Bussmann LP-CC 25A Current-Limiting Time-Delay Fuse with Rejection Style Design

Bussmann LP-CC 25A Current-Limiting Time-Delay Fuse with Rejection Style Design

Professional Class CC Protection for Specialized Circuits and Industrial Control

The Bussmann LP-CC series delivers reliable current-limiting time-delay protection with 25A rating and rejection style design. Featuring dual elements in a melamine tube construction with ferrule end connections, this Class CC fuse provides 200 kAIC interrupt rating at 600 Vac and 12-second response time at 200% overload for specialized circuits and industrial control applications.

Professional Features & Benefits

• 25A Current Rating: Provides precise overcurrent protection for medium-load circuits with reliable amperage capacity.
• Current-Limiting Time-Delay: Combines fast fault clearing with temporary overload tolerance to prevent nuisance tripping during motor starts.
• 200 kAIC Interrupt Rating: Delivers high fault current interruption capability at 600 Vac for robust system protection.
• Rejection Style Design: Prevents incorrect fuse installation and ensures proper circuit protection coordination.
• Class CC Construction: Meets stringent performance standards for specialized circuits and industrial control applications.
• Dual Element Configuration: Provides enhanced protection characteristics with separate overload and short-circuit elements.
• CE Marked Compliance: Meets European conformity standards for international installation requirements.

Technical Specifications

• Amperage Rating: 25 A
• Application: Specialized circuits and industrial control
• Class: Class CC
• Compliances: CE Marked
• Connection: Ferrule end x ferrule end
• Department: Electrical
• Fuse Indicator: Non-indicating
• Interrupt Rating: 200 kAIC at 600 Vac
• Material: Melamine tube
• Number Of Elements: Dual
• Packaging Type: Standard
• Product Details: Current-limiting time-delay fuse
• Product Group: Fuses
• Product Height: 1.5 in
• Product Length Depth: .41 in
• Product Subgroup: Time Delay Fuses
• Product Type: Time Delay Fuses
• Product Weight: .15 lb
• Product Width: .41 in
• Quantity: 10
• Response Time: 12 sec at 200%
• Special Features: Rejection style
• Voltage Rating: 600 Vac, 300 Vdc

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Control Panels
• Motor Control Centers
• Specialized Circuit Protection
• Commercial Electrical Systems
• Manufacturing Equipment
• Process Control Systems
• Automation and Control Circuits

Why Choose Bussmann Quality?

Bussmann delivers proven reliability with melamine tube construction, CE marked compliance, and precision-engineered dual element design. The rejection style feature ensures proper installation while the 200 kAIC interrupt rating provides robust protection for demanding industrial applications.
