DoorBird 423869998 D2101KV IP Video Door Station with RFID Reader and Keypad, Stainless Steel V2A Brushed

DoorBird 423869998 D2101KV IP Video Door Station with RFID Reader and Keypad, Stainless Steel V2A Brushed

(No reviews yet) Write a Review

Model: 423869998
Selected Video Intercom is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,019.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

DoorBird D2101KV IP Video Door Station with RFID Reader and Keypad, Stainless Steel V2A Brushed

The DoorBird D2101KV IP Video Door Station brings smart entrance control to your home or business, connecting directly to your smartphone so you can see, hear, and speak with visitors from anywhere. Built with a 3 mm (0.12 in) brushed stainless steel V2A front panel, this unit features a 720p HDTV camera with an ultra-wide angle 180" hemispheric lens, 2-way audio, RFID reader, illuminated keypad, and a 4D motion sensor. Power is supplied via 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A), and the unit can be flush- or surface-mounted with housings sold separately.

Key Features

  • Compact Dimensions: Measures 351.5 x 131 x 49.6 mm (13.84 x 5.16 x 1.95 in, H x W x D) with a weight of 1510 g for a sleek, low-profile entrance installation.
  • Flexible Power Options: Operates on 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A) for simplified wiring via LAN connection.
  • Durable Stainless Steel Construction: 3 mm (0.12 in) brushed stainless steel V2A front panel provides a weatherproof, corrosion-resistant housing suited for exterior use.
  • Flush or Surface Mounting: Supports both flush- and surface-mount installation styles, with mounting housings sold separately for installation flexibility.
  • HDTV Camera with Ultra-Wide Lens: High-end 720p dynamic camera (VGA-HDTV) paired with a 180" (D), 140" (H), 100" (V) hemispheric lens delivers a straightened, IR-capable ultra-wide field of view.
  • Night Vision: Automatic IR-cut filter with light sensor and 12 Infrared LEDs (850 nm) ensures clear visibility in low-light and nighttime conditions.
  • RFID Access with Configurable Range: RFID reader operates on a 125 KH frequency with a detection range of 1-10 m (3.3-32.9 ft), configurable in 1 m (3.3 ft) steps depending on environment.
  • 4D Motion Sensor and Automation: Enables scheduled automation such as switching external lighting during set hours and automatic door or gate opening when returning home.

Certifications & Compliance

  • Weather-Proof Rated Construction
  • Operating Conditions: -25 to +55°C / -13 to 131°F, humidity 10 to 85% RH (non-condensing)

Technical Specifications

  • Front panel: 3 mm (0.12 in) Available in brushed stainless steel V2A / V4A and V2A with bronze and titanium finish,
  • Mounting type: Flush- or surface-mounted, mounting housing sold separately
  • Call button: Illuminated
  • Power supply: 15 V DC (max. 15 W) or power over Ethernet (PoE 802.3af Mode-A)
  • Weight: 1510 g
  • Dimensions: 351,5 x 131 x 49,6 mm (H x W x D) 13.84 x 5.16 x 1.95 in (H x W x D)
  • Operating conditions: -25 to +55°C / -13 to 131°F humidity 10 to 85 % RH (non-condensing)

Typical Applications

  • Commercial Office Buildings
  • Healthcare Institutions
  • Retail Establishments
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Medical Offices

Why DoorBird D2101KV?

DoorBird D2101KV delivers professional-grade entrance security with a weatherproof, brushed stainless steel V2A housing engineered to withstand operating conditions from -25 to +55°C. With an HDTV camera, ultra-wide hemispheric lens, RFID access, and 4D motion sensing, this video door station brings real-time audio and video communication to smartphones, tablets, and SIP-enabled devices for dependable performance in demanding installations.

Product Specs

Catergory:
Access Control
Subcategory:
Intercoms
Product Group:
Electronic Access Controls
Product Subgroup:
Intercoms
Product Type:
Video Intercom
Series:
D2101KV
Call Button:
Illuminated
Power Supply:
15 V DC
Weather-proof:
Yes
Camera:
HDTV 720p, dynamic (VGA – HDTV)
Lens:
High-end ultra wide-angle hemispheric lens 180° (D), 140° (H), 100° (V), straightened, IR-capable
Night vision:
Yes, light sensor, automatic IR-cut filter, 12 Infrared LEDs (850 nm)
Range:
1 - 10 m (3.3 - 32.9 ft), depends on environment, configurable in 1 m (3.3 ft) steps
Frequency:
125 KH
Front Panel:
3 mm (0.12 in)
Product Dimension:
13.84 x 5.16 x 1.95 in (H x W x D)
Mounting Method:
Flush Mounted or Surface Mounted
Department:
Door Hardware

DoorBird 423869998 – Frequently Asked Questions

1) Can the DoorBird D2101KV run on PoE, or does it need a separate power supply at the door?
Both work. The D2101KV takes 15 V DC (max 15 W) or Power over Ethernet, PoE 802.3af Mode-A, over the same LAN cable that carries the video. On a commercial job a single Cat cable back to a PoE switch is usually the cleaner pull, since there is no low-voltage transformer to find room for at the entrance. If you are feeding it 15 V DC instead, that is a dedicated supply, not a doorbell transformer.
2) Does the DoorBird D2101KV come with a mounting housing, or do I have to order that separately?
The housing is a separate order. The D2101KV mounts flush or on the surface, and the mounting housing for either method is sold separately, so decide which one the opening needs before you order. Flush means cutting the wall or post for a back box; surface mount sits proud and is what you use on masonry, glass surrounds, and existing brick where you cannot open up the wall. Only the front panel unit and its electronics come in the box.
3) How much wall space do I need to cut in for a DoorBird D2101KV door station?
The unit measures 13.84 x 5.16 x 1.95 inches (H x W x D), 351.5 x 131 x 49.6 mm. That depth of just under 2 inches is what usually decides the job: a flush install needs a back box cavity behind the panel, so a narrow gate post or a thin partition beside the door may not take it and pushes you to surface mount instead.
4) Will a DoorBird D2101KV survive outdoors through a cold winter?
It is built for exterior use. The front panel is 3 mm brushed stainless steel V2A, weather-proof rated, and the station is specified to operate from -25 to +55 C (-13 to 131 F) at 10 to 85 percent RH non-condensing. That range covers northern US and Canadian winters. V2A is the standard 304-type stainless; in coastal or de-icing-salt environments the V4A panel version is the one to specify.
5) How many tenants can call in on a DoorBird D2101KV, and is it right for a multi-tenant building?
This configuration is a single call button unit, one unit with one illuminated call button. That makes it a one-destination station: a single-tenant entrance, an office front door, a service gate, or the staff entrance of a larger building. For a multi-tenant lobby where every apartment needs its own button, a one-button station is the wrong part, and the keypad is how you would let residents in on a code rather than a per-unit call.
6) What RFID cards work with the DoorBird D2101KV reader?
The reader runs at 125 KHz, so it reads low-frequency proximity credentials, not 13.56 MHz smart cards. If your building is already carrying 13.56 MHz cards, they will not read here. Read range is configurable from 1 to 10 m (3.3 to 32.9 ft) in 1 m (3.3 ft) steps, and actual range depends on the install environment, so a metal-heavy entrance surround will pull it in.
7) Do I need a keyfob to get in with the D2101KV, or can visitors and staff use a code?
Two ways in without a phone. The D2101KV carries both an illuminated keypad for PIN entry and a 125 KHz RFID reader, so cleaners, contractors, and delivery people can be given a code while regular staff carry a credential. The keypad being illuminated matters on an unlit entrance where someone is punching a code after dark.
8) Will the DoorBird D2101KV camera show a whole doorway, or just a face?
The camera is a 720p HDTV dynamic unit behind a hemispheric wide-angle lens covering 180 degrees diagonal, 140 horizontal, and 100 vertical, with the image straightened rather than left fisheyed. That horizontal spread takes in the full width of a doorway plus what is standing off to the side of it, which is what you want when someone steps out of frame after ringing. The 100 degree vertical field also picks up a package left on the ground close to the wall.
9) Can you see anything on a DoorBird D2101KV at night without a porch light?
Yes, it runs its own IR. A light sensor with an automatic IR-cut filter switches the camera over after dark, and 12 infrared LEDs at 850 nm light the scene, with the lens itself IR-capable. No exterior fixture is required for the camera to see, though 850 nm LEDs produce a faint visible red glow at the panel, which some clients notice on a residential front door.
10) Does the DoorBird D2101KV work with SIP phone systems, or only the app?
Both. Audio and video go to smartphones and tablets, and the station also talks to SIP-enabled devices, which is what lets it land on an existing desk phone system at a front office or clinic reception instead of forcing every staff member onto a mobile app. Connection to the network is over LAN, the same cable that can carry the PoE feed.
11) Can the D2101KV trigger a gate or turn on lights on its own schedule?
It has a 4D motion sensor tied to automation, so it can switch exterior lighting during set hours and open a door or gate automatically on arrival, rather than only reacting to someone pressing the button. On a property with a driveway gate, that motion trigger is often the reason to pick this station over a plain call-and-answer intercom.
12) What finishes does the D2101KV front panel come in besides brushed stainless?
The panel is offered in brushed stainless steel V2A, V4A, and V2A with bronze or titanium finish. This particular build is the brushed V2A. Where a property is standardizing an entrance package on a dark or warm metal, the bronze and titanium panels are how you match without changing hardware platform; V4A is the choice where corrosion exposure is the driver rather than looks.
