Eaton 10250T Series Square Legend Plate for Pushbutton Operators
Model: EAT-P438682
Eaton
Eaton 10250T Pushbutton Legend Plate, Blank Legend, White
The Eaton 10250T Pushbutton Legend Plate is engineered for use with the 10250T series of pushbutton operators and indicating lights, giving control panel builders and maintenance electricians a clean, code-ready way to identify switches and pilot lights on machinery, control stations, and panelboards. This legend plate ships with a blank legend and white lettering color, allowing installers to add custom text or symbols to match specific process, safety, or operational labeling requirements. It features a standard type construction and compact dimensions of 1.6 in product width, 1.7 in product length/depth, and just .1 in product height, so it mounts flush with minimal added depth in crowded enclosures and operator panels. Backed by CE Marking and CSA Certification, plus a 1 year manufacturer warranty, the 10250T legend plate is built to support reliable, professional-grade identification in demanding industrial and commercial control environments.
Key Features
- Compact Dimensions: 1.6 in product width and 1.7 in product length/depth with a low-profile .1 in product height, ideal for tight panel layouts and densely populated control stations.
- Blank Legend: Ships with a blank legend so installers and panel builders can customize labeling to match specific machine functions, safety warnings, or process steps.
- White Lettering Color: White lettering color delivers clear visual contrast against panel backgrounds for fast, accurate identification by operators and technicians.
- Standard Type Construction: Standard-type legend plate design built for dependable, everyday use on control panels and operator stations.
- Compatible with 10250T Series: Purpose-built for use with 10250T series pushbutton operators and indicating lights, simplifying sourcing and replacement.
- 1 Year Warranty: Backed by a 1 year manufacturer warranty, giving contractors and facility teams added confidence in long-term performance.
Certifications & Compliance
- CE Marked
- CSA Certified
Technical Specifications
- Warranty: 1 year
- Department: Electrical
Typical Applications
- Commercial and Industrial Control Panels
- Pushbutton Operator and Indicating Light Identification
- Machine and Equipment Control Stations
- Panelboard and Switchgear Labeling
- New Construction and Panel Retrofit Projects
Why Eaton?
Eaton legend plates are engineered for dependable performance alongside the 10250T series of pushbutton operators and indicating lights, with CE Marking and CSA Certification supporting code-compliant installations across commercial and industrial facilities. The standard-type construction, compact footprint, and clear white lettering color help ensure accurate, durable panel identification for professional electrical work, all backed by a 1 year manufacturer warranty for long-term peace of mind.
Manufacturer Resources
Product Specs
- Product Width:
- 1.6 in
- Used with:
- 10250T series, pushbutton operators and indicating lights
- Product Size:
- 1/2 round
- Product Length/Depth:
- 1.7 in
- Product Height:
- .1 in
- Product Type:
- Legend Plate
- Lettering color:
- White
- Warranty:
- 1 year
- Product category:
- Legend plate
- Series:
- 10250T
- Compliances:
- CE Marked
- Certifications:
- CSA Certified
- Department:
- Electrical
- Product Color:
- White
- Standards:
- CE Marked
- Listing:
- CSA Certified
- Product Group:
- Wiring Devices
