Eaton E22 Illuminated Momentary Pushbutton, Non-Metallic Heavy-Duty, White

Eaton E22 Illuminated Momentary Pushbutton, Non-Metallic Heavy-Duty, White

The Eaton E22 Illuminated Momentary Pushbutton is a 22.5 mm, non-metallic heavy-duty pushbutton built for demanding industrial control panels. Featuring a 25 mm bezel, plastic construction, and a white actuator, this illuminated, momentary-action device is rated NEMA 3, 3R, 4, 4X, 12, 13 for use across indoor, outdoor, and wash-down environments. The unit ships with no light unit installed, allowing integrators to select the appropriate lamp module for the application.

Key Features

• Mounting Size: 22.5 mm non-metallic heavy-duty pushbutton body for standard panel-mount cutouts.
• Bezel Size: 25 mm bezel diameter fits common industrial control station openings.
• Durable Construction: Plastic actuator material provides corrosion resistance for heavy-duty, non-metallic applications.
• Illuminated Design: Illuminated pushbutton configuration supports visual status indication (light unit not included).
• Momentary Operation: Momentary operating mode returns the actuator to its normal position upon release for pulse-type control signals.
• White Actuator: White actuator color offers clear visual identification on multi-button control panels.
• Multi-Circuit Capability: Supports up to 2 contact blocks (4 circuits) when used with the supplied 3-way adapter.
• Environmental Rating: NEMA 3, 3R, 4, 4X, 12, 13 rated for indoor, outdoor, and wash-down duty locations.

Certifications & Compliance

• CE Marked
• NEMA 3, 3R, 4, 4X, 12, 13 Rated

Technical Specifications

• Series: E22
• Department: Electrical

Typical Applications

• Industrial Control Panels and Operator Stations
• Machine Control and Start/Stop Stations
• Heavy-Duty Manufacturing Equipment
• Outdoor and Wash-Down Rated Enclosures
• Panelboard and Control Cabinet Pushbutton Assemblies

Why Eaton?

Eaton engineers the E22 Series for reliable, code-compliant performance in tough industrial settings, combining non-metallic heavy-duty construction with broad NEMA 3, 3R, 4, 4X, 12, 13 environmental protection and CE-marked compliance. The plastic actuator and illuminated, momentary design give professionals a dependable pushbutton solution for control panel applications where durability and clear operator feedback matter.
