Bussmann Fast Acting Fuse KTK Series 5A 600V LIMITRON Non-Indicating Ferrule End

Bussmann Fast Acting Fuse KTK Series 5A 600V LIMITRON Non-Indicating Ferrule End

Professional-Grade Current Limiting Circuit Protection

The Bussmann Fast Acting Fuse KTK Series 5A 600V LIMITRON delivers superior electrical protection and circuit safety for control circuits, lighting applications, and meter circuits. This fast-acting current limiting fuse features LIMITRON technology designed for electrical contractors, industrial facilities, and commercial installations, providing the reliable overcurrent protection and industry-leading safety that electrical professionals demand.

Professional Features & Benefits

Current Limiting Protection

• LIMITRON Fast-Acting Technology - Provides rapid fault clearing and arc suppression for enhanced electrical safety
• 100 kAIC Interrupt Rating at 600V - Handles high fault currents with reliable circuit protection performance
• 5 Ampere Rating - Precisely calibrated for control circuit and lighting protection applications
• Non-Indicating Design - Professional appearance with reliable operation indication through circuit monitoring

Safety & Standards Compliance

• UL Listed Construction - Meets rigorous electrical safety standards for professional installations
• NEC Compliant Design - Ensures code compliance for electrical panel and control circuit applications
• RoHS Compliant Materials - Environmentally responsible construction for sustainable electrical installations

Technical Specifications

5 ampere rating, 600 volt maximum, 100 kAIC interrupt rating at 600VAC, ferrule end x ferrule end connection, fast-acting response, non-indicating operation, dimensions 1.5" height x 0.41" width x 0.41" length, 0.19 lb weight, nickel-plated bronze endcap construction with melamine tube body.

Installation & Setup

1. Verify power is completely disconnected and use proper lockout/tagout procedures before installation
2. Inspect fuse holder and connections for proper sizing and compatibility with ferrule end design
3. Insert fuse into holder ensuring proper contact with ferrule end connections on both sides
4. Verify secure mounting and proper electrical contact before energizing circuit
5. Test circuit operation and monitor for proper overcurrent protection functionality
6. Document installation details and fuse specifications for maintenance records

Professional Applications

Ideal for:

• Control Circuit Protection - Motor starters, contactors, and automation control panels
• Lighting Circuit Applications - Commercial and industrial lighting control and protection systems
• Meter Circuit Protection - Electrical metering and monitoring equipment overcurrent protection
• Instrumentation Circuits - Process control and measurement equipment protection
• Low Current Applications - Electronic control systems and sensitive equipment protection
• Panel Board Protection - Distribution panels and electrical control enclosures
• Commercial Buildings - Office buildings, retail facilities, and institutional electrical systems
• Industrial Facilities - Manufacturing plants, processing facilities, and industrial control systems

LIMITRON Technology Advantage

Bussmann LIMITRON technology provides superior current limiting performance with fast-acting response to electrical faults. The advanced arc suppression design minimizes let-through energy and reduces damage to downstream equipment, while the precise calibration ensures reliable protection for sensitive control circuits and lighting applications.

Why Choose Bussmann Quality?

Bussmann demonstrates unwavering commitment to UL listing, NEC compliance, and reliable overcurrent protection for professional electrical installations. The KTK Series combines proven LIMITRON technology with robust construction, delivering the electrical safety and circuit protection reliability that electrical contractors and facility managers trust for critical applications.
