Dortronics 5215-SPB Series Exit Release 1-1/2" Square Illuminated Push Button, Singe Gang Plate

Dortronics 5215-SPB Series Exit Release 1-1/2" Square Illuminated Push Button, Singe Gang Plate

The 5215-SPB series push button assemblies provide a clearly visible means of actuating electric locking release. These easy to operate, request-to exit controls are ideal for use in any facility with access controlled entry/exit.

Features:

• Standard Single Gang Mounting: These push button switches are supplied with a brushed stainless steel plate for mounting on a standard single gang 2" x 4" electrical box. The switch contact block requires only 2-1/4" depth within the mounting cavity.
• Illuminated Square Actuator Button: The 1-1/2" x 1-1/2" illuminated button can be easily recognized when powered. The lamp is rated at 28 VDC for long life.
• LED Status Indicator: A red LED is available, as an option, to be mounted above the square actuator button. This can be utilized to provide indication of door lock status.
• Heavy Duty Contacts: The SPDT contacts on the momentary action switch are rated for 10 amps at 125/250 VAC. Color coded, 7" leads are easily connected to field wiring.
• Optional Text Graphic: The illuminated actuator button is also available with "Exit" text. The block lettering in black is clearly visible against the green background when the back-light is on or off.
• NFPA/BOCA Code Compliance: An optional FT-timer is available for use with R-E-X motion detector applications requiring compliance with NFPA and BOCA codes. These units provide a fixed 30 second unlock time whenever the push button actuator is depressed and then released.
• Economical Switch Control: This low-cost push button control will meet the requirements of most access control systems for request-to-exit devices. The illuminated square button is highly visible recognized exit device.

Specifications:

• Physical Size:
• Switch Plate: Single gang 2-3/4” wide x 4-1/2” high x 2-1/4” deep (including contact block)
• Push Button: Illuminated 1-1/2” x 1-1/2” square momentary action
• Optional LED: Standard red diffused T-1-3/4 LED with twin leads.
• Electrical:
• Contacts: Momentary SPDT action (P15) rated 10 amps @ 125/250 VAC.
• Lamp: Incandescent 28 VDC maximum.
• LED: Red LED - 28 VDC maximum.

Resources

5215 SQUARE BUTTON CUTSHEET
