Eaton 0-10V LED Dimmer Switch, Single-Pole/Three-Way, 120/277V

Eaton 0-10V LED Dimmer Switch, Single-Pole/Three-Way, 120/277V

(No reviews yet) Write a Review

Model: SF10P-W
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$68.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 0-10V LED Dimmer Switch, Single-Pole/Three-Way, 120/277V

The Eaton 0-10V LED Dimmer Switch delivers smooth, low-voltage dimming control for LED and fluorescent lighting circuits without requiring a neutral conductor. Built for 120/277 Vac, 60Hz service, this single-pole/three-way dimmer supports #14 – 12 AWG wiring via back and side connections or wire leads, and is rated for 1200/1660W maximum load. Housed in durable polycarbonate and cULus Listed, it is engineered for reliable, code-compliant performance in commercial and residential lighting applications.

Key Features

  • Dimming Control: 0-10V dimming protocol compatible with LED and fluorescent luminaires for smooth, low-voltage lighting control.
  • No Neutral Required: Simplifies retrofit and new-construction wiring where a neutral conductor is not available at the switch location.
  • Wiring Method: Accepts #14 – 12 AWG conductors via back and side wire connections or wire leads for flexible installation.
  • Power Rating: Rated for 1200/1660W maximum connected load at 120/277 Vac, 60Hz.
  • Configuration: Single-pole and three-way switching with maintained closure for standard multi-location control.
  • Durable Construction: Polycarbonate housing provides impact resistance and long-term durability.
  • Single-Phase Operation: Designed for single-phase, 60Hz electrical systems.

Certifications & Compliance

  • cULus Listed

Technical Specifications

  • Mounting Method: Flush
  • Voltage Rating: 120/277 V
  • Product Height: 4.3 in
  • Product Width: 2 in
  • Product Length/Depth: 2 in
  • Phase: Single-phase
  • Frequency Rating: 60 Hz
  • Power Consumption: 1200 W
  • Number of Ways: Three-way
  • Closure Type: Maintained
  • Number of Poles: Single-pole, Three-way
  • Connection Type: Back
  • Wiring Method: Back and side, wire leads
  • Material: Polycarbonate
  • Special Features: No neutral required

Typical Applications

  • Commercial and Residential Lighting Control
  • LED and Fluorescent Dimming Circuits
  • Single-Pole and Three-Way Switching Installations
  • New Construction and Retrofit Wiring
  • Energy-Efficient Lighting Upgrades

Why Eaton?

Eaton engineers its 0-10V dimmer switches with durable polycarbonate housings and cULus Listed performance to meet the demands of professional electrical installations. The no-neutral-required design and flexible back-and-side wiring options make this dimmer a practical choice for both new construction and retrofit lighting control, backed by Eaton's reputation for dependable electrical components.

Manufacturer Resources

Product Specs

Mounting Method:
Flush
Voltage Rating:
120/277V
Product Height:
4.3 in
Phase:
Single-phase
Frequency Rating:
60 Hz
Product Wattage:
1200 W
Number of ways:
Three-way
Closure Type:
Maintained
Certifications:
cULus Listed
Number Of Poles:
Single-pole, Three-way
Product Width:
2 in
Connection Type:
Back and Side Wire
Product Length/Depth:
2 in
Wiring Method:
Back and side, wire leads
Product Material:
Polycarbonate
Special Features:
No neutral required
Product Type:
Dimmer Switch
Department:
Electrical
Listing:
cULus
Product Group:
Wiring Devices
Product Subgroup:
Dimmer Switches
Product Length:
2 in
Product Weight:
0.233 lb

Eaton SF10P-W – Frequently Asked Questions

1) Will the Eaton SF10P dimmer work if there's no neutral wire in the switch box?
Yes. The Eaton SF10P 0-10V dimmer is a no-neutral-required device, so it installs in older boxes where only the switch legs and ground are present. That is the main reason it gets specced on retrofits, where pulling a neutral back to the switch location means opening walls.
2) Can I use the Eaton SF10P on a 277V commercial lighting circuit?
Yes. The SF10P 0-10V dimmer is rated 120/277 Vac, 60 Hz, single-phase, so it covers both residential 120V branch circuits and 277V commercial lighting without switching to a different part number. Max connected load is 1200W at 120V and 1660W at 277V.
3) Does this Eaton dimmer work in a three-way setup with a switch at each end of the hall?
It does. The SF10P is a single-pole/three-way device with maintained closure, so one dimmer plus a standard three-way switch at the other location gives you multi-location control. Use it as single-pole with no changes if you only have one control point.
4) Will the Eaton SF10P dim my LED fixtures, or do the drivers need to support something specific?
This is a 0-10V dimmer, not a line-voltage forward/reverse phase dimmer. Your LED drivers or fluorescent ballasts must have 0-10V (low-voltage) dimming inputs, meaning a violet and gray control pair run back to the switch. If your fixtures are phase-dimmable only, this is the wrong control and you need a standard LED dimmer instead.
5) What wire size does the Eaton SF10P accept, and how does it terminate?
It takes #14 to #12 AWG conductors, with back and side wire connections or wire leads. That gives you the choice of backwiring a tight box or landing on side screws where you're pigtailing multiple devices in a gang.
6) What's the maximum lighting load I can put on one Eaton SF10P dimmer?
1200W at 120V and 1660W at 277V maximum connected load. On LED runs you'll usually hit the driver-count or 0-10V sink-current limit before you hit the wattage ceiling, so size the circuit on both.
7) Will the Eaton SF10P fit a standard single-gang box with a decorator plate?
It's a flush-mount device measuring 4.3 x 2 x 2 inches, so it lands in a standard single-gang opening. The 2 inch depth figure is worth checking against shallow or old-work boxes that already have several conductors in them.
8) What colors does the Eaton SF10P 0-10V dimmer come in?
Two: white (SF10P-W) and ivory (SF10P-V). Both are the same 120/277V 0-10V device, so a property manager standardizing across a building can match existing device color without changing the electrical spec.
9) Is the Eaton SF10P body plastic or metal, and will it hold up in a high-traffic building?
The housing is polycarbonate, chosen for impact resistance in commercial and residential installs. For corridors, classrooms, and multi-family common areas that means it takes knocks without cracking the way a brittle housing would.
