B-Line Eaton series other enclosure accessories, 12, ANSI 61 gray painted, Used as wiring boxes, junction and pull boxes, Steel, Type 1 screw cover,

The 1212 SCF measures 13.5 inches in height, 13.5 inches in width, and 13.5 inches in length/depth, so plan on a cube roughly 13-1/2 inches on each side when you lay out wall space or a backpan. It weighs 2.887 lb, light enough for one person to hold in place while the mounting screws go in.

It carries a NEMA 12 degree of protection, which covers falling dirt, circulating dust, lint and dripping non-corrosive liquids, so it suits plant floors, machine shops and mill areas. NEMA 12 is not a rating for direct hosedown or outdoor exposure, so for rain or washdown spray you want a NEMA 4 or 4X enclosure instead. The 1212 SCF is UL Listed.

Flush mount. The box is built to recess into the wall with the cover trimming out at the finished surface, so it needs a wall cavity deep enough for the 13-1/2 inch body. If your run is exposed on a block wall or you're hanging it off strut, you want a surface-mount enclosure instead, because a flush box has no provision for standing off a finished face.

It's a screw cover, not a hinged door. The cover lifts off completely once the screws are backed out, which gives clear access to the full interior for pulling and splicing conductors but means you need a free hand (or a helper) to hold the cover on an overhead or ceiling-mounted box. If you're opening the box routinely for inspection, a hinged-cover enclosure is the easier choice.

Both. The 1212 SCF is intended for use as a wiring box, junction box and pull box, and the removable screw cover on a 13-1/2 inch square body gives you room to work slack out of a bend. It ships without knockouts specified, so conduit entries are field-drilled or punched where your run needs them.

Steel construction in 16 gauge, painted ANSI 61 gray, which is the standard gray used across most industrial enclosures and control panels, so it will read as a match alongside typical panelboards and disconnects. The paint is a coating over steel, not stainless, so for corrosive or coastal duty step up to a stainless or non-metallic enclosure.

Order it as B-Line 1212 SCF. That single catalog number covers the NEMA 12, ANSI 61 gray, flush-mount steel box with the Type 1 screw cover, and there are no finish or size options to specify behind it. The SCF suffix is the screw-cover flush configuration.
