Don-Jo EM-2 Scar Plate — 9" Commercial Door Filler Plate

The Don-Jo EM-2 Scar Plate is a professional-grade commercial door accessory designed to cover and conceal cutouts, mortise pockets, or other door surface imperfections left behind after hardware removal or replacement. Measuring 9" in length, this scar plate is available in finishes 605 (Bright Brass) and 630 (Satin Stainless), making it a versatile solution for a wide range of commercial door applications. Engineered for use in commercial environments, the Don-Jo EM-2 provides a clean, finished appearance to door surfaces where previous hardware has been removed or relocated.

Key Features

  • 9" Length: Generously sized at 9" to effectively cover standard door cutouts, mortise pockets, and hardware scars on commercial doors.
  • Dual Finish Options: Available in finish 605 (Bright Brass) and finish 630 (Satin Stainless) to coordinate with existing door hardware and architectural aesthetics.
  • Commercial-Grade Construction: Designed and rated for commercial applications, ensuring durability and long-lasting performance in high-traffic environments.
  • Concealment Function: Effectively covers exposed cutouts, mortise voids, and surface imperfections left by removed or replaced door hardware for a clean, professional appearance.
  • Door Trim Compatibility: Classified under Filler Plates, Lock Adapters, and Wrap Arounds, making it suitable for use alongside a broad range of door trim and accessory hardware.
  • Easy Integration: Designed to integrate seamlessly into commercial door hardware upgrade or replacement projects, minimizing visible evidence of prior hardware installations.

Certifications & Compliance

  • Commercial-Grade Product — Rated for Commercial Applications

Technical Specifications

  • Subcategory: Accessory Hardware
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Type: Scar Plates
  • Commercial/Residential: Commercial
  • Product Model: EM 2
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings Requiring Door Hardware Upgrades
  • Educational Facilities Replacing or Relocating Door Hardware
  • Healthcare Institutions Updating Door Hardware Configurations
  • Retail Establishments Concealing Prior Hardware Cutouts
  • Industrial and Warehouse Facilities Refinishing Door Surfaces
  • Multi-Tenant Residential Properties with Commercial-Grade Doors
  • Government and Municipal Buildings Undergoing Hardware Renovation

Why Don-Jo EM-2?

Don-Jo Scar Plate products deliver professional-grade reliability with commercial-rated construction designed to provide a clean, finished appearance on doors where hardware has been removed or replaced. The EM-2 is engineered for demanding commercial applications where a polished, professional result is essential, and its availability in multiple finishes ensures compatibility with a wide variety of existing door hardware installations.

Product Specs

Subcategory:
Accessory Hardware
Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Scar Plates
Commercial/Residential:
Commercial
Product Model:
EM 2
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Don-Jo EM-4-630 – Frequently Asked Questions

1) What is a Don-Jo EM-2 scar plate actually used for on a commercial door?
The EM-2 is a cover plate that hides the hole left in a door after hardware is pulled or moved. Take out an old mortise lock, a knob set, or a pull, and you are left with a mortise pocket or a bore that the new hardware does not land over. The EM-2 sits over that void so the door reads as finished instead of patched. It is a cosmetic and surface-cover part, not a lock and not a reinforcement, so it does not add security on its own.
2) What size is the Don-Jo EM-2 scar plate, and will it cover my old mortise pocket?
The EM-2 comes in two sizes: 9 x 4 x 2-3/8 inches and 9 x 4-1/4 x 2-3/4 inches. Measure the cutout you need hidden, in both directions, plus enough margin to land on solid door face all the way around. If your void exceeds the 9 inch dimension in its longest direction, the EM-2 will not cover it and you need a longer wrap or filler plate. The 2-3/8 and 2-3/4 figures line up with the two standard commercial backsets, so the larger size is the one to reach for on a door that was prepped at a 2-3/4 backset.
3) Which Don-Jo EM-2 size do I order for a 2-3/4 inch backset door?
Order the 9 x 4-1/4 x 2-3/4 inch EM-2. The smaller 9 x 4 x 2-3/8 inch version carries the 2-3/8 dimension, which matches the other common commercial backset. Getting this wrong is the usual reason a scar plate arrives and the hole still shows on one side, so pull the old lock and measure from the door edge to the center of the bore before you order.
4) What finishes does the Don-Jo EM-2 scar plate come in, and which matches my existing hardware?
Two finishes: 605 polished brass and 630 satin stainless. Both sizes are offered in both finishes, so size and finish are independent choices. If the rest of the openings in the building are satin chrome or brushed stainless levers and hinges, 630 is the match. Bright, shiny brass trim takes the 605. On a door where the plate will sit next to surviving original hardware, match the neighbor, not the building average, since the eye reads the two side by side.
5) Do I need a scar plate or a wrap around plate to fix a damaged door?
Different jobs. A scar plate like the EM-2 is a flat cover for a hole or gouge on the door face where hardware used to be. A wrap around plate folds over the door edge and reinforces a split or kicked-in lock area, and it wraps both faces. If your problem is purely cosmetic (old hardware removed, hole showing), the EM-2 is the part. If the door edge itself is damaged or you need the lock area strengthened, a wrap around is what you want instead.
6) Can I use the Don-Jo EM-2 on both sides of the door?
Yes, and on a through-bored or mortised opening you usually need to. A mortise pocket or cross bore goes through the door, so pulling the lock leaves a void showing on both faces. One EM-2 covers one face. Order two per opening if both sides are exposed, and match the finish per side if the two sides of the door carry different hardware finishes.
7) Will a Don-Jo EM-2 scar plate cover a 161 prep or a standard 2-1/8 inch bore?
A standard cylindrical prep is a 2-1/8 inch cross bore on a 2-3/8 or 2-3/4 backset, and both EM-2 sizes measure 9 x 4 or 9 x 4-1/4 across the face, so the plate footprint is larger than that bore in both directions. Match the plate size to the backset the door was drilled at, and the bore lands under the plate. Where the old hardware was mortised rather than bored, measure the pocket itself before ordering, since a mortise pocket can run longer than a bore.
8) Is the Don-Jo EM-2 scar plate suitable for a high traffic commercial building?
It is built for commercial use, which is how it is rated, and it is specified on offices, schools, healthcare, retail, warehouse, government, and multi-tenant buildings with commercial doors. For a property manager standardizing a floor of openings, the practical point is that the same two sizes and two finishes repeat across every door, so you can buy one configuration in quantity rather than measuring each opening separately, provided the doors were prepped alike.
