Don-Jo WP4S Frame Frog Wire Pathway for Electrified Door Hardware in Hollow Metal Frames

Don-Jo WP4S Frame Frog Wire Pathway for Electrified Door Hardware in Hollow Metal Frames

(No reviews yet) Write a Review

Model: WP4S-001

In Stock (leaves warehouse same day if ordered before 3pm ET)

$79.76
$63.62
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo WP4S Frame Frog Wire Pathway for Electrified Door Hardware in Hollow Metal Frames

The Don-Jo WP4S Frame Frog Wire Pathway is a compact, patented wiring accessory engineered specifically for electrified door hardware installations in hollow metal door frames. As the newer and smaller successor to the original WP4L-001 backbox, the WP4S is designed for use with 1/2" PVC conduit and standard 90-degree sweeps within the doorframe, providing a clean and organized pathway for fish tape and wiring. Its unique patented shape forces fish tape down a chosen path with the flick of a finger, making complex wire routing straightforward and efficient for commercial installers.

Key Features

  • Patented Fish Tape Guidance: Unique patented shape forces fish tape down a chosen path with the flick of a finger, dramatically simplifying wire routing in hollow metal door frames.
  • Four Connection Ports: Four connection ports allow for multiple pathway arrangements, providing flexibility for a wide range of electrified door hardware configurations.
  • Funnel-Shaped Ports: Funnel-shaped ports smoothly direct fish tape into electrical conduit, reducing snags and improving installation efficiency.
  • Port Dividers: Integrated dividers separate the ports for ease in steering fish tape into the desired port, keeping wiring organized and controlled.
  • Removable Port Caps: Easily removable port caps allow for straightforward conduit attachment, adapting to the specific needs of each installation.
  • Removable Knockouts: Easily removable knockouts provide clearance for door hardware prep welded to the frame, ensuring compatibility with pre-prepped hollow metal frames.
  • TB-215 Tab Mounting System: Comes standard with TB-215 tabs for easy and secure mounting within the doorframe.
  • Conduit Compatibility: Designed for use with 1/2" PVC conduit and standard 90-degree sweeps within the doorframe for a reliable, code-friendly installation.
  • Compact Successor Design: The newer and smaller version of the original WP4L-001 backbox, specifically designed for electrified door hardware in hollow metal door frames.

Technical Specifications

  • Product Group: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Commercial/Residential: Commercial
  • Product Category: Parts and Accessories

Typical Applications

  • Electrified Door Hardware Installations in Hollow Metal Frames
  • Commercial Office Buildings with Access Control Systems
  • Educational Facilities Requiring Electrified Locking Hardware
  • Healthcare Institutions with Controlled Access Doors
  • Government and Municipal Buildings with Security Door Hardware
  • Retail and Industrial Facilities with Electrified Exit Devices
  • Multi-Tenant Residential and Mixed-Use Properties

Why Don-Jo WP4S?

Don-Jo's WP4S Frame Frog Wire Pathway reflects a commitment to practical, installer-focused design with its patented fish tape guidance system, four-port configuration, and TB-215 tab mounting — all engineered to simplify electrified door hardware wiring in commercial hollow metal frames. The compact form factor and removable knockouts make it a versatile solution for professionals who demand reliable, efficient wire management on every job.

Manufacturer Resources

DON-JO FrameFrog Prep Kit

Product Specs

Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Frame Frog Wire Pathway
Commercial/Residential:
Commercial
Product Category:
Parts and Accessories
Department:
Door Hardware

Don-Jo WP4S-001 – Frequently Asked Questions

1) What is a Don-Jo WP4S Frame Frog and what does it actually do in the frame?
The WP4S Frame Frog is a wire pathway box that mounts inside a hollow metal door frame to route wiring for electrified door hardware. Its patented shape steers fish tape down whichever of four ports you choose with a flick of a finger, and funnel-shaped ports feed the tape into conduit instead of letting it snag. Internal dividers separate the ports so you can aim the tape at the one you want. It is not a junction box for splices or a power supply, it is the guide that gets the wire from A to B inside the frame.
2) Will the WP4S Frame Frog fit a hollow metal frame that is already prepped and welded for door hardware?
Yes. The WP4S has removable knockouts specifically to clear hardware prep welded to the frame, so it drops into pre-prepped hollow metal frames rather than fighting the reinforcement. It is designed for hollow metal frames, so it is not the part for a wood or aluminum frame.
3) How does the Don-Jo WP4S mount inside the frame, and does it come with the mounting hardware?
Mounting is by tab. The WP4S ships standard with TB-215 tabs, which secure it inside the doorframe, so you are not sourcing a separate bracket to hang it. You still supply the 1/2 inch PVC conduit and sweeps for the runs themselves.
4) What is the difference between the Don-Jo WP4S and the older WP4L-001 backbox?
The WP4S is the newer, smaller version of the original WP4L-001 backbox. Both are Frame Frog wire pathways for electrified door hardware, but the WP4S is the compact form built for hollow metal door frames, which is what you want when frame depth or existing hardware prep leaves you short on room.
5) Why use a four-port wire pathway instead of just fishing wire through the frame?
Four ports let you build multiple pathway arrangements out of one box, so a frame carrying an electric strike, a door position switch and a power transfer can be routed and kept separate rather than pulled blind through the frame cavity. The dividers hold the runs apart and the funnels aim the fish tape at the port you want, which is the difference between a ten minute pull and an afternoon of retries on an access control rough-in.
6) Is the Don-Jo WP4S rated for commercial access control work or is it a residential part?
Commercial. Don-Jo classes the WP4S as commercial door hardware, and the applications it is built for are access controlled openings in office buildings, schools, healthcare, government and municipal buildings, retail and industrial facilities, and multi-tenant residential.
7) How many models of the Frame Frog WP4S are there, and do I have to pick a finish or a hand?
One model, WP4S-001. There is no handing and no finish choice to make, since the pathway lives inside the frame where nothing shows. All you need to specify alongside it is your 1/2 inch PVC conduit and sweeps.
