Eaton Arrow Hart Heavy-Duty Industrial Duplex Receptacle, 15A 125V, 5-15R, Gray

Eaton Arrow Hart Heavy-Duty Industrial Duplex Receptacle, 15A 125V, 5-15R, Gray

(No reviews yet) Write a Review

Model: 5262W
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$5.27
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Arrow Hart Heavy-Duty Industrial Duplex Receptacle, 15A 125V, 5-15R, Gray

The Eaton Arrow Hart Heavy-Duty Industrial Duplex Receptacle is a specification-grade 5-15R duplex outlet built for demanding commercial and industrial wiring. Rated 15A at 125V and sized for #14-10 AWG conductors, this flush-mount receptacle accepts back and side wiring for fast, flexible screw-terminal installation. Brass contacts, a gray high-impact nylon face, and a glass-filled nylon body deliver the durability required for heavy-duty industrial applications, and the unit is UL Listed and RoHS Compliant.

Key Features

  • Duplex Configuration: 5-15R duplex receptacle layout for standard 15A grounded plugs.
  • Electrical Rating: 15A, 125V for reliable general-purpose and equipment circuits.
  • Wire Range: Accepts #14-10 AWG conductors for flexible branch-circuit wiring.
  • Wiring Method: Back and side wire screw terminals for fast, secure termination.
  • Industrial Specification Grade: Heavy-duty construction built for industrial-duty performance and repeated plug cycles.
  • Durable Construction: Brass contacts, high-impact nylon face, and glass-filled nylon body resist wear and impact.
  • Mounting Style: Flush mount for standard wallbox installation.
  • Finish: Gray high-impact nylon face for a clean, industrial appearance.

Certifications & Compliance

  • UL Listed
  • RoHS Compliant

Technical Specifications

  • Product Type: Receptacle
  • Warranty: Refer to warranty document.
  • Certifications: UL
  • Product Width: .88 in
  • Product Length/Depth: 1.32 in
  • Product Height: 4.19 in

Typical Applications

  • Industrial and Commercial Electrical Installations
  • Flush-Mount Wall Outlet Wiring
  • Heavy-Duty Equipment and Machinery Power Connections
  • Back-and-Side Wiring Applications
  • New Construction and Renovation Projects

Why Eaton?

Eaton Arrow Hart receptacles are engineered to industrial specification grade with brass contacts and impact-resistant nylon construction, giving electrical professionals a dependable duplex outlet for demanding environments. UL Listed and RoHS Compliant, this receptacle supports code-compliant installations where consistent performance and long-term durability matter.

Manufacturer Resources

Product Specs

Product Width:
.88 in
Warranty:
Refer to warranty document.
Product Length/Depth:
1.32 in
Compliances:
RoHS Compliant
Product Height:
4.19 in
Certifications:
UL
Product Type:
Duplex Receptacle
Department:
Electrical
Product Material:
Nylon
Voltage Rating:
125V
Amperage Rating:
15A
Configuration:
Duplex
Connection Type:
Screw
Listing:
UL Listed
Grade:
Industrial Specification Grade
Product Group:
Wiring Devices
Product Subgroup:
Receptacles & Outlets

Eaton 5262W – Frequently Asked Questions

1) Will the Eaton Arrow Hart 5262 receptacle take #12 or #10 wire on a 20A-fed branch circuit?
The 5262 accepts #14 to #10 AWG conductors on its screw terminals, so #12 and #10 land fine. But the device itself is rated 15A at 125V, so it can only be used as a 15A outlet. If the circuit needs a 20A receptacle face, go to a 20A device like the Bryant 5362B heavy-duty duplex or the Pass & Seymour 26352W spec grade decorator duplex.
2) Will this Eaton 5262 fit a standard single-gang wallbox with a regular duplex cover plate?
It is a flush-mount duplex sized for a standard wallbox and takes an ordinary duplex (two-hole) cover plate, not a decorator plate. The device measures 4.19 x 1.32 x .88 inches, so check your box depth against the 1.32 inch dimension if you are working in a shallow or crowded box. If you want a rectangular decorator opening instead, the Pass & Seymour 26352W is a decorator-style duplex.
3) Is the Eaton 5262 tamper resistant, and do I need TR outlets in my building?
The 5262 is a standard industrial-grade duplex without tamper-resistant shutters. Where the job calls for TR outlets, common in dwelling units, childcare, schools and patient areas, use a tamper-resistant device instead such as the Pass & Seymour 3232TRW Trademaster duplex.
4) Does this Eaton receptacle have GFCI protection?
No. The 5262 is a plain 5-15R duplex with no GFCI electronics, so it needs upstream protection where code requires it, either a GFCI breaker or a GFCI device ahead of it on the circuit. If you need the protection at the outlet itself, the Pass & Seymour 2097HGI is a self-test GFCI duplex, hospital grade and 20A.
5) Can I use this 5-15R receptacle on a 208V or 277V circuit for machinery?
No. The 5262 is rated 125V only, single-phase 15A. For higher-voltage equipment feeds you need a different configuration entirely, such as the Bryant 430R9W 2-pole 3-wire 277V motor-duty receptacle, or a locking device like the Bryant 70520FR flanged locking receptacle where the cord must not pull free.
6) What is the closest 20A alternative to the Eaton Arrow Hart 5262 duplex receptacle for a circuit that needs a 20 amp outlet?
The Eaton Arrow Hart 5262 is rated 15A at 125V in a duplex configuration. Where the branch circuit calls for a 20 amp device instead, the Bryant 5362B heavy-duty duplex receptacle is rated 20A/125V, as is the Bryant 5362BI. Both keep the same duplex format on a 125V circuit, so the change is the amperage rating rather than the layout.
7) Does the Eaton Arrow Hart 5262 meet tamper-resistant requirements, or do I need a different receptacle?
The Eaton Arrow Hart 5262 is an industrial specification grade duplex receptacle, UL Listed and RoHS compliant, with brass contacts and a glass-filled nylon body. Where the occupancy requires tamper-resistant outlets, the Pass & Seymour 3232TRW Trademaster tamper-resistant duplex receptacle in white is the device built with the shutter mechanism for that requirement.
8) Can the Eaton Arrow Hart 5262 be used in a patient care area, or is a hospital grade device required?
The Eaton Arrow Hart 5262 is an industrial specification grade device, UL Listed, intended for commercial and industrial branch circuits. For patient care spaces that call for hospital grade and GFCI protection, the Pass & Seymour 2097HGI is a hospital grade 20A duplex self-test GFCI receptacle in ivory. That is a different listing category from the industrial grade 5262, so the two are not interchangeable in healthcare work.
9) What should I use instead of the Eaton Arrow Hart 5262 in a hazardous or wet industrial location?
The Eaton Arrow Hart 5262 is a flush-mount duplex receptacle for a standard wallbox in commercial and industrial interiors. For classified areas, the Appleton FSQC Series interlocked explosionproof receptacle is built for that duty, and the Appleton U-Line ECS factory-sealed 15 and 20 amp plug and receptacle set is a 3-pole sealed assembly. Those are enclosure-based devices rather than wallbox flush-mount outlets, so the box and conduit work differs.
10) Can I back-wire this Eaton industrial receptacle, or do I have to wrap the screws?
Both work. The 5262 is a back and side wire device using screw terminals, so you can feed the conductor straight into the back clamp and tighten the screw, or hook it under the side screw. No push-in stab connections here, every termination is clamped by a screw.
11) Is a 5-15R industrial spec grade outlet worth it over a standard residential receptacle in a shop?
In a shop or plant where cords get pulled and plugged daily, yes. The 5262 is built to industrial specification grade with brass contacts, a high-impact nylon face and a glass-filled nylon body, which is what holds blade tension and survives impact over repeated plug cycles. A residential-grade outlet loses grip and cracks long before that.
12) Can I install the Eaton 5262 in a hazardous or classified area?
No. It is a general-purpose flush-mount device for standard wallboxes and carries no explosionproof or factory-sealed rating. Classified locations need purpose-built gear such as the Appleton FSQC Series interlocked explosionproof receptacle or the Appleton U-Line ECS factory-sealed plug and receptacle set.
13) Is a locking receptacle a substitute for the Eaton Arrow Hart 5262?
No. The Eaton Arrow Hart 5262 is a straight-blade 15A 125V duplex device that accepts standard grounded 15A plugs. The Bryant 70520FR is a 7 Series NEMA flanged locking receptacle and the Pass & Seymour Turnlok is a 30A non-NEMA single receptacle; both require twist-lock cord caps and will not accept an ordinary 5-15P plug. Choose those only when the equipment cord is already fitted with a locking plug.
14) I need a spec grade duplex outlet in a decorator style instead of the standard Arrow Hart 5262 face. What should I order?
The Eaton Arrow Hart 5262 has a standard duplex face in gray or white nylon. For a decorator-style opening, the Pass & Seymour 26352W is a 20A 125V heavy-duty specification grade decorator duplex receptacle in white. It keeps the spec-grade construction but uses the decorator faceplate opening, which needs a decorator wallplate rather than a standard duplex plate.
15) Will the Eaton Arrow Hart 5262 work on a 277V motor circuit?
No. The Eaton Arrow Hart 5262 is rated 125V. For a 277V circuit, the Bryant 430R9W is a 4750DR series 2-pole 3-wire 277V motor-duty receptacle. The voltage rating is the deciding difference, so the 5262 stays on 125V branch circuits.
