Bussmann TB100-06B Eaton TB100...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$82.31
$38.43
Bussmann TB100-06B Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, Six-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Nickel-plated brass philslot screw

Bussmann TB100-06B Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, Six-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Nickel-plated brass philslot screw

(No reviews yet) Write a Review

Model: TB100-06B
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$82.31
$38.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann TB100-06B Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, Six-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Nickel-plated brass philslot screw.

  • Amp rating: 100 A
  • Voltage rating: 3600 V
  • Product type: Double row, barrier
  • Dimensions (L x W x H): 2.16 x 0.88 x 0.41 IN

Genuine Bussmann part number TB100-06B.

Manufacturer Resources

Product Specs

Amperage Rating:
30A
Certifications:
Contact Manufacturer
Compliances:
CE Marked
Connection:
#6-32 TPI Screw
Number Of Poles:
Six-pole
Operating Temperature:
-40° to 130°C
Product Height:
.41 IN
Product Length Depth:
2.16 IN
Product Weight:
.43 LB
Product Width:
.88 IN
Special Features:
Breakdown voltage 3600V
Torque Rating:
9 lb-in
Voltage Rating:
300V
Product Group:
0
Department:
Electrical
Product Subgroup:
0
Product Type:
Double row, barrier
Product Details:
Double row, barrier
Product Color:
Black
Mounting Method:
Screw
Product Material:
Tin-plated brass terminal, Nickel-plated brass philslot screw

Bussmann TB100-06B – Frequently Asked Questions

1) How many circuits does the Bussmann TB100-06B terminal block handle?
Six. The TB100-06B is a six-pole double row barrier block, so you get six separate screw-to-screw circuits, each landing a wire on both sides of the barrier. If you need more than six circuits in one run, you'd gang additional blocks rather than trying to double up on a pole.
2) What voltage and current can I run through a Bussmann TB100 series barrier terminal block?
The TB100-06B carries a 300V, 30A working rating, with a 3600V breakdown (dielectric withstand) figure. The 3600V number is the insulation's flashover capability, not an operating voltage, so size your circuit to the 300V/30A rating.
3) What size ring or spade terminals fit the TB100-06B block screws?
The terminals take #6-32 screws, so use ring or spade lugs with a #6 stud hole. The screws are nickel-plated brass with a phillips/slot combination head, so either a #2 phillips or a small flat blade drives them.
4) Does the TB100-06B mount on DIN rail?
No. This is a screw-mounted panel block, not a DIN rail block. It fastens flat to a subpanel or chassis. If your panel is built around 35mm DIN rail, you need a rail-mount block instead, or a short section of DIN-mount adapter plate to carry it.
5) What torque should I use on the terminal screws of a Bussmann TB100 barrier block?
9 lb-in on the #6-32 terminal screws. Use a torque screwdriver on control panel work; overdriving a #6 brass screw strips the thread and undertightening is what causes the hot joints inspectors look for.
6) Can this terminal block go in an unheated outdoor enclosure or a hot mechanical room?
Its operating range is -40 to 130 degrees C, which covers unconditioned rooftop and outdoor enclosures as well as boiler and mechanical rooms. The block itself is not an enclosure, so weather protection still has to come from the box it sits in.
7) Why choose a barrier terminal block over a screwless push-in block?
A barrier block like the TB100-06B separates each pole with a molded wall and lands ring lugs under #6-32 screws, which is what you want where vibration, larger conductors, or field-serviced connections are involved, and where an inspector wants to see a torqued, visible joint at 9 lb-in. Push-in blocks are faster to wire and better for dense low-current I/O, but they do not give you the same barrier separation between adjacent poles.
8) Will the TB100 block corrode in a damp control panel?
Current-carrying parts are tin-plated brass terminals with nickel-plated brass screws, both plating systems chosen to resist oxidation at the joint and keep contact resistance stable. The body is black insulating barrier material. It is CE marked.
