinder keying at all.

Yes, the Brookhaven is made in a dummy function in both US32D stainless steel and US19 black, and in both round and square trim, so it matches the keyed doors exactly. If you're after a decorative dummy instead of a match, Emtek offers dummy pairs in Georgetown and Providence crystal, and the Omnia 434/0 is a solid brass egg-shaped single dummy.
