Delaney Olivia - Grade 3 Entrance Knobset

It drops into standard residential prep: 2-1/8 inch cross bore, 1 inch edge bore, and a latch that works at either a 2-3/8 inch or 2-3/4 inch backset. Door thickness range is 1-3/8 to 1-3/4 inches, so it covers both a typical 1-3/4 inch exterior door and an older 1-3/8 inch interior slab. Faceplate is 1 x 2.25 inches with round corners.

The latch has a 1/2 inch throw and ships with a 1-3/4 x 2-1/4 inch full lip round corner strike. If your existing strike is the same round corner size, the new latch will engage it; if your jamb has a square corner strike mortise, use the supplied round corner strike and re-cut, or the new plate will not sit flush.

Yes, within those two keyways. The Olivia is offered in KW1 5-pin (the standard Kwikset-style keyway) or SC1 5-pin (Schlage-style), and you choose keyed different or keyed alike at the time of order. For a rental unit or a house where every exterior door should take one key, order keyed alike in the keyway your other cylinders already use.

The Delaney Olivia is a Grade 3 knobset catalogued for residential use. For commercial traffic, step up to the BEST 8K Series entrance function single cylinder knob lock, which is Grade 1 heavy duty, or the Corbin Russwin CK4851 entrance/office cylindrical lock with Global knob and conventional cylinder, Grade 1, fitting 1-3/8 inch to 2 inch doors. A middle step is the Dexter C2000 entry/office ball knob, Grade 2, keyed, for 1-3/8 inch to 1-3/4 inch doors. All three keep the keyed entrance function you get from the Olivia.

The Olivia covers standard doors from 1-3/8 inch to 1-3/4 inch. For a thicker slab, the Corbin Russwin CK4851 entrance/office cylindrical lock is Grade 1 and rated for 1-3/8 inch to 2 inch doors, and the Deltana 3381 Egg knob entry and Deltana 6171 Round knob entry both cover 1-3/8 inch to 2 inch. If the opening is thicker still, the Falcon X101 cylindrical knobset handles 1-3/8 inch to 2-1/4 inch, though it is passage function rather than keyed.

The Delaney Olivia is a Grade 3 keyed entrance knobset with a 5-pin KW1 cylinder and adjustable 2-3/8 inch and 2-3/4 inch backset. The Kwikset 400P-CP Polo keyed entry knob is also Grade 3 entrance function and fits 1-3/8 inch to 1-3/4 inch doors, the same thickness range the Olivia covers. The Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway, so it accepts the same KW1 keys, and also fits 1-3/8 inch to 1-3/4 inch doors. Master Lock BC01 is another Grade 3 keyed entry knob. Any of the three is a like-for-like swap on a residential entry opening.

The Olivia is a keyed single cylinder entrance knobset, so for a hall, closet, or bedroom you want a different function entirely. For passage, the Pamex FTF Baron knob lockset in passage function is Grade 3 and fits 1-3/8 inch to 1-3/4 inch doors, and the Dexter C2000 passage ball knob is Grade 2 over the same thickness range. For a bed or bath door needing a thumbturn, the Pamex FTF Baron privacy and the Cal-Royal BER20 are both Grade 3 privacy knob locks for 1-3/8 inch to 1-3/4 inch doors. For a false door with no latch, the Bravura Biloxi round trim dummy knobset is Grade 2.

It is a keyed entry single cylinder lock. The inside knob has a push button that locks the outside knob; it releases when the key is turned outside or the inside knob is rotated. That makes it the right pick for a front, side, or garage-to-house door where you want the option of locking from inside without a key.

Yes. It comes with combination screws that work for either wood or hollow metal door mounting, provided the door carries the standard 2-1/8 inch cross bore and 1 inch edge bore.

The Olivia covered here is the keyed entrance function only. If you need a matched set of functions across bedroom, closet, and entry doors in one design, the Pamex FTF Baron Grade 3 line is offered in entrance/office, privacy, and passage, and the Dexter C2000 Series covers entry/office, privacy, passage, and classroom at Grade 2.

Straight equivalents at the same duty level: the Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway and a 1-3/8 to 1-3/4 inch door thickness range, and the Kwikset 400P-CP Polo is a Grade 3 keyed entry knob over the same thickness range. The Callan Canova and Callan Santo are also Grade 3 entrance knobsets if you are matching a different knob shape.

Both are required selections. Pick the keyway first (KW1 5-pin standard or SC1 5-pin), then the keying: keyed different for individual units, or keyed alike when several locks on the same order should share one key. The standard cylinder is 5 pin KW1.

No. The Olivia is entrance function: the inside button locks the outside knob until a key is used outside or the inside knob is rotated, so the outside knob can be left unlocked. A storeroom knob keeps the outside knob locked at all times and requires the key on every entry. If that is the behavior you need, the Sargent 6G04 is a Grade 2 storeroom/closet knob lock with single cylinder, and the Sargent 8XG04 is the Grade 1 heavy duty storeroom version with a 2-3/4 inch backset. Substituting one for the other will change how the door secures.

The Olivia is a Grade 3 entrance knobset sold in US32D stainless steel, US12P Tuscany bronze, and US19 black. Within the same grade and function, the Callan Canova and the Callan Santo are both Grade 3 entrance knobsets in different series styling, and the Pamex FTF Baron is a Grade 3 entrance/office knob lockset for 1-3/8 inch to 1-3/4 inch doors. If you want to stay in a similar function but move up a grade for the same look family, the Callan Edgewood and Callan Roland are Grade 2 entrance knobsets.

The Olivia is a keyed entry knobset using a 5-pin KW1 or SC1 cylinder, so every user needs a cut key. The Lockey 3830 is a mechanical keyless combination knob lock with auto-locking passage function that fits doors from 1-3/16 inch to 2 inch, which is a wider range than the Olivia covers. It trades key control for a pushbutton code, so rekeying and keyed-alike grouping no longer apply.

The Olivia is a Grade 3 residential entrance knobset. For a labeled opening, specify a knob lock that is listed as fire rated: the Falcon W101 Grade 2 cylindrical knob lock is fire rated with a 2-3/4 inch backset in passage/closet function, and the Falcon X101 Grade 1 heavy duty cylindrical passage knobset with interchangeable core is also fire rated and fits 1-3/8 inch to 2-1/4 inch doors.

Only if the door does not need to lock. The Olivia is a keyed single cylinder entrance knobset with a 5-pin KW1 cylinder. The Kwikset 200P Polo is a passage knob for interior hall and closet openings and ships with a 6AL latch and RCS round corner strike, with no cylinder at all. The keyed counterpart in that same Polo style is the Kwikset 400P, which is entrance function with the 6AL latch and RCS strike, and that is the one that stands in for the Olivia.

Three: US32D stainless steel, US12P Tuscany bronze, and US19 black. If you are matching other openings in a building, US32D reads as brushed stainless against satin nickel trim, while US19 is a flat black for modern or farmhouse packages.

The Olivia is sold as a keyed entrance knobset on its own, ordered per finish and per keyway. If you would rather buy the entry and interior trim together, the Schlage Residential F500 Plymouth with Georgian knob is a combo pack with adjustable backsets and dual strikes for 1-3/8 inch to 1-3/4 inch doors. For stocking interior openings in quantity, the Sure-Loc Bergen round knob ships as a 6-pack with adjustable backset.
