The Eaton E30 Square Multifunction Indicating Light Pushbutton is a 30.5 mm metallic operator interface component engineered for panel-mounted control and status-indication applications. This single-unit, square multifunction indicating light actuator combines pushbutton actuation with an integral light unit rated 120 Vac, using LED lamp number 6PSB, and carries a NEMA 12 rating for use in dusty and oil-splash industrial environments. Backed by CSA certification and Eaton's 1-year warranty, this E30 series component is built for reliable, long-term machine and panel-control duty in demanding facilities.
Key Features
- Compact 30.5 mm Footprint: Metallic square multifunction actuator sized for standard E30 series panel cutouts, simplifying retrofit and new-build panel layouts.
- Durable Metallic Construction: Metallic housing provides a rugged, professional-grade actuator suited to demanding industrial panels and repeated operator actuation.
- Single-Unit Square Multifunction Actuator: Combines indicating light and pushbutton actuation in one square multifunction component for streamlined operator interface design.
- 120 Vac Light Unit Voltage: Integral light unit operates at 120 Vac for standard panel indication circuits without additional transformers.
- LED Lamp Number 6PSB: Uses 6PSB lamp designation with an incandescent, transformer-type light unit for reliable illumination and status feedback.
- NEMA 12 Rated: Rated for dust-tight and oil/coolant-splash environments common in industrial control panels and manufacturing floors.
- Compact Dimensions: Measures 2.4 in wide x 3.3 in deep x 2.1 in high for predictable panel layout and enclosure spacing planning.
Certifications & Compliance
- CSA Certified
- NEMA 12 Rated for Dust and Oil-Splash Environments
Technical Specifications
- Warranty: 1 year
- Series: E30
- Product Type: Pushbutton
Typical Applications
- Industrial Control Panels and Enclosures
- Machine Operator Interface Stations
- Panel-Mounted Status and Fault Indication
- Manufacturing and Process Control Equipment
- Oil, Dust, and Coolant-Exposed Industrial Environments
- OEM Machine Builder Control Stations
Why Eaton?
Eaton's E30 series pushbutton and indicating light components are built with metallic construction and CSA certification to deliver dependable, code-compliant performance in demanding industrial control environments. The NEMA 12 rating and 1-year warranty reflect Eaton's commitment to durable, professional-grade operator interface hardware for panel builders, OEMs, and maintenance professionals who need consistent, long-lasting performance.
Manufacturer Resources
Product Specs
- Light Unit Voltage:
- 120 Vac
- LED lamp number:
- 6PSB
- Product Width:
- 2.4 in
- Performance Rating:
- NEMA 12
- Warranty:
- 1 year
- Series:
- E30
- Product Length/Depth:
- 3.3 in
- Product Height:
- 2.1 in
- Light unit type:
- Incandescent, transformer
- Product Type:
- Pushbutton
- Actuator:
- Single unit, square multifunction
- Certifications:
- CSA Certified
- Department:
- Electrical
- Product Material:
- Metallic
- Voltage Rating:
- 120V
- Listing:
- CSA Certified
- Standards:
- NEMA 12
- Product Group:
- Motor Control & Automation
- Product Subgroup:
- Push Buttons & Pilot Devices
- Product Length:
- 3.3 in
- Product Weight:
- 0.45 lb
Eaton E30BA – Frequently Asked Questions
1) Can I run the Eaton E30BA indicating light directly off 120 Vac control power?
Yes. The light unit on the E30BA is rated 120 Vac, so it wires straight into a standard 120 V control circuit with no separate step-down transformer in the panel. The light unit itself is the transformer type, and the lamp designation is 6PSB.
2) Is this Eaton pushbutton suitable for a machine shop panel with coolant mist and dust?
It carries a NEMA 12 rating, which covers dust-tight service and protection from dripping or splashing oil and coolant, the usual condition on a machining or process floor. It is not rated for washdown or outdoor hosedown duty. It is also CSA certified.
3) What is the difference between a plain pushbutton and the E30BA square multifunction indicating light unit?
A plain pushbutton only actuates a contact block. The E30BA is a single-unit, square multifunction actuator, meaning the illuminated indicator and the pushbutton actuation live in one operator and one panel hole. Use it where the operator needs to press a command and read status from the same position; use a separate button and pilot light when the indication reports on a different circuit than the button commands.
4) How much depth do I need behind the panel door for the Eaton E30BA?
Plan on 3.3 in of depth for the unit, with a 2.4 in by 2.1 in footprint around the hole. Check that against door-mounted components and any wireway behind the operator before you lay out the station.
5) What part number do I quote to order this Eaton E30 illuminated pushbutton?
Order by Eaton manufacturer part number E30BA. That is the E30 series square multifunction indicating light operator, metallic, with the 120 Vac light unit.
6) Does the Eaton E30BA meet Canadian approval requirements for an industrial control panel?
It is CSA certified, so it can be used where the panel build calls for CSA-recognized operator components. The environmental rating on the operator is NEMA 12.
7) Is the Eaton E30BA actuator metal or plastic?
Metallic. The operator housing is metal rather than moulded plastic, which is what panel builders and OEMs usually spec for stations that see constant operator contact on a production line.
