Eaton B-Line series wireway hanger, Wireway hangers(drop), NEMA 12, Steel, ANSI 61 gray painted finish, 8" X 8"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Finish Color:
- ANSI 61 gray painted
- Product Height:
- 8 in
- Product Length Depth:
- .067 in
- Product Weight:
- 3.276 lb
- Product Width:
- 20 in
- Special Features:
- NEMA12
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Wireway hangers(drop)
- Product Details:
- Wireway hangers(drop)
- Product Material:
- Steel
B-LINE 88-12LDH – Frequently Asked Questions
1) What size wireway does the B-Line 88-12LDH drop hanger fit?
The Eaton B-Line 88-12LDH drop hanger is built for 8 in. x 8 in. wireway. Match the hanger to the duct cross section, so if your run is 4x4, 6x6 or 12x12, this is not the part.
2) Is this hanger rated for NEMA 12 wireway or only for indoor NEMA 1?
It is the NEMA 12 version, meant to support dust-tight, drip-tight lay-in wireway rather than the standard NEMA 1 screw-cover type. It is UL Listed.
3) How much does the 88-12LDH wireway hanger weigh, and what are its dimensions?
It weighs 3.276 lb and measures 20 in. wide by 8 in. high, formed from .067 in. material. Factor the weight in when you are calculating total suspended load on threaded rod or beam clamps for a long wireway run.
4) Is a drop hanger the right choice, or should I use a wall bracket for my wireway?
A drop hanger like the 88-12LDH is for suspending wireway below a structure, typically off threaded rod from deck, beam or joist, so the duct hangs in open space. If the wireway runs tight along a wall or column face, a wall-mount bracket or strut and post base is the better route. Pick the drop hanger only where the run is overhead and free-standing.
5) Does the 88-12LDH come with the threaded rod and hardware to hang it?
What ships is the steel hanger itself. Threaded rod, rod couplings, beam clamps or concrete anchors, and the nuts and washers at the rod ends are separate items you order to suit the ceiling structure and the drop length on your job.
6) What is the B-Line 88-12LDH made of and how is it finished?
Steel with an ANSI 61 gray painted finish, which is the same gray used on most industrial enclosures and wireway, so the hanger blends with the duct run instead of standing out.
7) How many wireway hangers do I need for a run?
Set hanger spacing from the wireway manufacturer's support interval for NEMA 12 lay-in duct and add a hanger near each coupling, elbow and tee where the run changes direction or picks up extra weight. Each 88-12LDH carries 8 x 8 duct, so order one per support point across the whole run rather than per section length.
