Bussmann Time Delay Fuse LP-CC Series 2A 600VAC/300VDC Class CC Ferrule End Current Limiting

Bussmann Time Delay Fuse LP-CC Series 2A 600VAC/300VDC Class CC Ferrule End Current Limiting

Professional-Grade Current Limiting Circuit Protection

The Bussmann LP-CC Series Time Delay Fuse delivers superior electrical protection and circuit safety for specialized circuits and industrial control applications. This Class CC time delay fuse features current-limiting technology and rejection style design for electrical contractors, industrial facilities, and commercial installations, providing the reliable overcurrent protection and industry-leading safety that electrical professionals demand.

Professional Features & Benefits

Current Limiting Protection

• Dual Element Design - Provides time delay characteristics for motor starting while offering fast response to short circuits
• Current Limiting Technology - Reduces let-through energy and peak current to protect downstream equipment
• 200 kAIC Interrupt Rating at 600VAC - Handles high fault currents safely in industrial applications
• Rejection Style Construction - Prevents installation of incorrect fuse types for enhanced safety

Safety & Standards Compliance

• Class CC Classification - Meets stringent current limiting and size requirements for critical applications
• CE Marked Compliance - Certified for international electrical safety standards
• Non-Indicating Design - Provides reliable protection without visual indication for specialized applications

Technical Specifications

2A amperage rating, 600VAC/300VDC voltage rating, 200 kAIC interrupt rating at 600VAC and 20 kAIC at 300VDC, Class CC current limiting fuse, ferrule end connections, 1.5" height x 0.41" width x 0.41" depth, 0.15 lb weight, melamine tube construction, 12 second response time at 200% rated current.

Installation & Setup

1. Verify power is completely disconnected and use proper lockout/tagout procedures before installation
2. Confirm fuse holder is rated for Class CC fuses and rejection style design
3. Insert fuse with ferrule ends properly seated in fuse clips ensuring secure connection
4. Verify proper fuse orientation and that rejection features prevent incorrect installation
5. Test installation with appropriate electrical testing equipment before energizing
6. Document installation per NEC requirements and facility maintenance procedures

Professional Applications

Ideal for:

• Industrial Control Circuits - Motor control panels, PLC systems, and automation equipment protection
• Specialized Circuit Protection - Critical control systems requiring precise overcurrent protection
• Motor Protection Circuits - Small motor applications requiring time delay for starting currents
• Lighting Control Systems - Commercial and industrial lighting control panel protection
• Instrumentation Circuits - Sensitive electronic equipment and measurement systems
• Power Distribution Panels - Branch circuit protection in electrical distribution systems
• Control Transformer Circuits - Primary and secondary protection for control transformers
• Electronic Equipment Protection - Variable frequency drives and electronic control systems

Current Limiting Technology Advantage

Bussmann's current limiting technology significantly reduces the destructive effects of short circuit currents by limiting peak let-through current and energy. The dual element design provides excellent time delay characteristics for motor starting while maintaining fast response to dangerous fault conditions, ensuring optimal protection for both equipment and personnel in industrial applications.

Why Choose Bussmann Quality?

Bussmann demonstrates unwavering commitment to electrical safety through rigorous testing, CE marking compliance, and adherence to Class CC current limiting standards. Our rejection style design prevents dangerous misapplication while providing reliable overcurrent protection that electrical professionals trust for critical industrial control and specialized circuit applications.
