Eaton E47CMS42 E47 Precision L...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$83.94
$33.94
Eaton E47CMS42 E47 Precision Limit Switch, Basic, Extended Roller Lever, Mineral Filled Phenolic enclosure, 20A max AC, 20A max DC, SPDT, 20A at 125Vac / 20A at 14Vdc, Screw Terminals

Eaton E47CMS42 E47 Precision Limit Switch, Basic, Extended Roller Lever, Mineral Filled Phenolic enclosure, 20A max AC, 20A max DC, SPDT, 20A at 125Vac / 20A at 14Vdc, Screw Terminals

(No reviews yet) Write a Review

Model: E47CMS42
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$83.94
$33.94
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
E47 Precision Limit Switch, Basic, Extended Roller Lever, Mineral Filled Phenolic enclosure, 20A max AC, 20A max DC, SPDT, 20A at 125Vac / 20A at 14Vdc, Screw Terminals

Manufacturer Resources

Product Specs

Catalog Notes:
Bottom facing M4 x 0.7 (8-32) terminal screws with cup washers will accept 22 -12 AWG (2.5 sq. mm maximum)
Certifications:
UL Listed
Compliances:
CE Marked
Connection:
Screw terminal
Contact Configuration:
SPDT
Contact Rating:
20A at 125Vac / 20A at 14Vdc
Enclosure Material:
Mineral filled phenolic
Environmental Rating:
NEMA 1
Maximum Ac Current:
20 A
Maximum Dc Current:
20 A
Operating Temperature Max:
176 °F
Operating Temperature Min:
-13 °F
Product Height:
1.5 in
Product Length Depth:
2 in
Product Weight:
.08 lb
Product Width:
1 in
Switch Type:
Extended roller lever
Type:
E47
Product Group:
Electrical
!
