Eaton Arrow Hart Extra Heavy-Duty Hospital Grade Duplex Receptacle, 20A, 125V

Eaton Arrow Hart Extra Heavy-Duty Hospital Grade Duplex Receptacle, 20A, 125V

(No reviews yet) Write a Review

Model: AH8200B

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.49
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Arrow Hart Extra Heavy-Duty Hospital Grade Duplex Receptacle, 125V

The Eaton Arrow Hart Extra Heavy-Duty Hospital Grade Duplex Receptacle is engineered for healthcare and other demanding commercial environments where reliability is non-negotiable. Rated 125V with a #14-10 AWG wire range, this 5-R duplex receptacle features brass contacts, a high-impact nylon face, and a glass-filled nylon base for long-term durability. Designed for flush mounting with back-and-side wiring, it is UL Listed and RoHS Compliant, making it a dependable choice for patient care areas and other critical-use installations.

Key Features

  • Wire Range: Accepts #14-10 AWG conductors for flexible installation.
  • Extra Heavy-Duty Hospital Grade: Built to the demanding performance standards required for healthcare applications.
  • Durable Construction: Brass contacts paired with a high-impact nylon face and glass-filled nylon base for strength and longevity.
  • Voltage Rating: Rated 125V for standard duplex receptacle applications.
  • Configuration: 5-R duplex receptacle with screw-terminal connections.
  • Mounting: Flush mount design wired from the back and side for installer flexibility.
  • Finish: Available in multiple finishes suited to healthcare and institutional interiors.

Certifications & Compliance

  • UL Listed
  • RoHS Compliant

Technical Specifications

  • Warranty: Refer to warranty document.
  • Certifications: UL
  • Product Width: .88 in
  • Product Height: 4.19 in
  • Compliances: RoHS Compliant

Typical Applications

  • Hospitals and Healthcare Facilities
  • Patient Care Area Wiring
  • Commercial and Institutional Electrical Installations
  • Medical Office and Clinical Space Wiring
  • Renovation and New Construction Projects

Why Eaton?

Eaton's Arrow Hart line of hospital grade devices combines brass contacts, high-impact nylon components, and UL Listed, RoHS Compliant construction to deliver dependable performance in healthcare and other critical environments. For electrical professionals specifying devices where consistent, code-compliant performance is essential, this extra heavy-duty duplex receptacle is built to meet that standard.

Variant Specifications

ColorMotor FLASKU
Black15AAH8200B
Black20AAH8300B
White/IvoryStandardAH8300W

Manufacturer Resources

Product Specs

Listing:
UL Listed
Department:
Electrical
Product Type:
Duplex Receptacle
Certifications:
UL
Product Width:
.88 in
Voltage Rating:
125V
Connection Type:
Screw
Warranty:
Refer to warranty document.
Product Height:
4.19 in
Product Group:
Wiring Devices
Product Subgroup:
Receptacles & Outlets

Eaton AH8200B – Frequently Asked Questions

1) What wire size does the Arrow Hart hospital grade receptacle accept, and how is it terminated?
It takes #14 through #10 AWG copper conductors on screw terminals, and it can be wired from the back or the side, so you can either backwire and tighten the screws or wrap the side screws in a crowded box.
2) Which amperage and color options does the Arrow Hart 8200/8300 hospital grade duplex come in?
Three orderable configurations: AH8200B in black at 15A, AH8300B in black at 20A, and AH8300W in white/ivory. All are 125V 5-R duplex devices. Match the amp rating to the branch circuit breaker and conductor size before ordering.
3) Do I need a hospital grade receptacle or will a heavy-duty spec grade one do?
Hospital grade is what patient care areas call for, and that is what the Arrow Hart extra heavy-duty device is built to. For general commercial areas outside patient care, a heavy-duty commercial device like the Bryant 5362B 20A/125V duplex or the Pass & Seymour 26352W specification grade decorator duplex covers the same 20A 125V duty without the hospital grade construction.
4) What is the closest equivalent to the Arrow Hart AH8300B if hospital grade is not required for the circuit?
For a 20A 125V duplex where hospital grade is not required, the Bryant 5362B is a heavy-duty 20A/125V duplex receptacle, and the Bryant 5362BI is the same 20A/125V heavy-duty duplex in an alternate color. The Arrow Hart AH8300B is an extra heavy-duty hospital grade device rated 125V with brass contacts, a high-impact nylon face and a glass-filled nylon base, UL Listed and RoHS compliant. Hospital grade carries additional ground-retention and assembly requirements that the heavy-duty Bryant devices are not described as meeting, so use the Arrow Hart in patient care areas.
5) Do I need a hospital grade GFCI instead of the Arrow Hart AH8300W in a wet patient care location?
Where GFCI protection is required at the device, the Pass & Seymour 2097HGI is a hospital grade 20A duplex self-test GFCI receptacle in ivory. The Arrow Hart AH8300W is a straight hospital grade duplex rated 125V with screw terminals and back-and-side wiring, with no GFCI protection built in, so it relies on upstream protection if the location calls for it. Choose the 2097HGI when the device itself must provide ground-fault protection and self-test.
6) Will the Arrow Hart hospital grade duplex work in a hazardous or explosionproof area such as a lab or generator room?
No. For classified hazardous areas the Appleton FSQC Series is an interlocked explosionproof receptacle and the Appleton U-Line ECS is a factory-sealed 15 and 20 amp 3-pole plug and receptacle set, both built for that duty. The Arrow Hart AH8300B is a flush-mount hospital grade duplex rated 125V, UL Listed and RoHS compliant, intended for patient care areas and general commercial and institutional wiring rather than classified locations.
7) Will this Arrow Hart receptacle fit a standard single-gang wall plate and box?
The device body measures 4.19 in high by .88 in wide, which is the standard duplex strap footprint, so it takes a normal single-gang duplex wall plate and mounts flush in a standard device box. Wall plates are a separate order.
8) Is this receptacle tamper resistant for a pediatric or waiting area?
No tamper-resistant shutters on this Arrow Hart device. If TR is required by the area you are wiring, the Pass and Seymour 3232TRW Trademaster tamper-resistant duplex is a tamper-resistant option in white.
9) Can I use the Arrow Hart 8300 on a 277V or locking-plug circuit?
No. It is rated 125V with a NEMA 5 style straight-blade duplex face, so it is for standard 125V branch circuits only. For 277V motor-duty work look at the Bryant 430R9W 4750DR 2-pole 3-wire 277V receptacle, and for a twist-lock connection the Bryant 70520FR flanged locking receptacle or the Pass and Seymour Turnlok 30A single receptacle.
10) Is a tamper-resistant receptacle available instead of the Arrow Hart AH8200B for pediatric or day-care rooms?
The Pass & Seymour 3232TRW Trademaster is a tamper-resistant duplex receptacle in white, which addresses code requirements for tamper-resistant devices in areas serving children. The Arrow Hart AH8200B is an extra heavy-duty hospital grade duplex rated 125V and is not described as tamper resistant. Many pediatric and patient rooms require both attributes, so confirm the room classification before substituting one for the other.
11) What is the difference between the Arrow Hart hospital grade duplex and a spec grade decorator receptacle like the P&S 26352W?
The Pass & Seymour 26352W is a 20A 125V heavy-duty specification grade decorator duplex in white, which uses a rectangular decorator opening and takes a decorator-style wallplate. The Arrow Hart AH8300W is an extra heavy-duty hospital grade 5-R duplex with a standard duplex face, screw terminals and back-and-side wiring, UL Listed and RoHS compliant. If a corridor or office is being matched to existing decorator plates, the 26352W keeps the face style consistent; patient care circuits should stay on the hospital grade device.
12) Can I use a locking or twist-lock receptacle in place of the Arrow Hart AH8300B for equipment that must not unplug?
For a cord that must not pull free, locking devices are a different family: the Bryant 70520FR is a 7 Series NEMA flanged locking receptacle and the Pass & Seymour Turnlok is a 30A non-NEMA single receptacle. Both require a matching locking plug and will not accept the standard straight-blade cord caps that the Arrow Hart 5-R duplex serves. Keep the Arrow Hart hospital grade duplex for general 125V equipment and add a locking device only where the equipment ships with a twist-lock cord.
13) Is the Bryant 430R9W a substitute for the Arrow Hart hospital grade duplex on a 277V circuit?
No. The Bryant 430R9W is a 4750DR 2-pole 3-wire 277V motor-duty receptacle, intended for motor loads at 277V. The Arrow Hart hospital grade duplex is rated 125V and accepts #14-10 AWG conductors on screw terminals. The two are not interchangeable in either direction because the voltage and the intended load differ.
14) We standardize on white devices across the building. Can I get this hospital grade duplex in something other than black?
Yes. Alongside the black AH8200B and AH8300B, the same hospital grade duplex is offered as AH8300W in white/ivory, so you can keep the finish consistent with the rest of the openings and plates in a facility.
