Eaton B-Line series wireway hanger, Wireway hangers(drop), NEMA 12, Steel, ANSI 61 gray painted, 6" X 6"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Finish Color:
- ANSI 61 gray painted
- Product Height:
- 16 in
- Product Length Depth:
- .067 in
- Product Weight:
- 2.605 lb
- Product Width:
- 16 in
- Special Features:
- NEMA12
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Wireway hangers(drop)
- Product Details:
- Wireway hangers(drop)
- Product Material:
- Steel
B-LINE 66-12LDH – Frequently Asked Questions
1) What size wireway does the B-Line 66-12LDH hanger fit?
The Eaton B-Line 66-12LDH drop hanger is built for 6 inch by 6 inch wireway. Match the hanger to the duct cross section, not to the rod size, since the cradle dimension is what carries the wireway.
2) Is the 66-12LDH hanger suitable for a NEMA 12 wireway run?
Yes. It is the NEMA 12 version of the B-Line drop hanger, so it belongs on an oiltight/dusttight 6 x 6 wireway run rather than a NEMA 1 screw-cover run. Using the matching NEMA rating keeps the whole installed system consistent for inspection.
3) What is the drop hanger made of and how is it finished?
Steel, painted ANSI 61 gray. That matches the standard gray finish on Eaton B-Line wireway, so the support does not stand out against the duct in an exposed run. Painted steel is intended for dry indoor work, not corrosive or wet exterior locations.
4) What are the dimensions of the 66-12LDH drop hanger?
It measures 16 in by 16 in, formed from .067 in material. The 16 inch envelope is what you need to clear when the wireway runs tight to a wall, ceiling, or an adjacent duct.
5) Is a drop hanger the right choice, or should I use a wall bracket for my wireway?
A drop hanger like the 66-12LDH suspends the wireway from structure above on threaded rod, which is what you want for a run down the middle of a space or below a deck. If the run follows a wall or a column line, a wall-mount bracket is the simpler support. Pick by where the run sits, then match the 6 x 6 size and NEMA 12 rating.
6) How much does one B-Line 66-12LDH hanger weigh for load calculations?
Each hanger weighs 2.605 lb. On a long horizontal run, count the hanger weight plus the filled wireway when you size the rod and the structural attachment overhead.
7) Does the wireway hanger come with threaded rod and anchors?
What you are ordering is the steel hanger itself. Threaded rod, the structural anchor at the deck, and the nuts and washers are job-supplied and sized to your load and ceiling type, so order them alongside the hangers.
