Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 8 In., 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open Collector, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 4 Pin M12 Connector, 10-30 Vdc input, Diffuse Reflective
Manufacturer Resources
Product Specs
- Cable Type:
- Polyvinyl Chloride (PVC)
- Compliances:
- Contact Manufacturer
- Connection:
- 4-pin M12 connector
- Contact Configuration:
- NPN and PNP open collector
- Contact Rating:
- 100 mA PNP, 250 mA NPN at 10-30 Vdc
- Cord Length:
- 8 in
- Enclosure Material:
- Lens: polycarbonate
- Environmental Rating:
- NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
- Input Voltage:
- 10-30 Vdc
- Led Indicator:
- Output status: red
- Maximum Dc Current:
- 100 mA PNP, 250 mA NPN
- Operating Mode:
- Diffuse reflective
- Operating Temperature Max:
- 158 °F
- Operating Temperature Min:
- -40 °F
- Product Height:
- 2.2 in
- Product Length Depth:
- .47 in
- Product Weight:
- .1313 lb
- Product Width:
- .71 in
- Protection:
- Auto reset short circuit
- Sensor Type:
- Diffuse reflective
- Switch Type:
- Photoelectric
