Eaton Custom single-throw fused safety switch, Enhanced visible blades, upper viewing window, 100 A, NEMA 12/3R, Painted galvanized steel, Class R, Three-pole, Three-wire, 600 V, Max Hp: 30, 40/ 60, 75 hp (1/3PH @480, 600 V), #14-#1/0 Cu/Al
Manufacturer Resources
Product Specs
- Amperage Rating:
- 100A
- Certifications:
- UL 98
- Enclosure:
- NEMA 12, NEMA 3R
- Enclosure Material:
- Painted galvanized steel
- Fuse Class Provision:
- Class R
- Fuse Configuration:
- Fusible without neutral
- Hp Rating Max:
- 30, 40/ 60, 75 hp (1/3PH @480, 600 V)
- Number Of Poles:
- Three-pole
- Number Of Wires:
- 3
- Product Category:
- Heavy Duty, Fusible without neutral
- Product Height:
- 9.17 in
- Product Length Depth:
- 24.95 in
- Product Weight:
- 24 lb
- Product Width:
- 11.72 in
- Special Features:
- Enhanced visible blades, upper viewing window
- Type:
- Heavy duty fusible safety switch
- Voltage Rating:
- 600 V
