The QDB100 line of Grade 1 deadbolts provides strength, durability, and reliability for high security applications. We designed the QDB100 series with solid forged housing for added strength and performance life, and then added anti-drill and saw-resistant features to deliver even greater security for a long-lasting, reliable deadbolt solution.

Features

• Built for durability and security

  • Solid forged housing, full 1” steel throw bolt with hardened steel roller pin for saw resistance, and anti-drill design with two ball bearings for drill resistance on non-IC cylinders are just a few of the heavy-duty security features we built into our QDB100 series.
• Backed by a leading warranty

  • The QDB100 series comes with lifetime mechanical and three-year finish warranties.
• Easy to retrofit

  • Choose deadbolts with a SFIC option or keep your existing small format cores and use them with QDB100 series products. Standard door prep makes retrofit quick and easy.
• Simple to install

  • Compartmentalized packaging makes QDB100 deadbolts easier to install.
• Additional security features

  • Depending on your application, available options like hurricane compliance can add an additional layer of reliability and security
• Short lead time

  • Our QDB100 series deadbolts are available for immediate shipment

Certifications:

• ANSI/BHMA A156.5 Series—Grade 1
• ANSI A117.1 Accessibility Code (ADA compliant)
• UL/cUL listed (3 hour) for “A” label single door applications (4’ by 8’) UL10C/UBC 7-2 (1997) positive pressure rated
• UL10B pressure rated
• California State Reference Code (formerly Title 19 – Fire Marshal) Hurricane Compliant – Miami DADA N.O.A.
• ADA compliant thumb turn

Product Specifications:

• Exposed trim: solid forged brass, plated to match finish designation
• Door range: 1 3/8” (35mm) – 2” (51mm); service part 8Q00082 spacer rings required for 1 3/8” doors
• Backset: 2 3/4” (70mm) square standard; 2 3/8” (60mm) available
• Strike: standard deadbolt strike 1 1/8” (32mm) x 2 3/4” (70mm); other options available Door prep: 2 1/8” (54mm)
  diameter cross bore
• Latch bolt: full 1”(25.4mm) throw with hardened steel roller
• Latch faceplate: 1 1/8” (29mm) x 2 1/4” (57mm) standard

Keying:

• 6-pin non-IC brass cylinders
• 6- or 7-pin SFIC option available
• Two keys per lockset
• Keying options include: master keying, grand master keying, construction keying Keyway options include: BF-SFIC “F”, KW-Kwikset, WE-Weiser, SC-Schlage, GA-Yale, LA-Sargent, LC-Less Cylinder

Recommended applications
