Delta Breez BreezSlim Ventilation Fans - SLM80-110DLED-C - 80/110 CFM Fan/Dimmable LED Light with Dual Speed

Delta Breez BreezSlim Ventilation Fans - SLM80-110DLED-C - 80/110 CFM Fan/Dimmable LED Light with Dual Speed

(No reviews yet) Write a Review

Model: SLM80-110DLED-C
From the BreezSlim Collection
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$202.77
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Super Low Profile. Super Low Energy Consumption.
Delta BreezSlim SLM80-110DLED-C is suitable for ceiling or wall mount installation. It is ENERGY STAR qualified with Brushless DC Motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 110 CFM and loudness rating of 1.3 sones at 0.1 static pressure as certified by the Home Ventilating Institute (HVI); power consumption of 16.5 Watts with efficiency rating of 6.6 CFM/Watt at 0.1” static pressure; fan will feature motor lock protection and self-compensating motor speed for intended airflow when static pressure is encountered. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.

Features

  • ENERGY STAR® qualified with innovative brushless DC motor technology
  • UL approved for ceiling or wall mount installation, and it can fit in a 4" wall
  • 4" Oval Duct
  • SLM80-110DLED-C can fit with Ceiling Radiation Damper SMT-CRD2
  • Perfectly quiet operation at 0.4 sones (80 CFM), 1.3 sones (110 CFM)
  • Adjustable full speed 80 CFM or 110 CFM
  • Allows fan to operate in full speed mode or continuous low speed mode by manual switch
  • Energy efficiency at 8.8 CFM/Watt (80 CFM), 6.6 CFM/Watt (110 CFM)
  • For continuous low speed mode, the fan runs continuously at a user-preset lower level (0, 50, 80 CFM)
  • Delay time preset positions (0.5, 5, 15, 30, 45, or 60 min)
  • 13-Watt Dimmable LED light included (equivalent to a 60-Watt incandescent bulb). Dimmer switch not included
  • Main light output: 850 Lumens; 3000K; 90 CRI for high color accuracy and compliance with CEC JA8 Title 24 requirements
  • Green and amber LED indicator lights show continuous low speed and full speed modes
  • Annual energy cost for 24/7 operation is approximately $8.94* (80 CFM) or $17.35* (110 CFM)

Product Specs

Subcategory:
BreezSlim
Fan Speed:
Continuous Low Speed/Full Speed
Static Pressure:
0.1 - 0.25
Maximum CFM:
106
Sones:
0.3 - 1.5
Power:
24-Jun
Current:
0.6 Max.
Energy Star:
Yes
Warranty:
3 Year Limited
Duct Size:
4"
Duct Diameter:
4"
Product Group:
Washroom/Bath
Product Subgroup:
Ventilation Fans
Collection:
BreezSlim
Product Voltage:
120/60
Product Height:
4"
Product Category:
Ventilation Fans
Product Width:
13"
Department:
Plumbing
Product Depth:
13"

Delta Breez SLM80-110DLED-C – Frequently Asked Questions

1) Can the Delta Breez BreezSlim SLM80-110DLED-C be installed in a 2x4 wall?
Yes. The BreezSlim SLM80-110DLED-C is UL approved for ceiling or wall mount installation and the housing fits in a 4 inch wall. Housing height is 4 inches, with a 13 by 13 inch footprint, so joist or stud bay depth is rarely the limiting factor on a remodel.
2) What size duct do I need for the BreezSlim SLM80-110DLED-C bath fan?
It takes 4 inch duct, specifically a 4 inch oval duct connection at the housing. If your existing run is 4 inch round, that is the same nominal size, but plan the transition at the fan since the outlet itself is oval.
3) Can this Delta Breez fan be installed over a tub or shower?
Yes. The SLM80-110DLED-C is UL and cUL listed for use in a tub or shower enclosure, provided it is wired to a GFCI-protected branch circuit. Standard supply is 120V, 60 Hz, drawing 0.6 amps max.
4) How do the 80 CFM and 110 CFM settings work on the BreezSlim dual speed fan?
The fan is field adjustable for a full speed output of either 80 or 110 CFM, set at install. Separately, a manual switch lets it run in continuous low speed mode at a user-preset level of 0, 50 or 80 CFM, or kick to full speed. That combination covers both a spot-vent bathroom and a whole-house continuous ventilation requirement without a second fan.
5) Do I need a dimmer switch for the LED light on this Delta Breez fan?
The 13-watt dimmable LED is included in the fan, but the dimmer switch is not. If you want dimming you supply a compatible dimmer; wired to a standard switch it simply runs at full output, 850 lumens at 3000K with 90 CRI.
6) Can I use a ceiling radiation damper with the BreezSlim SLM80-110DLED-C?
Yes. It is rated to fit the SMT-CRD2 ceiling radiation damper, which is what you need when the fan penetrates a fire-rated ceiling assembly in multi-family or commercial work. The damper is a separate order.
7) How loud is the Delta Breez SLM80-110DLED-C bathroom fan?
0.4 sones at the 80 CFM setting and 1.3 sones at 110 CFM, HVI certified at 0.1 inch static pressure. Anything at or under 1.5 sones is quiet enough for a hotel guest bath or a multi-family unit where noise complaints matter. Published sone range across operating conditions is 0.3 to 1.5.
8) Does this bath fan meet California Title 24 requirements?
The light output on the SLM80-110DLED-C is 3000K at 90 CRI, which the manufacturer states complies with CEC JA8 Title 24 requirements. The fan itself is ENERGY STAR qualified.
9) Does this Delta Breez fan have a built-in timer?
There is a delay-off function with preset positions of 0.5, 5, 15, 30, 45 or 60 minutes, set at the fan rather than at the wall. Green and amber indicator LEDs tell you at a glance whether it is in continuous low speed or full speed.
10) Will this fan keep its airflow on a long duct run with elbows?
It uses a brushless DC motor with self-compensating speed, so it increases motor speed to hold the intended airflow when static pressure rises. Published performance covers 0.1 to 0.25 inches of static pressure, and it includes motor lock protection. The motor is engineered for a minimum 70,000 hours of continuous running, which is why it suits continuous-ventilation duty rather than intermittent use only.
11) How much power does the Delta Breez BreezSlim 110 CFM fan draw?
16.5 watts at the 110 CFM setting, an efficiency of 6.6 CFM/watt at 0.1 inch static pressure; at 80 CFM it runs 8.8 CFM/watt. Maximum current is 0.6 amps on a 120V, 60 Hz circuit, so several units can share a branch circuit in a multi-unit retrofit.
