DoorBird 423860353 A1061W IP Door Chime, Polycarbonate, White, Wi-Fi / LAN Connection (PoE Capable) with Story-Call Option

DoorBird 423860353 A1061W IP Door Chime, Polycarbonate, White, Wi-Fi / LAN Connection (PoE Capable) with Story-Call Option

(No reviews yet) Write a Review

Model: 423860353
Selected Door Chime is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$337.97
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

DoorBird A1061W IP Door Chime, Polycarbonate, White, Wi-Fi / LAN Connection (PoE Capable) with Story-Call Option

The DoorBird A1061W IP Door Chime is a versatile, network-based chime designed to pair with any DoorBird video door station. Measuring 125 x 119 x 26 mm (4.92 x 4.68 x 1.02 in, H x W x D) and weighing 200 g, this polycarbonate, UV-resistant, white-finish chime connects via Wi-Fi (2.4 GHz, 802.11 b/g/n) or Ethernet, and can be powered via 15 V DC or Power over Ethernet (PoE 802.3af Mode-A). With support for 50+ ringtones and unlimited range, it works both online and offline, and is configurable worldwide through the DoorBird App.

Key Features

  • Compact Dimensions: 125 x 119 x 26 mm (4.92 x 4.68 x 1.02 in, H x W x D) allows flexible wall or ceiling mounting.
  • Flexible Power Options: Operates on 15 V DC or Power over Ethernet (PoE 802.3af Mode-A) for simplified installation without extra wiring.
  • Dual Connectivity: Connects via Wi-Fi (2.4 GHz, 802.11 b/g/n, internal antenna) or Ethernet/LAN for reliable network integration.
  • Durable Housing: UV-resistant polycarbonate construction in white finish supports long-term indoor performance.
  • Universal DoorBird Compatibility: Works with all DoorBird IP video door stations, supporting an unlimited number of paired door chimes and door stations.
  • Front Door and Story-Call Option: A separate story-call button can be wired via two-wire cable with its own configurable ringtone profile, letting residents distinguish between the main door and apartment door.
  • Online and Offline Operation: Continues functioning over the local network (LAN) even if internet connectivity is temporarily lost.
  • 50+ Ringtones and Unlimited Range: Choose from a wide selection of ringtones with adjustable volume, configurable remotely via the DoorBird App from anywhere in the world.

Technical Specifications

  • Dimensions: 125 x 119 x 26 mm (H x W x D) 4,92 x 4,68 x 1,02 in (H x W x D)
  • Power supply: 15 V DC or Power over Ethernet (PoE 802.3af Mode-A)
  • Operating conditions: 0 to +55°C / 32 to 131°F relative humidity 10% to 85% (non condensing)
  • Wi-Fi: 2.4 GHz, 802.11 b/g/n, internal antenna
  • PoE: IEEE 802.3 af/at
  • Housing: Polycarbonate, UV-resistant
  • Weight: 200 g
  • System requirements:
    • Mobile Device: Newest iOS on iPhone/iPad, newest Android on smartphone/tablet
    • Internet: High-speed landline broadband internet connection, DSL, cable or fiber optic, no socks or proxy server
    • Network: 802.11b/g/n 2.4 GHz or Ethernet network, with DHCP
    • Compatible with all DoorBird IP video door stations

Typical Applications

  • Single-Family Residences
  • Multi-Tenant Residential Properties
  • Commercial Office Buildings
  • Retail Establishments
  • Healthcare Institutions
  • Educational Facilities

Why DoorBird A1061W?

DoorBird A1061W delivers dependable, network-based chime performance backed by UV-resistant polycarbonate construction and flexible Wi-Fi, LAN, or PoE connectivity. Engineered for seamless integration with the full DoorBird ecosystem, it provides consistent audible alerts whether connected online or operating locally over LAN, making it a smart addition to any DoorBird-equipped entryway.

Product Specs

Catergory:
Access Control
Subcategory:
Parts and Accessories
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Door Chime
Series:
A1061W
Power Supply:
15 V DC
WiFi:
2.4 GHz, 802.11 b/g/n, external antenna
Weather-proof:
No
Product Dimension:
4,92 x 4,68 x 1,02 in
Department:
Door Hardware

DoorBird 423860353 – Frequently Asked Questions

1) Will the DoorBird A1061W chime work with my DoorBird video door station?
The A1061W IP chime pairs with all DoorBird IP video door stations, and you can run an unlimited number of chimes and door stations together on the same system. That is what makes it workable in a building where one entrance needs to ring in several units, or one unit needs a chime on more than one floor.
2) Can the A1061W door chime be powered over Ethernet, or do I need to run a separate power supply?
Either works. The A1061W runs on 15 V DC or on Power over Ethernet (802.3af Mode-A), so if you are pulling a Cat cable to the mounting location anyway, one run carries power and network and you skip the low-voltage supply. Choose the 15 V DC supply where you are on Wi-Fi and there is no data cable at the spot.
3) Can I mount a DoorBird A1061W chime outside or in an unheated garage or breezeway?
Indoors only. The A1061W is not a weather-proof device, and its stated operating range is 0 to +55 C (32 to 131 F) at 10 to 85 percent relative humidity, non condensing. An unheated space that drops below freezing or a location that sees condensation is outside that window. The UV-resistant polycarbonate housing is about color stability near a window, not exterior exposure.
4) Will the DoorBird chime still ring if the building internet goes down?
Yes. The A1061W keeps working over the local network if internet connectivity is lost, so the door station still rings the chime on-site. What you lose during an outage is the remote side: app configuration and ringtone changes are done through the DoorBird App over a broadband connection.
5) How do I make an apartment door button ring differently from the building entrance on a DoorBird chime?
That is the story-call option on the A1061W. A separate story-call button wires to the chime with two-wire cable and gets its own configurable ringtone profile, so the tenant hears one tone for the main entrance door station and a different one for someone standing at their apartment door. Useful in multi-tenant residential and in offices with a suite door behind a lobby entrance.
6) What network does the DoorBird A1061W need, and will it join a 5 GHz Wi-Fi?
The A1061W is a 2.4 GHz device: 802.11 b/g/n, or wired Ethernet. It will not associate with a 5 GHz-only SSID, so on a dual-band network the 2.4 GHz band has to be broadcasting. DHCP is required on whichever network segment you put it on. In a building with heavy 2.4 GHz congestion, take the Ethernet path and use PoE.
7) How big is the DoorBird A1061W chime and where can it be mounted?
The chime measures 4.92 x 4.68 x 1.02 inches (125 x 119 x 26 mm) and weighs 200 g. At roughly an inch deep it sits close to the surface, and it can go on a wall or a ceiling, which matters when the only spot with a data drop is above a corridor rather than beside a door.
8) Can I put several DoorBird chimes on different floors of one house or unit?
Yes, and there is no distance limit between them because the A1061W works over the network rather than by radio pairing to the door station. Any number of chimes can be added to the same DoorBird system, so a chime in a basement shop, one in a kitchen, and one on an upper floor all ring off the same door station as long as each has network and power.
9) Is the ringtone and volume on the DoorBird A1061W adjustable, and can a property manager change it remotely?
There are 50-plus ringtones with adjustable volume, all set from the DoorBird App, and the app manages the device from anywhere in the world. For a manager holding a portfolio, that means a tenant complaint about chime volume or tone gets settled without a site visit. The app runs on current iOS or Android on a phone or tablet.
10) What color and material is the DoorBird A1061W chime housing?
White polycarbonate, UV-resistant, in a single finish. There is one orderable configuration of the A1061W, so there is no finish or size decision to make on the order, which is what you want when standardizing a chime across dozens of units in a building.
