Eaton 30.5 mm Heavy-Duty Watertight/Oiltight Enclosure, NEMA 4X Stainless Steel
Eaton's 30.5 mm Heavy-Duty Watertight/Oiltight Enclosure, Series 10250T, is built from 14 gauge, Type 304 Stainless Steel to withstand harsh washdown, outdoor, and corrosive environments. Rated NEMA 4, 4X, 12, this surface-mounted enclosure houses up to 2 pilot devices and carries CE Marking and CSA Certification for demanding industrial control applications.
Key Features
- Heavy-Duty Watertight/Oiltight Design: Sized for 30.5 mm pilot devices, delivering a rugged watertight and oiltight seal for operator interface hardware.
- Durable Construction: 14 gauge, Type 304 Stainless Steel construction resists corrosion in washdown, food-processing, and outdoor installations.
- NEMA 4, 4X, 12 Rated: Protects internal components against water ingress, corrosion, and dust for wet, washdown, and dusty locations.
- Surface Mounting: Configured for straightforward surface mount installation on panels and equipment.
- Compact Dimensions: 3.8 in product width, 8.3 in product length/depth, and 5.1 in product height fit tight panel and machine layouts.
- 2-Element Capacity: Accommodates up to 2 pilot devices, pushbuttons, or indicators.
- Stainless Steel Bus Material: Internal bus components are stainless steel for long-term corrosion resistance.
- 1-Year Warranty: Backed by Eaton's standard 1-year warranty for added peace of mind.
Certifications & Compliance
- NEMA 4, 4X, 12 Rated
- CE Marked
- CSA Certified
Technical Specifications
- Series: 10250T
- Type: 30.5 mm, Heavy-Duty Watertight/Oiltight
- Product Width: 3.8 in
- Product Length/Depth: 8.3 in
- Product Height: 5.1 in
- Mounting Method: Surface
- Number of elements: 2
- Bus Material: Stainless steel
- Rating: NEMA 4X
- Warranty: 1 year
Typical Applications
- Industrial Control Panels and Machine Enclosures
- Washdown and Food-Processing Environments
- Outdoor Electrical and Equipment Installations
- Wet, Corrosive, and Dusty Location Wiring
- Operator Interface and Pilot Device Housings
Why Eaton?
Eaton's 10250T Series enclosures pair Type 304 stainless steel construction with NEMA 4, 4X, 12 protection to deliver reliable, code-compliant performance in demanding industrial and washdown environments. Backed by CE Marking, CSA Certification, and a 1-year warranty, this heavy-duty watertight/oiltight enclosure is engineered for long-term durability in the field.
Manufacturer Resources
Product Specs
- Product Width:
- 3.8 in
- Rating:
- NEMA 4X
- Mounting Method:
- Surface
- Product Length/Depth:
- 8.3 in
- Product Height:
- 5.1 in
- Product Type:
- Enclosure
- Number of elements:
- 2
- Warranty:
- 1 year
- Catalog Notes:
- 14 gauge, Type 304 Stainless Steel
- Product category:
- Enclosure
- Series:
- 10250T
- Bus material:
- Stainless steel
- Compliances:
- CE Marked
- Certifications:
- CSA Certified
- Department:
- Electrical
- Product Material:
- Stainless Steel
- Standards:
- NEMA 4X
- Listing:
- CSA Certified
- Configuration:
- Surface Mount
- Product Group:
- Boxes & Enclosures
