Eaton Commercial Loadcenter Flush Cover, Galvanized Steel
The Eaton Commercial Loadcenter Flush Cover is a galvanized steel enclosure cover engineered for flush-mount installation on compatible Eaton BR commercial loadcenters, including the 3BR4242n225ny. Rated 208Y/120, 240V for three-phase service and housed in a NEMA 1 enclosure, this cover is approved for use in New York and suited for commercial electrical distribution equipment. It is designed to pair with #1 AWG-300 kcmil Cu/Al conductors and a 10 kAIC interrupt-rated system, giving contractors a code-compliant finishing component for BR-series loadcenter installations.
Key Features
- Flush Mounting: Configured for flush mounting, providing a clean, finished appearance for commercial installations.
- Durable Construction: Galvanized steel enclosure material delivers corrosion resistance and long-term durability.
- Voltage Rating: Rated 208Y/120, 240V for three-phase commercial power distribution.
- Wire Compatibility: Accommodates #1 AWG-300 kcmil Cu/Al conductors across 4 wires.
- Interrupt Rating: 10 kAIC interrupt rating supports demanding commercial fault conditions.
- Enclosure Rating: NEMA 1 enclosure suited for indoor commercial applications.
- Compatibility: Designed for use with the Eaton 3BR4242n225ny loadcenter.
- Special Feature: Approved for use in New York, including 150A and up residential services in New York City.
Certifications & Compliance
- UL 67
- NEMA 1 Enclosure
- Approved for Use in New York
Technical Specifications
- Product Type: Load Center
- Box size: B
- Main circuit breaker: CC
- Number of wires: 4
- Product Width: 1.75 in
- Product Length/Depth: 18.13 in
- Product Height: 44 in
- Enclosure material: Galvanized steel
- Bus material: Aluminum
- Wire size: #1 AWG-300 kcmil Cu/Al
- Phase: Three-phase
- Mounting: Flush
- Interrupt rating: 10 kAIC
- Enclosure: NEMA 1
- Used with: 3BR4242n225ny
Typical Applications
- Commercial and Industrial Electrical Installations
- Loadcenter and Panelboard Enclosure Finishing
- Flush-Mount Loadcenter Installations
- New York City Residential Service Upgrades, 150A and Up
- New Construction and Renovation Projects
Why Eaton?
Eaton engineers this loadcenter flush cover with a galvanized steel enclosure and a NEMA 1 rating to hold up in demanding commercial environments, backed by UL 67 listing for verified safety performance. Approval for use in New York, including 150A-and-up residential services in New York City, makes it a dependable choice for electricians working under strict local code requirements. Paired with the compatible Eaton BR loadcenter, it delivers a code-compliant, professional finish for commercial electrical distribution systems.
Manufacturer Resources
Product Specs
- Product Width:
- 1.75 in
- Cover Type:
- Cover included
- Enclosure material:
- Galvanized steel
- Used with:
- 3BR4242n225ny
- Voltage Rating:
- 208Y/120, 240V
- Product Length/Depth:
- 18.13 in
- Special features:
- Approved for use in new york
- Product Height:
- 44 in
- Product Type:
- Load Center
- Phase:
- Three-phase
- Box size:
- B
- Mounting Method:
- Flush
- Main circuit breaker:
- CC
- Interrupt rating:
- 10 kAIC
- Bus material:
- Aluminum
- Product Size:
- #1 AWG-300 kcmil Cu/Al
- Number of wires:
- 4
- Configuration:
- Flush Mount
- Certifications:
- UL 67
- Department:
- Electrical
- Product Material:
- Galvanized Steel
- Standards:
- NEMA 1
- Listing:
- UL 67
- Product Group:
- Load Centers & Panel Boards
Eaton 3BR42FTNY – Frequently Asked Questions
1) Is the 3BR42FTNY a complete load center or just the cover?
It's the trim/cover component only, in galvanized steel, for a BR commercial loadcenter. The panel interior, bus, and breakers are separate. Order it along with the matching 3BR4242n225ny enclosure when you're building the job out.
2) Can this Eaton flush cover be used on a surface-mounted panel?
No. It is configured for flush mounting, meaning the panel is recessed into the wall and the trim laps onto the finished surface. A surface-mounted BR loadcenter needs a surface-type cover instead. Mixing the two leaves either a gap at the wall or a trim that won't seat on the box.
3) Is this Eaton loadcenter cover approved for use in New York City?
Yes. It carries New York approval, including 150A and up residential services in New York City, which is the sticking point on most NYC service upgrades. It is also UL 67 listed and the enclosure is NEMA 1.
4) Can this NEMA 1 Eaton panel cover be installed outdoors or in a wet area?
No. NEMA 1 is an indoor, general-purpose rating with no protection against rain, splashing, or hose-down. Keep it to dry indoor commercial and residential spaces. Outdoor or damp locations call for a rainproof enclosure and trim.
5) What voltage and fault current system is this Eaton BR cover rated for?
It is rated 208Y/120, 240V on three-phase service with a 10 kAIC interrupt rating, four wires, and an aluminum bus in the matched loadcenter. If your available fault current at the panel exceeds 10 kAIC, the assembly is not the right choice for that service point.
6) What conductor sizes does this Eaton BR loadcenter assembly land?
The lugs take #1 AWG through 300 kcmil, copper or aluminum, across four wires. That covers typical 150A to 225A three-phase feeders. If your service conductors are larger than 300 kcmil or parallel sets, the terminations won't accept them.
7) Will a galvanized steel panel cover hold up in a parking garage or mechanical room?
The galvanized steel gives corrosion resistance for indoor commercial spaces, which is what most mechanical and electrical rooms need. But the NEMA 1 rating still governs: no dripping water, no washdown. A damp garage bay with vehicle spray needs a higher enclosure type.
