Bussmann BBS-5 Eaton series BBS fuse, Fast acting Midget fuse, 5 A, Non-indicating, Ferrule end x ferrule end, 10 kAIC at 600 Vac, Nickel-plated brass endcaps, Standard, 600 V

Bussmann BBS Series Fast Acting Midget Fuse 5A 600V with Ferrule Ends

(No reviews yet) Write a Review

Model: BBS-5
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$63.87
$14.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann BBS Series Fast Acting Midget Fuse 5A 600V with Ferrule Ends

Professional Fast-Acting Circuit Protection for Industrial Applications

The Bussmann BBS Series Fast Acting Midget Fuse delivers reliable 5A circuit protection at 600V with professional-grade nickel-plated brass endcaps and ferrule end connections. This non-indicating midget fuse provides 10 kAIC interrupt rating at 600 Vac, ensuring dependable overcurrent protection in demanding electrical applications with compact 1.34" x 0.36" x 0.36" dimensions.

Professional Features & Benefits

  • 5A Current Rating: Provides precise overcurrent protection for sensitive circuits and equipment loads
  • 600V Voltage Rating: Supports high-voltage industrial and commercial electrical systems
  • 10 kAIC Interrupt Rating: Delivers robust fault current interruption capability for reliable system protection
  • Nickel-Plated Brass Endcaps: Ensures superior conductivity and corrosion resistance for long-term reliability
  • Ferrule End Connections: Provides secure, professional-grade termination for consistent electrical contact
  • Fast Acting Response: Quickly interrupts overcurrent conditions to protect downstream equipment
  • CE Marked Compliance: Meets international safety and performance standards for global applications

Technical Specifications

  • Amperage Rating: 5:00 AM
  • Compliances: CE Marked
  • Connection: Ferrule end x ferrule end
  • Ean: 5.02759E+12
  • Fuse Indicator: Non-indicating
  • Interrupt Rating: 10 kAIC at 600 Vac
  • Packaging Type: Standard
  • Product Height: 1.34 in
  • Product Length Depth: .36 in
  • Product Material: Nickel-plated brass endcaps
  • Product Weight: .1 lb
  • Product Width: .36 in
  • Voltage Rating: 600 V

Professional Applications

  • Industrial Control Panels and Motor Control Centers
  • Commercial HVAC and Lighting Systems
  • Manufacturing Equipment Protection
  • Process Control and Automation Systems
  • Power Distribution and Switchgear Applications
  • Instrumentation and Control Circuits
  • Emergency Power and Backup Systems

Why Choose Bussmann Quality?

Bussmann delivers proven reliability with CE marked compliance and professional-grade nickel-plated brass construction. The compact midget fuse design with ferrule end connections ensures dependable circuit protection backed by rigorous international safety standards for long-term performance in demanding electrical environments.

Manufacturer Resources

Product Specs

Amperage Rating:
5 A
Compliances:
CE Marked
Connection:
Ferrule end x ferrule end
Ean:
5.02759E+12
Fuse Indicator:
Non-indicating
Interrupt Rating:
10 kAIC at 600 Vac
Packaging Type:
Standard
Product Height:
1.34 in
Product Length Depth:
.36 in
Product Material:
Nickel-plated brass endcaps
Product Weight:
.1 lb
Product Width:
.36 in
Voltage Rating:
600 V
Department:
Electrical
Product Type:
Fuse
Product Group:
Fuses
Product Subgroup:
Other Fuses

Bussmann BBS-5 – Frequently Asked Questions

1) Should I use a fast acting fuse or a time delay fuse for a motor circuit?
The BBS-5 is fast acting, which means it clears an overcurrent quickly with no intentional delay. That suits control circuits, instrumentation, transformers on the secondary side, and electronic loads where you want the fuse out fast. It is the wrong choice ahead of a motor or anything with a high inrush, because the starting surge will blow it. For motor branch circuits use a time delay (dual element) fuse instead.
2) Does the Bussmann BBS-5 have a blown fuse indicator?
No, it's a non-indicating fuse. There is no pop-up pin or window to show it has opened, so on a panel with a row of these you will be pulling and metering them to find the bad one. If technicians need to spot a blown fuse visually, specify an indicating version or pair the holder with a blown fuse indicating light.
3) What is the exact part number for the 5 amp Bussmann BBS fuse?
Order it as BBS-5. That's the Bussmann catalog number for the 5 amp, 600 volt fast acting midget fuse in the BBS series, ferrule end by ferrule end. The amp rating is the suffix, so the same series in another size follows the same pattern.
4) Does the Bussmann BBS-5 carry a CE mark for equipment being shipped to Europe?
Yes, the BBS-5 is CE marked, so it can go into control panels and machinery built for export where CE marking is required on the components. That is the only compliance marking held on record for this fuse.
