Detex Electric Integration Hardware Kit – For Value and Advantex Series Exit Devices

Detex Electric Integration Hardware Kit for Value and Advantex Series Exit Devices with Electronic Control

(No reviews yet) Write a Review

Model: 101809-5

In Stock (leaves warehouse same day if ordered before 3pm ET)

$23.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Detex Electric Integration Hardware Kit for Value and Advantex Series Exit Devices with Electronic Control

Advanced Electronic Control Integration for Mechanical Exit Devices

The Detex Electric Integration Hardware Kit transforms standard mechanical panic hardware from the Value Series and Advantex Series into sophisticated electrified systems. This professional integration kit enables advanced electronic control functions including delayed egress, access control, and emergency override capabilities while maintaining full life safety code compliance. Compatible with 12VDC or 24VDC power supplies and designed for seamless integration with logic controllers and magnetic locks.

Professional Features & Benefits

  • Series Compatibility: Specifically engineered for Detex Value Series and Advantex Series exit devices for reliable mechanical-to-electronic conversion.
  • Advanced Control Functions: Enables delayed egress setups, access control configurations, and emergency override systems for enhanced security management.
  • Flexible Power Options: Compatible with external 12VDC or 24VDC power supplies for versatile system integration requirements.
  • System Integration Ready: Easily integrates with logic controllers, magnetic locks, keypads, card readers, remote switches, and fire alarm systems.
  • Life Safety Compliance: Retains panic device compliance with life safety requirements while adding electronic control capabilities.
  • Versatile Installation: Supports both retrofit applications and new installations for maximum project flexibility.
  • Compatible Accessories: Works with logic controllers such as Detex 12-800, magnetic locks, remote switches, and alarm signaling systems for complete system solutions.
  • Professional Applications: Ideal for commercial, industrial, and healthcare settings requiring additional security and controlled access functionality.

Technical Specifications

  • Product Category: Parts and Accessories
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Devices - Vertical Rod
  • Product Type: Exit Devices - Vertical Rod
  • Subcategory: Accessories

Installation & Operation

This integration kit is designed for use with compatible Detex Value Series and Advantex Series exit devices. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Office Buildings with Access Control
  • Healthcare Facilities Requiring Delayed Egress
  • Educational Institutions with Security Systems
  • Industrial Facilities with Controlled Access
  • Retail Establishments with Loss Prevention
  • Government Buildings with Enhanced Security
  • Multi-Tenant Properties with Electronic Control

Why Choose Detex Quality?

Detex Electric Integration Hardware Kits deliver professional-grade reliability for demanding commercial applications where dependable electronic control is essential. Engineered specifically for Value Series and Advantex Series compatibility, this kit maintains life safety compliance while enabling advanced security functions. The system supports flexible power requirements and integrates seamlessly with professional access control components for comprehensive door security solutions.

Manufacturer Resources

Product Specs

Subcategory:
Accessories
Product Group:
Exit Devices and Trim
Product Type:
Exit Devices - Vertical Rod
Product Subgroup:
Exit Devices - Vertical Rod
Product Category:
Parts and Accessories
Department:
Door Hardware

Detex 101809-5 – Frequently Asked Questions

1) What does the Detex 101809-5 electric integration kit actually do on an exit device?
The 101809-5 is an electric integration hardware kit that converts a mechanical Detex Value Series or Advantex Series panic device into an electrified one. Once fitted, the device can support delayed egress, access control release, and emergency override while still functioning as a panic device for life safety. It is the hardware that ties the exit device into an electronic system, not a complete exit device on its own.
2) Will this Detex kit work on a Von Duprin or Marks USA vertical rod exit device?
No. The 101809-5 kit is built for Detex Value Series and Advantex Series exit devices only. If your opening has a Von Duprin 8827 or a Marks USA M9900VR, this kit is not the part; you would need an electrified option from that device's own manufacturer, or replace the device with a Detex Value or Advantex unit first.
3) What voltage power supply do I need for the Detex electric integration kit?
It runs off an external 12VDC or 24VDC supply. The power supply is separate, so budget for it along with any logic controller or access control head end you are wiring into.
4) What else do I have to order to make a delayed egress setup work with this kit?
The kit itself is the device-side hardware. A working delayed egress or access controlled opening also needs an external 12VDC or 24VDC power supply and a logic controller, such as the Detex 12-800, plus whatever release and signaling devices the design calls for: magnetic locks, keypads, card readers, remote switches, and a fire alarm connection for release on alarm.
5) I need a complete vertical rod exit device, not an electric kit - what are the options?
The Detex 101809-5 is an accessory kit that adds electronic control to an existing Detex Value or Advantex Series device, so it does not include a panic device. For a complete surface vertical rod device, the Von Duprin 8827-3FT is a Grade 1 wide stile device for a 3 ft opening with a 1-3/4 inch door thickness, the Imperial USA ED-VR531 is a Grade 1 wide stile exit-only device for a 36 inch door in the ED-500 Series, and the Marks USA M9900VR is a non-handed exit-only device for a 36 inch by 84 inch door. Delaney also offers the 9100 Series and 8100 Series Grade 1 vertical rod devices for 36 inch by 84 inch doors.
6) Can the Detex 101809-5 electric integration kit be used to electrify a Von Duprin or Marks USA vertical rod exit device?
No. The Detex 101809-5 electric integration hardware kit is engineered specifically for Detex Value Series and Advantex Series exit devices, and compatibility with the existing hardware has to be confirmed before installation. Devices from other makers such as the Von Duprin 8827-3FT wide stile surface vertical rod device or the Marks USA M9900VR 36 inch by 84 inch vertical rod panic device are separate complete exit devices with their own electrification paths, so the Detex kit is not a means of adding delayed egress or access control to them.
7) The opening is a fire rated pair - does the Detex 101809-5 kit apply, or do I need different hardware?
The Detex 101809-5 kit adds delayed egress, access control, and emergency override functions to Detex Value and Advantex Series devices while retaining panic device compliance with life safety requirements, but the device itself determines the fire rating of the assembly. Where a fire rated vertical rod device is what the opening calls for, the Delaney F9100 Series is a Grade 1 fire rated heavy duty vertical rod device for a 36 inch by 84 inch door, and the Marks USA M9900FVR covers 36 inch by 84 inch fire rated while the MARM9900F-VR covers 48 inch by 84 inch fire rated, both exit only. Note that delayed egress is not permitted on every fire rated opening, so confirm the requirement with the authority having jurisdiction.
8) Can I add this to exit devices already installed, or is it new construction only?
Both. The kit is written for retrofit onto existing Detex Value or Advantex devices as well as new installations. On a retrofit, confirm the device on the door is actually a Value or Advantex unit before ordering, and follow the parent device's installation instructions for the integration.
9) Does electrifying the exit device with this kit affect panic egress compliance?
No. Adding the 101809-5 keeps the panic device's life safety egress function intact while layering electronic control on top of it. That is the point of the kit: security and access control without giving up free egress on the pushbar.
10) Is this the right approach for a healthcare unit that needs delayed egress on stair and exit doors?
Yes, that is one of its intended uses. The kit lets a Detex Value or Advantex panic device run delayed egress, and it can be tied to the fire alarm so the door releases on alarm. It is also used for access controlled office, school, industrial, retail, government, and multi tenant openings where the door has to stay secure but egress cannot be defeated.
11) If I do not need electronic control at all, what is the simpler vertical rod option?
The Detex 101809-5 exists only to bring electronic functions - delayed egress, access control, emergency override, and integration with logic controllers, magnetic locks, keypads, card readers, and fire alarm systems - to a mechanical Detex device. A purely mechanical opening needs none of that. The Cal-Royal 9860 is a heavy duty Grade 2 surface vertical rod exit-only device, and the Delaney 8100 Series is a Grade 1 vertical rod device for a 36 inch by 84 inch door; both are non-fire-rated mechanical devices with no power supply or controller in the picture.
12) My opening is a 48 inch leaf - does that change what I order alongside the Detex 101809-5?
Door width does not select the 101809-5 itself; the kit is matched to the Detex Value or Advantex Series device it electrifies, and that device is sized to the leaf. For a 48 inch by 84 inch vertical rod opening, the Marks USA M9900VR-48X84 is an exit-only device at that size and the Marks USA MARM9900F-VR is the 48 inch by 84 inch fire rated exit-only version. The 36 inch equivalents include the Von Duprin 8827-3FT for a 3 ft opening and the Imperial USA ED-VR531 at 36 inches.
