Don-Jo DS-234 Deadbolt Strike 2-3/4" x 1-1/8" Single Hole ASA Strike in 630 Satin Stainless Steel

Don-Jo DS-234 Deadbolt Strike 2-3/4" x 1-1/8" Single Hole ASA Strike in 630 Satin Stainless Steel

(No reviews yet) Write a Review

Model: DS-234-630
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4.90
$3.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo DS-234 Deadbolt Strike 2-3/4" x 1-1/8" Single Hole ASA Strike in 630 Satin Stainless Steel

The Don-Jo DS-234 is a commercial-grade deadbolt strike designed to deliver reliable latching performance in a compact, precisely dimensioned profile. Measuring 2-3/4" in height and 1-1/8" in width with a single latch hole, this ASA-pattern strike is constructed from 18-gauge ferrous steel (.050) and finished in 630 Satin Stainless Steel for lasting corrosion resistance. Radius corners are available, offering installation flexibility for a clean, professional fit in a wide range of door frame applications.

Key Features

  • Precise Dimensions: Measures 2-3/4" in height and 1-1/8" in width, providing a compact footprint suited for standard deadbolt strike applications.
  • Single Latch Hole Configuration: Features 1 latch hole designed to align with standard deadbolt throw geometry for secure, reliable engagement.
  • Heavy-Gauge Construction: Manufactured from 18-gauge (.050) ferrous steel for a sturdy, durable build capable of withstanding repeated use in commercial environments.
  • 630 Satin Stainless Steel Finish: The 630 finish provides a clean, professional appearance with excellent resistance to corrosion and tarnishing.
  • Multiple Finish Options: Available in finishes 605, 622, 630, and DU to coordinate with a variety of door hardware and frame aesthetics.
  • Radius Corners Available: Optional radius corner configuration allows for a refined, finished look and compatibility with routed strike preparations.
  • ASA Strike Pattern: Conforms to the standard ASA strike layout for broad compatibility with deadbolt locksets across commercial applications.
  • Commercial-Grade Quality: Rated for commercial use, making it suitable for high-traffic doors in offices, retail, and institutional settings.

Technical Specifications

  • Subcategory: Door Strikes
  • Product Group: Parts and Accessories
  • Product Subgroup: Door Strikes and Strike Boxes
  • Product Type: Door Strikes
  • Commercial/Residential: Commercial
  • Door Strike: ASA Strike
  • Product Substrate: Ferrous
  • Product Category: Parts and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Institutions
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities

Why Don-Jo DS-234?

Don-Jo deadbolt strike products are engineered for dependable commercial performance, combining 18-gauge (.050) ferrous steel construction with a precision-dimensioned 2-3/4" x 1-1/8" profile that meets the demands of high-traffic door applications. The DS-234's ASA-pattern layout and availability in multiple finishes — including 605, 622, 630, and DU — make it a versatile, professional-grade solution for installers and facility managers seeking consistent, long-lasting hardware performance.

Manufacturer Resources

DON-JO Strike Plates

Product Specs

Subcategory:
Door Strikes
Product Group:
Parts and Accessories
Product Subgroup:
Door Strikes and Strike Boxes
Product Type:
Door Strikes
Commercial/Residential:
Commercial
Product Model:
DS-234
Door Strike:
ASA Strike
Product Substrate:
Ferrous
Product Category:
Parts and Accessories
Department:
Door Hardware

Don-Jo DS-234-630 – Frequently Asked Questions

1) Will the Don-Jo DS-234 strike work in a frame prepped for a standard ASA strike?
Yes. The DS-234 is an ASA-pattern strike, so it drops into the standard ASA prep found in most commercial hollow metal frames. The face measures 2-3/4 x 1-1/8 inches with a single latch hole for the deadbolt. If your existing frame cutout is the common ASA layout, no new prep is needed.
2) Is the DS-234 a deadbolt strike or a latch strike for a knob or lever?
It is a deadbolt strike. The DS-234 has one hole sized for a deadbolt to shoot into, not the two-opening arrangement a latch strike uses. If you are replacing the strike for a cylindrical knob or lever latch, this is the wrong part; you want a latch strike instead. On a door with a separate deadbolt above the lockset, this is the piece that goes with the deadbolt.
3) I have a pair of doors with no mullion. Will an ASA deadbolt strike like the DS-234 work?
No. The DS-234 mounts in a frame jamb and needs a fixed jamb or mullion to fasten to, so it will not serve the meeting edge of a pair of doors. For a double door application, look at the Detex 92 Strike Kit, which is made for double doors and ships with tamper resistant fasteners.
4) My storefront door has a pipe or tube frame instead of a hollow metal jamb. Is the DS-234 the right strike?
Not for a round pipe jamb. The DS-234 has a flat 2-3/4 x 1-1/8 inch face made to sit against a flat frame prepped to the ASA pattern. Where the deadbolt is landing on a pipe column or tube rail, the Trimco 1260P pipe adapter strike is the part built for that condition.
5) Will the Don-Jo DS-234 match the strikes already installed on my other doors?
If the other openings use a standard ASA strike prep, yes, the DS-234 shares that pattern and the same 2-3/4 x 1-1/8 inch footprint, which is what lets a property manager buy one part for a whole building. Check two things on a sample door before ordering a case: that the existing plate is 2-3/4 inches on the long dimension (some frames use a taller 4-7/8 inch ASA plate) and whether the corners are square or radiused.
6) Is the Detex 92 strike kit a substitute for a Don-Jo DS-234 deadbolt strike?
No - they solve different openings. The DS-234 is an ASA-pattern deadbolt strike for commercial door frames, 2-3/4 inches by 1-1/8 inches with a single latch hole in 18-gauge ferrous steel. The Detex 92 Strike Kit is a double door strike kit from the 90 Strike Series supplied with tamper resistant fasteners, intended for a pair of doors rather than a single frame-mounted deadbolt prep. If you are replacing a deadbolt strike in an existing ASA cutout on a single leaf, the DS-234 is the part that matches the prep; a double door application is where the 92 kit belongs.
7) What is the difference between a Trimco 1260P pipe adapter strike and a Don-Jo DS-234 deadbolt strike?
The Trimco 1260P is a pipe adapter strike from the 1260 Series, supplied as a strike only, made to adapt a strike into a pipe or tube frame condition. The Don-Jo DS-234 is a flat ASA-pattern deadbolt strike, 2-3/4 inches by 1-1/8 inches with one latch hole, in 18-gauge ferrous steel with optional radius corners for routed strike preparations. For a standard hollow metal or wood frame with an ASA deadbolt prep, the DS-234 is the direct-fit part; the 1260P addresses a tube or pipe frame instead, so the two are not interchangeable on the same opening.
8) Can I get the Don-Jo DS-234 with radius corners for a routed frame prep?
Radius corners are available on the DS-234. That matters if your frame was routed rather than square-cut, since a square-corner strike leaves gaps at a radiused pocket. Square corner and radius corner both cover the same 2-3/4 x 1-1/8 inch face.
9) What finishes does the Don-Jo DS-234 deadbolt strike come in?
Four: 605 polished brass, 622 matte black, 630 satin stainless, and DU duronodic brown. For a building where you are standardizing, 630 satin stainless is the usual commercial default and matches most lever and deadbolt trim already in the field; DU is the one to pick against dark bronze aluminum entrances, 622 against black hardware.
10) Is the DS-234 strike heavy enough for a high traffic commercial door?
It is built for commercial use, stamped from 18-gauge ferrous steel at .050 thickness. That is the weight you want on an office, retail, school, or apartment entry where the deadbolt is thrown many times a day. Because the base metal is ferrous steel rather than brass or stainless throughout, the finish is what carries the corrosion resistance, which is why 630 satin stainless is the common spec for exterior openings.
11) Do I need a strike box behind the Don-Jo DS-234, or does it come with one?
The DS-234 is the strike plate itself, an 18-gauge ferrous steel face with a single deadbolt hole. No box or dust box is included, so order one separately if your frame is open behind the prep and you want the bolt end enclosed. In a filled or reinforced hollow metal frame with an existing ASA pocket, the plate alone is typically all that gets replaced.
12) I need a deadbolt strike that will match the rest of the hardware on a commercial building - which one keeps the finishes consistent?
The Don-Jo DS-234 deadbolt strike is offered in 605 polished brass, 622 matte black, 630 satin stainless, and DU duronodic brown, so the same 2-3/4 inch by 1-1/8 inch ASA strike can be run across doors with different existing hardware finishes without changing the prep. The Detex 92 Strike Kit and the Trimco 1260P pipe adapter strike are each built for a specific frame condition - a double door pair and a pipe or tube frame respectively - rather than for finish coordination across a fleet of standard openings. For standardizing deadbolt strikes building-wide on ASA-prepped frames, the DS-234 is the one that repeats.
