Crouse-Hinds 3/4" FMC Squeeze Type Connector 90� Angle Non-Insulated Zinc Die Cast

Crouse-Hinds 3/4" FMC Squeeze Type Connector 90� Angle Non-Insulated Zinc Die Cast

Professional 90� Angle Flexible Metal Conduit Connection Solution

The Crouse-Hinds 3/4" FMC squeeze type connector delivers reliable 90� angle connections for flexible metal conduit applications in ordinary/non-hazardous locations. Constructed from durable zinc die cast material with non-insulated design, this professional-grade connector provides secure conduit termination with squeeze-type installation for efficient electrical installations.

Professional Features & Benefits

• 3/4" Trade Size: Standard sizing ensures compatibility with common FMC applications and electrical box configurations.
• 90� Angle Design: Right-angle configuration provides space-saving installation options and improved cable management in tight spaces.
• Zinc Die Cast Construction: Robust material delivers long-lasting durability and corrosion resistance for reliable performance.
• Squeeze Type Installation: Tool-free squeeze mechanism enables quick, secure conduit connection without additional hardware.
• Non-Insulated Design: Provides direct electrical continuity for grounding applications where insulation is not required.
• NEC/CEC Compliance: Meets National Electrical Code and Canadian Electrical Code standards for professional installations.
• Compact Dimensions: 4.95" length x 4.84" width x 3.43" height with lightweight 0.15 lb design for versatile mounting.

Technical Specifications

• Area Classification: Ordinary/Non-Hazardous Locations
• Conduit Type: FMC
• Connector Type: 90� angle
• Insulator: Non-insulated
• Product Height: 3.43 in
• Product Length Depth: 4.95 in
• Product Material: Zinc die cast
• Product Style: Squeeze
• Product Weight: .15 lb
• Product Width: 4.84 in
• Standards Type: NEC/CEC
• Trade Size: 3/4"

Installation & Operation

1. Mount the connector in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Commercial Building Electrical Systems
• Industrial Facility Conduit Connections
• Residential Electrical Panel Installations
• Maintenance and Retrofit Projects
• Professional Electrical Contractor Applications
• Code-Compliant Conduit Terminations

Why Choose Crouse-Hinds Quality?

Crouse-Hinds delivers proven reliability through NEC/CEC compliant design and durable zinc die cast construction. The lightweight yet robust connector ensures long-term performance in ordinary locations while meeting professional electrical installation standards.
