You may also like
Eaton B-Line series wireway hanger, Wireway hanger, NEMA 1, Steel, ANSI 61 gray painted, 6" X 6"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Degree Of Protection:
- 1
- Finish Color:
- ANSI 61 gray painted
- Product Height:
- 16.5 in
- Product Length Depth:
- 5.87 in
- Product Weight:
- 1.75 lb
- Product Width:
- 8 in
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Wireway hanger
- Product Details:
- Wireway hanger
- Product Material:
- Steel
B-LINE 66 FH – Frequently Asked Questions
1) What size wireway does the Eaton B-Line 66 FH hanger fit?
The 66 FH hanger is sized for 6 x 6 inch wireway, which is the trough size called out in the Eaton B-Line description. If your run is 4 x 4, 8 x 8 or 12 x 12, you need the matching hanger for that trough size instead, not this one.
2) Is the B-Line 66 FH hanger suitable for indoor NEMA 1 wireway, or can I use it outdoors?
It is built for NEMA 1 (degree of protection 1) wireway, which is an indoor, general-purpose enclosure rating with no water or dust protection. For outdoor or washdown runs you'd be on NEMA 3R or 4X trough and its matching hanger, not this one. The ANSI 61 gray painted steel here matches standard indoor gray wireway.
3) How much clearance do I need to hang 6x6 wireway with a B-Line 66 FH hanger?
Plan on roughly 16-1/2 inches of drop for the hanger itself. Its stated dimensions are 16.5 in height, 8 in width and 5.87 in length/depth, so between the structure attachment point and the top of the trough you need that vertical space plus whatever rod or strut you are hanging from. In a tight plenum or low ceiling, measure that 16.5 inches before you commit.
4) How heavy is a single B-Line 66 FH hanger, and does it come as one piece?
Each hanger weighs 1.75 lb and is ordered as the single model 66 FH item. It is the hanger only, so threaded rod, strut, anchors and the fasteners into the structure are separate line items on your order.
5) Is a steel wireway hanger the right support, or should I just use strut and clamps?
A purpose-made hanger like the B-Line 66 FH cradles the 6 x 6 trough at a fixed geometry, so every support along the run sits at the same height and the trough stays square, which is faster than field-fitting strut and clamps on a long run. Strut still makes sense where you are supporting mixed conduit and trough on one trapeze. For a straight wireway run, the matched steel hanger is fewer pieces and less layout.
6) Will the gray finish on the B-Line wireway hanger match my existing wireway run?
It is painted ANSI 61 gray, the standard gray used on general-purpose steel wireway and enclosures, so it matches typical NEMA 1 trough already installed in a plant or electrical room. Matching matters if hangers are exposed in a finished space; in a ceiling cavity it is cosmetic only.
