Eaton CH Hold Down Retainer Kit 3/4-inch 6 Circuits for Back-Feed Main Applications

(No reviews yet) Write a Review

Model: CH125RB

In Stock (leaves warehouse same day if ordered before 3pm ET)

$7.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Hold Down Retainer Kit 3/4-inch 6 Circuits for Back-Feed Main Applications

Professional Circuit Breaker Securing Solution for Loadcenter Applications

The Eaton CH Hold Down Retainer Kit provides essential circuit breaker securing functionality for back-feed main applications in CH loadcenters. This professional-grade retainer bracket system accommodates 6 circuits with 3/4-inch sizing, specifically designed for use with 1-, 2-, or 3-pole type CH circuit breakers to ensure secure installation and NEC compliance in back-feed configurations.

Professional Features & Benefits

  • 6 Circuit Capacity: Accommodates multiple breaker configurations for comprehensive loadcenter securing in back-feed applications.
  • 3/4-inch Sizing: Precise dimensional compatibility ensures proper fit and secure mounting in CH loadcenter systems.
  • Multi-Pole Compatibility: Works with 1-, 2-, or 3-pole type CH circuit breakers for versatile installation flexibility.
  • Back-Feed Main Application: Specifically designed to secure circuit breakers for back-feed main configurations per NEC requirements.
  • Compact Design: 1-inch dimensions (height, length, width) provide space-efficient installation without compromising accessibility.
  • Lightweight Construction: 1 lb weight facilitates easy handling and installation while maintaining structural integrity.

Technical Specifications

  • Catalog Notes: Device used to secure the circuit breaker to the loadcenter for back-feed main application. See nec
  • Certifications: Contact Manufacturer
  • Number Of Circuits: 6
  • Product Details: Retainer bracket
  • Product Height: 1 in
  • Product Length Depth: 1 in
  • Product Size: 3/4 in
  • Product Weight: 1 lb
  • Product Width: 1 in
  • Special Features: Suitable for CH breakers
  • Used With: 1-, 2-, or 3-pole type ch circuit breakers

Professional Applications

  • Residential Back-Feed Main Installations
  • Commercial Loadcenter Configurations
  • Generator Connection Systems
  • Emergency Power Applications
  • Multi-Unit Properties
  • Professional Electrical Installations

Why Choose Eaton Quality?

Eaton delivers reliable circuit breaker securing solutions with precision-engineered retainer bracket systems designed for professional loadcenter applications. The compact 1-inch dimensional design and lightweight 1 lb construction ensure easy installation while maintaining the structural integrity required for secure back-feed main configurations and NEC compliance.

Manufacturer Resources

Product Specs

Certifications:
Contact Manufacturer
Number Of Circuits:
6
Product Details:
Retainer bracket
Product Height:
1 in
Product Length Depth:
1 in
Product Size:
3/4 in
Product Weight:
1 lb
Product Width:
1 in
Special Features:
Suitable for CH breakers
Used With:
1-, 2-, or 3-pole type ch circuit breakers
Department:
Electrical
Product Group:
Circuit Protection
Product Type:
Breaker Mounting Accessory
Product Subgroup:
Circuit Breakers
Product Length:
1 in

Eaton CH125RB – Frequently Asked Questions

1) Why do I need a hold down retainer kit for a back-feed main breaker in a CH panel?
When a breaker is used as a back-feed main, it has to be physically secured to the loadcenter so it cannot be pulled off the bus while energized. The Eaton CH125RB retainer bracket is the device that does that on CH loadcenters, and back-feed applications are exactly what it is made for. Without it the back-feed installation is not acceptable per NEC.
2) Will the Eaton CH125RB retainer work with a 2-pole or 3-pole breaker?
It does. The CH125RB hold down retainer kit is listed for use with 1-, 2-, or 3-pole type CH circuit breakers, so a 2-pole back-feed main is covered the same as a single pole.
3) Does this Eaton retainer fit BR series breakers or only CH?
CH only. The CH125RB is built for type CH breakers and CH loadcenters. Eaton's BR line is a different breaker and panel footprint, so if your panel takes BR breakers you need the BR-series hold down, not this kit.
4) How many breaker poles will one CH125RB kit hold down?
One kit covers 6 circuits. That is six 3/4 inch pole positions, so it will handle a 3-pole back-feed main plus additional positions, or several smaller breakers within that span. If you are securing more than six circuits, order more than one kit.
5) Is the Eaton CH125RB a generator interlock or just a breaker retainer?
It is strictly a retainer bracket, not an interlock. It mechanically holds the breaker to the loadcenter. If you are doing a generator or emergency power tie-in with a back-fed breaker, the retainer is one required piece; any mechanical interlock between the main and the back-fed breaker is a separate part.
6) What part number do I order for an Eaton CH back-feed breaker hold down?
Eaton catalog number CH125RB. It is sold as a hold down retainer kit for CH loadcenters, 3/4 inch spacing, 6 circuits.
7) How much room does the CH125RB take up inside the panel?
Very little. Eaton lists the hold down retainer kit at 1 inch height, 1 inch width and 1 inch length/depth, weighing 1 lb, so it mounts over the breaker without eating into wiring gutter space.
