Panduit B4M2S-TL Dome-Top B4M2S-TL Barb Marker Tie, PA6.6, 8"L, 50lb, PK250

Panduit B4M2S-TL Dome-Top Barb Marker Cable Tie, 8" Natural Nylon 6.6

(No reviews yet) Write a Review

Model: B4M2S-TL

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,134.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit B4M2S-TL Dome-Top Barb Marker Cable Tie, 8" Natural Nylon 6.6

Panduit's B4M2S-TL Dome-Top Barb Marker Cable Tie combines secure cable bundling with built-in identification in one component. Built from durable Nylon 6.6, this 8" tie delivers a 50lb minimum loop tensile strength and accommodates bundle diameters from 0.37" to 2", making it suitable for demanding commercial and industrial cable management. The tie is UL 62275 compliant and RoHS compliant, and includes an integrated 2.47" x 0.91" write-on area for fast, clear labeling directly on the bundle.

Key Features

  • Overall Length: 8" tie accommodates bundle diameters from 0.37" to 2" (maximum).
  • Durable Construction: Natural Nylon 6.6 material resists chemicals and supports long-term indoor and outdoor reliability.
  • Dome-Top Barb Design: Low-profile barb reduces snagging while providing a secure, retained grip on cable bundles.
  • Minimum Loop Tensile Strength: 50lb (222N) rating supports heavy-duty bundling applications.
  • Integrated Write-On Area: 2.47" x 0.91" marking surface allows on-tie cable identification without separate labels.
  • Wide Operating Range: Rated from -70°F to 185°F, with a minimum installation temperature of -4°F.
  • Natural Color Finish: Clean, professional appearance suited to visible commercial and industrial installations.

Certifications & Compliance

  • UL 62275 Compliant
  • RoHS Compliant

Technical Specifications

  • Arra Compliant: Y
  • Body Thickness Mm: 1.2
  • Body Width Mm: 4.7
  • California Pro65 Cancer: No
  • Hazardous Material Flag: N
  • Lead Content Indicator: N
  • Maximum Bundle Diameter In: 2
  • Maximum Bundle Diameter Mm: 51
  • Maximum Operating Temperature C: 85
  • Maximum Operating Temperature F: 185
  • Mercury Content Indicator: N
  • Min Order Qty: 250
  • Minimum Bundle Diameter Mm: 9.5
  • Minimum Installation Temperature C: -20
  • Minimum Installation Temperature F: -4
  • Minimum Loop Tensile Strength Lb: 50
  • Minimum Loop Tensile Strength N: 222
  • Minimum Operating Temperature C: -60
  • Minimum Operating Temperature F: -70
  • Overall Length In: 8
  • Overall Length Mm: 203
  • Pallet Weight: 648
  • Product Segment: IEI
  • Reach Status: N
  • Standard Carton Weight Pounds: 36
  • Standard Package Weight Pounds: 3.6
  • Std Package Height In: 2.4
  • Std Package Length In: 14
  • Std Package Width In: 14
  • Std Pkg Qty: 250

Typical Applications

  • Telecommunications Equipment Rooms and Data Centers
  • Electrical Panel and Control Cabinet Organization
  • Industrial Machinery and Equipment Wiring
  • Network and Server Room Cable Management
  • General Purpose Cable Bundling and Identification

Why Panduit?

Panduit's Nylon 6.6 construction, UL 62275 compliance, and RoHS compliant materials make this cable tie a dependable choice for professional cable management. The wide -70°F to 185°F operating range and integrated write-on area help installers bundle, label, and maintain cable runs with confidence in commercial and industrial environments.

Manufacturer Resources

Product Specs

Application:
General
Arra Compliant:
Y
Body Thickness In :
0.45
Body Thickness Mm :
1.2
Body Width In :
0.185
Body Width Mm :
4.7
California Pro65 Cancer:
No
Country Of Origin:
Costa Rica
Ean:
74983777396
Environment:
Indoor
For Use With:
Bundles
Gtin Carton:
5.0075E+13
Gtin Package:
74983777396
Hazardous Material Flag:
N
Lead Content Indicator:
N
Marker Type:
Wrap
Maximum Bundle Diameter In :
2
Maximum Bundle Diameter Mm :
51
Maximum Operating Temperature C :
85
Maximum Operating Temperature F :
185
Mercury Content Indicator:
N
Min Order Qty:
250
Minimum Bundle Diameter In :
0.37
Minimum Bundle Diameter Mm :
9.5
Minimum Installation Temperature C :
-20
Minimum Installation Temperature F :
-4
Minimum Loop Tensile Strength Lb :
50
Minimum Loop Tensile Strength N :
222
Minimum Operating Temperature C :
-60
Minimum Operating Temperature F :
-70
Overall Length In :
8
Overall Length Mm :
203
Pallet Quantity:
45,000
Pallet Volume:
48.059872
Pallet Weight:
648
Product Color:
Natural
Product Material:
Nylon 6.6
Product Segment:
IEI
Product Type:
Cable Tie
Reach Status:
N
Rohs Compliant:
Compliant
Standard Carton Volume Ft3:
2.67
Standard Carton Weight Pounds:
36
Standard Package Volume Ft3:
0.267
Standard Package Weight Pounds:
3.6
Std Carton Height In:
14.41
Std Carton Height Mm:
366.014
Std Carton Length In:
21.96
Std Carton Length Mm:
557.784
Std Carton Width In:
14.58
Std Carton Width Mm:
370.332
Std Ctn Qty:
2500
Std Package Height In:
2.4
Std Package Height Mm:
60.96
Std Package Length In:
14
Std Package Length Mm:
355.6
Std Package Width In:
14
Std Package Width Mm:
355.6
Std Pkg Qty :
250
Std Pkg Uom:
Piece
Write On Area Height In :
0.91
Write On Area In :
2.47W x 0.91H
Write On Area Width In :
2.47
Department:
Electrical
Product Group:
Wiring Devices

Panduit B4M2S-TL – Frequently Asked Questions

1) How big is the write-on label area on the Panduit B4M2S-TL, and how much can I actually fit on it?
The integrated marking panel measures 2.47 inches wide by 0.91 inches high. That is enough for a circuit ID, port or drop number, and a short destination note written with a permanent marker, so you do not need a separate wrap label or a printed sleeve. It is a wrap-style marker built into the tie body.
2) Are these Panduit marker ties rated for outdoor use?
The B4M2S-TL is specified for indoor environments, in natural (undyed) nylon 6.6. Natural nylon is not UV stabilized, so for exposed outdoor runs you want a black weather-resistant tie instead. Indoors, the natural color takes marker ink well and reads clearly in a rack or cabinet.
3) Do Panduit B4M2S-TL cable ties meet UL and RoHS requirements for a federally funded job?
They are UL 62275 compliant and RoHS compliant, and flagged ARRA compliant, which matters on federally funded work. No lead, no mercury, no California Prop 65 cancer listing, and they are not classed as hazardous material for shipping. Country of origin is Costa Rica.
4) Can I install Panduit B4M2S-TL ties in a cold building or unheated space?
Installation is rated down to -4 F (-20 C). Once installed, the tie holds across a -70 F to 185 F range. So a cold warehouse or mechanical space in winter is fine, but do not try to seat these below -4 F, nylon gets brittle and the barb can crack on the ratchet.
5) What is the minimum order quantity and how do Panduit B4M2S-TL ties come packaged?
They ship in packs of 250 pieces, and 250 is also the minimum order. A standard carton holds 2,500 pieces (ten packs) and a full pallet runs 45,000. Handy if you are standardizing identification across a facility and buying by the carton.
6) Can I use a B4M2S-TL marker tie instead of a separate wire label on data cable runs?
That is the point of it. You get bundling and identification in one piece, so there is no adhesive label to peel off a jacket and no printed sleeve to thread on before termination. Write the ID on the 2.47 by 0.91 inch panel as you dress the bundle. The tradeoff is handwriting rather than machine printing, so for long permanent labeling schemes with barcodes you still want a printed marker system.
7) What does the dome-top barb design on this Panduit tie change compared with a standard pawl tie?
The barb sits inside a low, rounded dome head rather than a flat-topped locking pawl. Practically, that means less to snag on when you are pulling a hand through a dense bundle or sliding a bundle past a cabinet edge, and the barb is retained so it stays engaged on the ratchet strap. Functionally it is still a one-piece, non-releasable nylon 6.6 tie, just with the marker panel built into the strap.
