Delaney Olivia - Grade 3 Passage Knobset

Delaney Olivia - Grade 3 Passage Knobset

(No reviews yet) Write a Review

Model: D14422
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$26.50
$21.05
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Delaney Olivia Non-Keyed Passage Door Knobset

passage-functionPassage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn't needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.

Features:

  • Functional and traditional appearance
  • Works well with both classic and functional decor
  • Installs on doors with 1-3/8" to 1-3/4" thick
  • Coordinates well with products from the Olympus Series
  • Combination screws for wood or metal door mounting



Specifications:

  • Backset: Fits 2-3/8" and 2-3/4"
  • Cross Bore: 2-1/8"
  • Edge Bore: 1"
  • Faceplate: 1" x 2.25" Round Corner
  • Door Thickness: Standard from 1-3/8" to 1-3/4"
  • Function: Passage
  • Latch: 1/2" throw
  • Strike: 1-3/4" x 2-1/4" full lip round corner



Technical Specification Download

Manufacturer Resources

Product Specs

Subcategory:
Bored Locksets
Series:
Olivia
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Commercial/Residential:
Residential
Lock Function:
Passage
Product Type:
Knobsets
Grade:
Grade 3
Product Attribute:
Cylindrical Locks
Product Function:
Passage/Hall/Closet
Product Category:
Mechanical Locks
Department:
Door Hardware

Delaney Hardware D14422 – Frequently Asked Questions

1) Does the Olivia knob lock, or is it always free?
No lock at all. The Olivia is a passage function knobset, so both knobs turn freely at all times with no button, no key, and no thumbturn. That is what you want on a hallway, a closet, or a laundry door. If you need the door to secure, pair it with a separate deadbolt, or step over to a privacy or entry function instead.
2) Will the Olivia latch work with the strike plate already in my door frame?
The Olivia ships with a 1-3/4 x 2-1/4 inch full lip round corner strike and a 1/2 inch latch throw. If your existing frame has a square corner mortise, the round corner strike won't seat without rework, so plan to use the included strike in a fresh prep or match your frame cutout before you swap. The latch faceplate is 1 x 2.25 inches, round corner.
3) Is this knobset rated for a commercial building or apartment corridor?
The Olivia is a Grade 3 residential knobset. That is fine for interior doors in a home, and it is a reasonable spec for low-traffic in-unit doors in multi-family. For a commercial corridor or a school, go heavier: the Corbin Russwin CK4310 is a Grade 1 passage cylindrical lock, and the Schlage D10S passage latch is Grade 1 heavy duty. In the middle, the Dexter C2000 passage knob and the Arrow MK01 are Grade 2.
4) My door is 2 inches thick. Can I still use the Olivia?
No. The Olivia tops out at 1-3/4 inches. For a 2 inch door, look at the Corbin Russwin CK4310 passage lock, which covers 1-3/8 to 2 inches, or the Falcon X101 passage knobset at 1-3/8 to 2-1/4 inches.
5) What is the closest Grade 3 passage knob equivalent to the Delaney Olivia passage knobset from another brand?
The Pamex FTF Baron knob lockset in passage function is the nearest match: it is a Grade 3 knob lockset with passage function and fits doors 1-3/8 inch to 1-3/4 inch thick, the same door thickness range the Olivia passage knobset covers. Both are non-keyed knob sets for hall and closet openings, so the substitution is a straight one on function and grade; the difference is the knob style and finish range.
6) I need a passage knob for a commercial corridor with heavy traffic - what should I use instead of a residential Grade 3 knob?
The Delaney Olivia passage knobset is designated for residential use at Grade 3. For heavy commercial traffic, step up to the Schlage D10S passage latch, a Grade 1 heavy duty cylindrical non-keyed knob lock with an Orbit knob, or the Falcon X101, a Grade 1 heavy duty cylindrical passage knobset with interchangeable core, fire rated, covering doors 1-3/8 inch to 2-1/4 inch. Corbin Russwin CK4310 is another Grade 1 passage/closet option with a Global knob for 1-3/8 inch to 2 inch doors.
7) Is a dummy knob the same as the Olivia passage knobset?
No. The Olivia passage knobset is a cylindrical lockset with a working latch, a 1/2 inch throw latch and a 1-3/4 inch by 2-1/4 inch full lip round corner strike, so the knob retracts the latch and holds the door closed. A dummy knob is surface trim with no latch at all, used on inactive leaves and closet doors held by a catch. Dummy options include the Schlage A170 single dummy trim, the BEST 6K single dummy trim, the Bravura Biloxi dummy knobset, and the Cal-Royal BA40 dummy knob for 1-3/8 inch to 1-3/4 inch doors. Do not substitute a dummy where the opening needs a latch.
8) My door is thicker than 1-3/4 inches - which passage knob covers it if the Olivia does not?
The Delaney Olivia passage knobset is built for standard doors 1-3/8 inch to 1-3/4 inch thick. For a thicker slab, the Corbin Russwin CK4310 Grade 1 passage/closet cylindrical lock with Global knob covers 1-3/8 inch to 2 inch, and the Falcon X101 Grade 1 heavy duty passage knobset covers 1-3/8 inch to 2-1/4 inch. The Lockey 3830 keyless combination knob lock with auto-locking passage function spans 1-3/16 inch to 2 inch if a code entry is also wanted.
9) Can I use the Olivia passage knobset on a hollow metal door?
Yes. It comes with combination screws that mount to either wood or metal doors, so you are not buying separate fasteners for a steel door as long as the bore is standard at 2-1/8 inch cross bore and 1 inch edge bore and the door falls in the 1-3/8 to 1-3/4 inch range.
10) What finishes does the Delaney Olivia passage knob come in, and will it match my other doors?
Three finishes: US32D stainless steel, US12P Tuscany bronze, and US19 black. Delaney states the Olivia coordinates with the Olympus series, so if your entry or privacy hardware is Olympus you can carry one look across the openings.
11) Do I need to worry about handing when ordering the Olivia knobset?
No. It is a cylindrical bored passage set with no locking mechanism and both knobs always free, so there is no hand to specify. Order the finish, drill the standard 2-1/8 inch cross bore, and set the latch for your 2-3/8 or 2-3/4 inch backset.
12) Can I use the Delaney Olivia passage knobset on a classroom or storeroom door?
No. The Olivia is passage function with no locking mechanism, so it cannot secure a room. For a classroom door, the Dexter C2000 classroom cylindrical ball knob is Grade 2 keyed for 1-3/8 inch to 1-3/4 inch doors. For storeroom, the Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with single cylinder, and the Sargent 8XG04 is a Grade 1 heavy duty storeroom/closet knob lock with a 2-3/4 inch backset.
13) What do I order if I need a keyed knob on the same door instead of the Olivia passage set?
Passage is non-keyed by design, so for a keyed opening switch function. Staying at Grade 3, Cal-Royal BER00 is an entrance/office knob lock with a Kwikset keyway for 1-3/8 inch to 1-3/4 inch doors, Pamex FTF Baron is offered in entrance/office function over the same thickness range, and the Kwikset 400P-CP Polo keyed entry knob is Grade 3 for 1-3/8 inch to 1-3/4 inch doors. The Delaney Olivia passage set can also be paired with a separate deadbolt when a back door only needs added security.
14) What is a mid-grade step up from the Olivia passage knobset without going to Grade 1?
Grade 2 passage knob sets that sit between the Grade 3 Olivia and heavy duty hardware include the Dexter C2000 passage cylindrical ball knob, Grade 2 non-keyed for 1-3/8 inch to 1-3/4 inch doors; the Arrow MK01 Grade 2 passage cylindrical knob over the same thickness range; and the Corbin Russwin CK4410 Grade 2 passage/closet lock with Global knob, also 1-3/8 inch to 1-3/4 inch. All three drop into the same door prep thickness band as the Olivia.
15) Is the Kwikset Polo passage knob a drop-in alternative to the Delaney Olivia passage knobset?
Functionally yes for a hall or closet door. The Kwikset 200P Polo passage knob is an interior hall/closet lock supplied with a 6AL latch and RCS round corner strike, and the 200P-CP ships with a round corner adjustable latch and round corner strike. The Olivia passage knobset also uses a round corner strike, 1-3/4 inch by 2-1/4 inch full lip, and fits both 2-3/8 inch and 2-3/4 inch backsets with a 2-1/8 inch cross bore and 1 inch edge bore, so the standard bored prep is shared. Confirm the existing strike cutout is round corner rather than square before swapping either way.
16) Is this a knob or a lever? I need something a tenant with limited grip can use.
The Olivia is a knobset, not a lever. Knobs require a twisting grip, so if accessibility is the driver you want a lever design instead. Within the same passage function, the comparable knob options include the Pamex FTF Grade 3 passage knob and the Bravura Albany Grade 2 passage knobset, but all of those are knobs as well.
17) What decorative passage knob alternatives are there if the Olivia styling is too plain for the project?
For a more ornamental interior passage knob, the Baldwin Estate 5011 Colonial passage knob with 5058 rose and the Baldwin Estate 5000 Baltimore knob with 5048 rose, supplied with a 2-3/8 inch backset and full lip strike, are both passage function. The Omnia 434/PA egg-shaped knob latchset in passage function is solid brass with a 3 inch projection. The Bravura Albany and Lynchburg round trim passage knobsets are Grade 2 if a stated grade is needed alongside the styling; the Delaney Olivia carries Grade 3.
18) I am buying passage knobs in quantity for an apartment turn - is there a multi-pack option?
The Delaney Olivia passage knobset is sold as a single set, offered in US32D Stainless Steel, US12P Tuscany Bronze and US19 Black. If you would rather buy pre-packed quantity, the Sure-Loc Bergen round knob is offered as a 6-pack with adjustable backset. The Olivia itself fits both 2-3/8 inch and 2-3/4 inch backsets, so either approach handles mixed door prep across units.
