Eaton 10250T Series Heavy-Duty 30.5 mm Momentary Pushbutton, Non-Illuminated

Eaton 10250T Series Heavy-Duty 30.5 mm Momentary Pushbutton, Non-Illuminated

(No reviews yet) Write a Review

Model: 10250T101E

In Stock (leaves warehouse same day if ordered before 3pm ET)

$53.90
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 10250T Series Heavy-Duty 30.5 mm Momentary Pushbutton, Non-Illuminated

The Eaton 10250T Series is a heavy-duty 30.5 mm non-illuminated pushbutton operator built for demanding industrial control panels and machine interfaces. Featuring a momentary operating mode, a half-shrouded actuator, and a 2 NO contact configuration, this pushbutton is rated NEMA 4X for reliable performance in washdown and corrosive environments. UL Listed and CE Marked construction ensures dependable, code-compliant operation on the panel.

Key Features

  • Type: 30.5 mm, Heavy-Duty pushbutton for industrial control applications.
  • Durable Construction: Plastic actuator with a Chrome bezel for long-lasting panel-mount performance.
  • Operating Mode: Momentary action with 2 NO contact configuration for precise circuit control.
  • Actuator Style: Half-shrouded actuator in Black helps prevent accidental activation.
  • Illumination: Non-illuminated design for standard indicator-free control stations.
  • Environmental Rating: NEMA 3, 3R, 4, 4X, 12, 13 rated for indoor and outdoor, wet, and corrosive-duty locations.
  • Mounting: Horizontal mounting method for standard control enclosure layouts.

Certifications & Compliance

  • UL Listed
  • CE Marked
  • NEMA 3, 3R, 4, 4X, 12, 13 Rated

Technical Specifications

  • Warranty: 1 year
  • Department: Electrical
  • Product Type: Electrical Component

Typical Applications

  • Industrial Control Panels
  • Machine Operator Interfaces
  • Washdown and Corrosive-Duty Environments
  • Outdoor and Wet-Location Control Stations
  • Panelboard and Switchgear Control Circuits

Why Eaton?

Eaton's 10250T Series pushbuttons combine heavy-duty plastic actuator construction with a Chrome bezel and broad NEMA environmental ratings to deliver dependable performance across demanding industrial settings. UL Listed and CE Marked, these pushbuttons are built for code-compliant, reliable operation in professional electrical and automation installations.

Manufacturer Resources

Spec Sheet

Product Specs

Warranty:
1 year
Series:
10250T
Department:
Electrical
Actuator color:
Black
Compliances:
CE Marked
Product Type:
Pushbutton Switch
Product Material:
Plastic
Product Color:
Black
Product Finish:
Chrome
Listing:
UL Listed
Standards:
NEMA 4X
Product Group:
Wiring Devices
Product Subgroup:
Push Buttons

Eaton 10250T101E – Frequently Asked Questions

1) Will an Eaton 10250T pushbutton hold up in a washdown area?
Yes. The 10250T heavy-duty 30.5 mm pushbutton carries NEMA 3, 3R, 4, 4X, 12 and 13 ratings, so it covers indoor and outdoor wet locations, hosedown, dust and oil, and corrosive duty. The 4X rating is the one that matters for food plants, dairies and other daily washdown areas.
2) What size panel hole does the Eaton 10250T pushbutton need?
It's a 30.5 mm operator, which is the standard heavy-duty panel opening used across industrial control stations. If your enclosure is already drilled for 30.5 mm buttons, this drops straight in; a 22 mm compact-duty panel cutout is the wrong size for it.
3) Is the Eaton 10250T button momentary or maintained?
Momentary. The button makes the circuit only while it's held and springs back when released, which is what you want for jog, start, and machine-interface commands. It ships with a 2 NO contact arrangement, so both contacts close on press.
4) Can I use this pushbutton as an emergency stop?
No. The 10250T covered here is a black half-shrouded momentary operator with 2 NO contacts. An E-stop must be a red maintained mushroom head with normally closed contacts, so specify a dedicated 10250T E-stop operator for that duty.
5) Does a half-shrouded actuator prevent accidental operation?
Partly, and that's the point of it. The 10250T's half-shrouded black actuator sits recessed behind a raised guard on part of its circumference, so a brush past the panel or a dropped tool is far less likely to trip it than with a full extended head. It still leaves the button easy to hit deliberately. For a command that must never be bumped, use a fully shrouded or key-operated operator instead.
6) Is the Eaton 10250T lighted?
No, it's a non-illuminated operator. There is no lamp or LED in the head, so you don't need to run a separate lamp supply to it. If the operator has to double as a status indicator, you need an illuminated 10250T operator rather than this one.
7) Is the Eaton 10250T pushbutton UL Listed and CE marked for a plant spec?
Both. The 10250T pushbutton is UL Listed and CE Marked, which covers the usual approval line on a North American panel build and on machinery headed to Europe.
8) Which Eaton 10250T part number do I order?
Three configurations are offered: 10250T101E, 10250T2411-1, and 10250T511-2. Order by the full part number rather than by the series alone, since the 10250T family covers many different operator and contact builds.
9) What is the Eaton 10250T pushbutton made of, and will the bezel corrode?
The actuator is plastic and the bezel is chrome finished. That combination is what carries the NEMA 4X corrosion rating, so it stands up to washdown chemicals and damp outdoor control stations better than a plain painted metal operator.
