Eaton B-Line series wireway hanger, Wireway hanger, NEMA 1, Steel, ANSI 61 gray painted finish, 8" X 8"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Degree Of Protection:
- 1
- Finish Color:
- ANSI 61 gray painted
- Product Height:
- 20.5 in
- Product Length Depth:
- 6.87 in
- Product Weight:
- 3.039 lb
- Product Width:
- 10.688 in
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Wireway hanger
- Product Details:
- Wireway hanger
- Product Material:
- Steel
B-LINE 88 FH – Frequently Asked Questions
1) What size wireway does the B-Line 88 FH hanger fit?
The Eaton B-Line 88 FH hanger is built for 8 inch by 8 inch wireway, the size called out in its description. If your run is 4x4, 6x6, or 12x12, this is not the hanger for it - match the hanger to the trough cross section.
2) Is the 88 FH wireway hanger rated for outdoor or wet locations?
No. It is a NEMA Type 1 item, which is indoor, general purpose only - no rain, sleet, or washdown protection. For an outdoor or damp run you need Type 3R or 4 rated wireway and matching support hardware.
3) What are the dimensions and weight of the 88 FH hanger for planning clearance?
It measures 20.5 in height, 10.688 in width, and 6.87 in length/depth, and weighs 3.039 lb. Allow for the 20.5 in dimension when you are laying out the hanger above a suspended ceiling or against structure, since it is the deepest part of the bracket profile.
4) What exactly is a wireway hanger and do I need one for every section of trough?
A wireway hanger is a steel support bracket that carries the wireway trough off a wall or structure instead of letting the trough hang on its own joints. The B-Line 88 FH is that bracket, sized for 8x8 wireway. Support spacing comes from your wireway manufacturer's instructions and the NEC, so order enough hangers to hit that spacing across the full run plus the ends.
5) When I order the 88 FH, is the mounting hardware or the wireway included?
You are ordering the hanger only, model 88 FH. The wireway trough, covers, fittings, and the anchors or bolts that fasten the hanger to concrete, block, or steel are separate line items and need to be specified for the substrate you are fastening to.
6) Will the gray finish on this hanger match my existing wireway and enclosures?
The hanger is steel with an ANSI 61 gray painted finish, the same standard gray used on most commercial wireway, panelboards, and enclosures. In a plant or a back-of-house electrical room it blends with the existing equipment rather than standing out.
