Eaton 30.5 mm Heavy-Duty Illuminated Momentary Pushbutton

Eaton 30.5 mm Heavy-Duty Illuminated Momentary Pushbutton

(No reviews yet) Write a Review

Model: 10250T411LRD06-1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$307.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 30.5 mm Heavy-Duty Illuminated Momentary Pushbutton

The Eaton 30.5 mm Heavy-Duty Illuminated Momentary Pushbutton (10250T series) delivers reliable manual control for industrial and commercial equipment. Featuring an illuminated LED light unit, extended red actuator, and momentary 1 NO-1 NC contact configuration, this heavy-duty pushbutton is rated NEMA 3, 3R, 4, 4X, 12, and 13 for use in demanding indoor and outdoor environments requiring frequent operation and long-term durability. UL Listed and CE Marked, it is engineered for dependable, code-compliant performance on control panels, machinery, and switchgear where operator safety and visibility are critical.

Key Features

  • Trade Size: 30.5 mm heavy-duty pushbutton design for industrial control applications requiring a standard panel cutout.
  • Extended Actuator: Red plastic extended actuator for clear visibility, easy identification, and reliable tactile operation.
  • Momentary Operation: 1 NO-1 NC contact configuration provides momentary switching control for start, stop, and interlock functions.
  • Illuminated LED Light Unit: LED light unit with transformer, rated at 120 Vac light unit voltage and 6 V lamp voltage (min/max), for clear status indication.
  • Chrome Bezel: Durable chrome bezel finish for a professional appearance and long service life in high-traffic control environments.
  • Environmental Rating: NEMA 3, 3R, 4, 4X, 12, and 13 rated for indoor, outdoor, wash-down, and wet-location use.
  • Heavy-Duty Build: 30.5 mm heavy-duty housing designed for demanding industrial-duty cycles and repeated actuation.
  • Warranty: Backed by a 1 year manufacturer warranty for added confidence in long-term installations.

Certifications & Compliance

  • UL Listed
  • CE Marked
  • NEMA 3, 3R, 4, 4X, 12, 13 Rated

Technical Specifications

  • Lamp voltage - min: 6 V
  • Lamp voltage - max: 6 V
  • Actuator color: Red
  • Warranty: 1 year
  • Department: Electrical

Typical Applications

  • Industrial Control Panels and Operator Stations
  • Machine Start/Stop and Interlock Controls
  • HVAC and Process Control Equipment
  • Panelboard and Switchgear Interfaces
  • Wet, Wash-Down, and Outdoor Industrial Environments
  • Manufacturing and Assembly Line Equipment

Why Eaton?

Eaton's 10250T series pushbuttons combine heavy-duty 30.5 mm construction, illuminated LED indication, and multi-environment NEMA 3, 3R, 4, 4X, 12, and 13 ratings to deliver dependable, code-compliant performance for professional electrical and industrial control installations. With UL Listed and CE Marked compliance plus a 1 year warranty, these pushbuttons are built for demanding commercial and industrial environments where safety and reliability are essential.

Manufacturer Resources

Product Specs

Light unit voltage:
120 Vac
Illumination:
Illuminated
Product Width:
1.38 in
Performance Rating:
NEMA 13
Lamp voltage - min:
6 V
Product Length/Depth:
2.87 in
Special features:
10250T series
Application:
Pushbutton
Product Height:
1.38 in
Light unit type:
LED, transformer
Product Type:
Pushbutton
Actuator color:
Red
Actuator material:
Plastic
Warranty:
1 year
Operating mode:
Momentary
Series:
10250T
Bezel:
Chrome
Contact configuration:
1 NO-1 NC
Compliances:
CE Marked
Lamp voltage - max:
6 V
Actuator:
Extended
Certifications:
UL Listed
Department:
Electrical
Product Material:
Plastic
Product Color:
Red
Voltage Rating:
120V
Product Finish:
Chrome
Listing:
UL Listed
Standards:
CE Marked
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton 10250T411LRD06-1 – Frequently Asked Questions

1) Can I wire the Eaton 10250T illuminated pushbutton for both a start command and a stop interlock?
Yes. The contact block is 1 NO-1 NC, so you get one normally open contact for the start or run command and one normally closed contact you can drop into an interlock or stop string off the same operator. It's momentary, so the contacts revert the instant the operator lets go.
2) What voltage does the light on this Eaton illuminated pushbutton run on?
The light unit is fed 120 Vac and steps it down through an integral transformer to a 6 V LED lamp, minimum and maximum both 6 V. That means you feed the station 120 Vac control power, not 6 V, and you don't need a separate step-down transformer in the panel.
3) Is this Eaton pushbutton OK for an outdoor or wash-down enclosure?
It carries NEMA 3, 3R, 4, 4X, 12 and 13 ratings, which covers outdoor rain and sleet, hosedown and wash-down, corrosive locations, and dust or oil-laden indoor industrial air. The seal only holds if the enclosure itself is rated to match and the 30.5 mm cutout is clean and properly gasketed.
4) Is a red extended momentary button the right choice for an E-stop?
No. This is a momentary button, meaning it releases as soon as your hand comes off it. An emergency stop has to be maintained and latch in until it's deliberately reset, so it needs a maintained push-pull or twist-release mushroom operator instead. Use this red extended button for a normal stop, start, or interlock function.
5) Should I use an extended actuator or a flush button on a machine control panel?
This one is an extended red plastic actuator, which stands proud of the bezel so it can be hit fast and found by feel, and it reads clearly across a shop floor. Extended buttons are the choice for frequent-use start or jog functions where speed matters. If you're worried about accidental operation from a passing elbow or a tool, a flush actuator is the safer pick for that position.
6) Is the Eaton 10250T pushbutton UL Listed for a control panel build?
UL Listed and CE Marked. That is what a panel shop or an inspector will be looking for on an operator device going into an industrial control panel or switchgear interface.
7) What's the Eaton part number and how do I match the rest of the stations on my panel?
The catalog number is 10250T411LRD06-1, an Eaton 10250T series heavy-duty illuminated momentary operator with a chrome bezel and red extended actuator. If you're standardizing a panel, the chrome bezel and 30.5 mm heavy-duty body are what to match across the other stations so the faces line up and the cutouts are common.
8) Is the button body metal or plastic?
The actuator and body are plastic, with a chrome bezel ring at the panel face. Plastic actuators are non-conductive and hold up in the corrosive and wash-down settings the NEMA 4X rating covers; if you need a metal actuator for abuse resistance, that's a different operator.
