Don-Jo CV-86 Conversion Plate,...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$14.40
$12.32
Don-Jo CV-86 Conversion Plate, 8" x 1-1/4", 1/4" Gauge Steel, Prime Coated

Don-Jo CV-86 Conversion Plate, 8" x 1-1/4", 1/4" Gauge Steel, Prime Coated

(No reviews yet) Write a Review

Model: CV-86
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$14.40
$12.32
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo CV-86 Conversion Plate, 8" x 1-1/4", 1/4" Gauge Steel, Prime Coated

The Don-Jo CV-86 Conversion Plate is a commercial-grade door trim accessory engineered to cover and conceal existing cutouts or hardware preparations on doors during lock conversions or upgrades. Measuring 8" in length and 1-1/4" in width, this plate is constructed from 1/4" gauge steel and features a prime coat finish ready for field painting to match surrounding door hardware. Designed for commercial applications, it provides a clean, professional appearance when adapting or updating door hardware configurations.

Key Features

  • Precise Dimensions: Measures 8" in length and 1-1/4" in width, providing accurate coverage for standard door hardware cutouts and conversion applications.
  • Heavy-Gauge Steel Construction: Fabricated from 1/4" gauge steel for a durable, rigid filler plate that withstands the demands of commercial door environments.
  • Prime Coated Finish: Arrives with a prime coat applied, making it ready for field painting to coordinate with existing door hardware and finishes.
  • Commercial-Grade Quality: Rated for commercial use as a door trim and accessory component, suitable for high-traffic institutional and commercial settings.
  • Versatile Filler and Conversion Use: Classified as a filler plate, lock adapter, and wrap-around accessory, offering flexibility across a range of door hardware conversion and upgrade scenarios.
  • Convenient Shelf Pack: Available in a shelf pack of 10 units, making it practical for contractors and facilities managers handling multiple door conversions.

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Commercial/Residential: Commercial
  • Subcategory: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings Undergoing Lock Upgrades or Conversions
  • Educational Facilities Replacing or Updating Door Hardware
  • Healthcare Institutions Standardizing Door Hardware Configurations
  • Retail Establishments Concealing Legacy Hardware Cutouts
  • Industrial and Warehouse Facilities During Hardware Retrofits
  • Multi-Tenant Residential Properties with Commercial-Grade Door Requirements
  • Government and Municipal Buildings Performing Door Hardware Modernization

Why Don-Jo CV-86?

Don-Jo Conversion Plate products deliver professional-grade reliability through heavy-gauge steel construction and a prime coat finish engineered for commercial door hardware applications. The CV-86 is purpose-built for contractors and facilities professionals who require a dependable, field-ready filler plate that covers hardware cutouts cleanly and holds up in demanding commercial environments.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Conversion Plate
Commercial/Residential:
Commercial
Subcategory:
Filler Plates, Lock Adapters and Wrap Arounds
Product Model:
CV 86
Product Category:
Door Trim and Accessories
Product Substrate:
Steel
Department:
Door Hardware

Don-Jo CV-86 – Frequently Asked Questions

1) What is a Don-Jo CV-86 conversion plate actually used for?
The CV-86 is a flat steel filler plate that covers an old hardware cutout in a door face. When you pull a lock or piece of trim and the new hardware doesn't cover the same prep, the plate hides the leftover hole so the opening looks finished. It's a cover piece, not a working part of the lock, so it carries no latch, no cylinder, and no strike prep.
2) How big is the Don-Jo CV-86 plate, and will 8 x 1-1/4 cover my old lock prep?
The CV-86 measures 8 by 1-1/4 inches in 1/4 inch gauge steel. That footprint is long and narrow, so it suits a strip-shaped leftover prep (an old mortise or edge-style cutout) rather than a round knob bore. Measure the exposed hole in both directions first: anything wider than 1-1/4 inches will show around the edges of the plate, and you'd want a wider wrap around or filler instead.
3) Will the Don-Jo CV-86 fill the round hole left by an old knob lock?
No. The CV-86 is a 1-1/4 inch wide strip, narrower than a standard 2-1/8 inch knob or lever cross bore, so it won't span a round bore hole. For a vacated knob prep you want a round hole filler or a wrap around plate sized to the bore. The CV-86 is for narrow, elongated preps where an 8 inch long strip is the right shape.
4) Does the Don-Jo CV-86 come painted, or do I have to finish it myself?
Four finishes are offered: prime coated, brass plated, chrome plated, and duronodic brown coated. The prime coated version is bare primer meant to be field painted so it disappears into a painted door or matches surrounding trim. If you want the plate to read as hardware rather than as part of the door, take the brass, chrome, or duronodic instead and skip the paint step.
5) Is the CV-86 heavy enough for a school or hospital door, or is it a thin cover plate?
At 1/4 inch gauge steel this is a rigid plate, not shim stock, and Don-Jo rates the CV-86 for commercial use. It holds its shape against kicks and cart traffic in institutional corridors, which is where thin stamped covers dish in and start rattling. Steel throughout, so it takes paint and abuse the same way the door does.
6) I'm standardizing locks across a building, how do I order enough CV-86 plates for a batch of doors?
The CV-86 is packed in shelf packs of 10, which lines up with the way these get used: a conversion program hits a run of openings at once and every door that changes hardware needs one. Pick a single finish across the run so the doors match, and if the doors are painted, prime coated plus your own topcoat gives the most consistent result across a mixed set of door colors.
7) Does the CV-86 conversion plate come with screws?
Fastener content isn't part of what the CV-86 is specified on, so plan to have machine screws or sheet metal screws on the truck sized to your door. On a hollow metal door that usually means self tapping screws into the face sheet; on wood, short pan heads. The plate itself is 1/4 inch steel, so drive fasteners with heads that sit flush against it rather than countersinking into a plate that thick.
