Eaton Crouse-Hinds Condulet Cover - Series 470 (Standard or Integral Gasket)

Crouse-Hinds Series 470 Condulet Cover 1-1/4" NEC/CEC Standard with Gasket Options

(No reviews yet) Write a Review

Model: 470F SA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,000.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Crouse-Hinds Series 470 Condulet Cover 1-1/4" NEC/CEC Standard with Gasket Options

Professional Condulet System Component for Reliable Electrical Connections

The Crouse-Hinds Series 470 Condulet Cover delivers professional-grade protection for 1-1/4" condulet installations in ordinary/non-hazardous locations. Engineered to NEC/CEC standards, this cover provides reliable sealing with standard or integral gasket configurations for versatile electrical system applications.

Professional Features & Benefits

  • 1-1/4" Size Compatibility: Precisely engineered for Series 470 condulet bodies ensuring proper fit and reliable connections.
  • NEC/CEC Standards Compliance: Meets National Electrical Code and Canadian Electrical Code requirements for professional installations.
  • Ordinary Location Rating: Designed for non-hazardous environments providing dependable protection in standard electrical applications.
  • Gasket Configuration Options: Available with standard or integral gasket designs for flexible sealing requirements.
  • Series 470 Integration: Engineered specifically for Series 470 condulet systems ensuring seamless compatibility and performance.
  • Professional Construction: Built to Crouse-Hinds quality standards for long-term reliability in electrical installations.

Technical Specifications

  • Area Classification: Ordinary/Non-Hazardous Locations
  • Product Size: 1-1/4"
  • Standards Type: NEC/CEC

Professional Applications

  • Commercial Electrical Systems
  • Industrial Facility Wiring
  • Institutional Building Projects
  • Residential Electrical Installations
  • Maintenance and Retrofit Projects
  • Condulet System Upgrades
  • Professional Electrical Contracting

Why Choose Crouse-Hinds Quality?

Crouse-Hinds delivers proven reliability through NEC/CEC compliant construction and precision engineering. The Series 470 Condulet Cover provides dependable protection for ordinary location applications, backed by professional-grade materials and manufacturing standards that ensure long-term performance in demanding electrical environments.

Manufacturer Resources

Product Specs

Area Classification:
Ordinary/Non-Hazardous Locations
Product Size:
1-1/4"
Standards Type:
NEC/CEC
Department:
Electrical
Product Type:
Conduit Body Cover
Product Subgroup:
Conduit Bodies & Covers
Product Group:
Conduit & Raceway

Crouse-Hinds 470F SA – Frequently Asked Questions

1) What is the difference between the 470F and 470G SA Condulet covers?
Two different sealing and mounting approaches. The 470F is a wedge-nut cover in cast aluminum, and 470F SA is the same wedge-nut style in Feraloy iron alloy. The 470G SA is an integral-gasket cover in sheet steel, so the gasket is built into the cover rather than handled separately. Pick the integral-gasket version when you want the seal captive on the cover; pick wedge-nut when you are matching existing cast-body hardware.
2) Can I use a Series 470 Condulet cover in a hazardous or classified area?
No. The Series 470 cover is rated for ordinary, non-hazardous locations. For Class I or Class II classified areas you need a conduit body and cover listed for that classification, not this one.
3) I'm replacing a damaged cover on an existing 1-1/4 inch Condulet, do I have to replace the whole body?
No. The cover is sold on its own as a conduit body cover, so a cracked or missing 1-1/4 inch Series 470 cover can be swapped without pulling the body or disturbing the conductors. Match the style already on the body, wedge-nut or integral-gasket, so the hardware lines up.
4) Does this Condulet cover meet NEC and Canadian Electrical Code requirements?
The Series 470 cover is built to NEC/CEC standards, which is what inspectors look for on commercial and institutional work in both the US and Canada. It is a code-standard ordinary-location component.
5) Which Series 470 cover material should I use outdoors or in a damp industrial area?
Material is the decision here. 470F is cast aluminum, 470F SA is Feraloy iron alloy, and 470G SA is sheet steel with an integral gasket. For corrosive or wash-down environments crews typically stay with the cast aluminum or Feraloy bodies and match the cover material to the condulet body already installed, since mixing dissimilar metals at the seam is what causes trouble. All three are rated for ordinary locations only.
6) Do I need a separate gasket when I order a Series 470 Condulet cover?
Depends which one you order. The 470G SA is an integral-gasket cover, so the seal comes as part of the cover. The wedge-nut versions, 470F and 470F SA, are supplied as standard covers, so if the installation calls for a gasketed seal you order the gasket alongside them.
