Eaton E30 Metallic Indicating Light Pushbutton, 30.5mm Square Multifunction
The Eaton E30 Metallic Indicating Light Pushbutton is a 30.5 mm, metallic operator built as a single-unit, square multifunction actuator for industrial control panels and machine interfaces. Rated NEMA 12 and UL Listed, this E30 series light unit accepts an LED lamp (24PSB) or an incandescent, full-voltage lamp, with a light unit voltage of 18 Vac/dc at 60 Hz or 24 Vac/dc at 50 Hz. Compact dimensions of 2.1 in width, 2.4 in depth, and 3.3 in height make it a reliable indicating-light solution for panel builders and maintenance teams standardizing on the Eaton E30 platform.
Key Features
- Actuator Type: Single unit, square multifunction, 30.5 mm actuator for standard E30 series panel cutouts.
- Durable Construction: Metallic housing designed for demanding industrial and commercial control environments.
- Light Unit Type: Incandescent, full voltage, with the light unit also accepting an LED lamp (number 24PSB) for flexible retrofit options.
- Light Unit Voltage: 18 Vac/dc at 60 Hz, 24 Vac/dc at 50 Hz, matching common low-voltage control circuits.
- Environmental Rating: NEMA 12 rated for protection against dust, dirt, and oil in industrial settings.
- Compact Dimensions: 2.1 in width, 2.4 in depth, and 3.3 in height for space-conscious panel layouts.
- Series: Part of the Eaton E30 pushbutton and indicating light series for consistent panel design.
- Warranty: Backed by Eaton's 1 year warranty.
Certifications & Compliance
- UL Listed
- NEMA 12 Rated
Technical Specifications
- Warranty: 1 year
- Series: E30
- Product Type: Pushbutton
- Department: Electrical
Typical Applications
- Industrial Control Panels and Operator Interfaces
- Machine Start/Stop and Status Indication
- Manufacturing and Process Automation Equipment
- Panelboard and Enclosure Retrofits
- Commercial and Industrial Electrical Installations
Why Eaton?
Eaton's E30 series pushbuttons and indicating lights combine metallic construction with NEMA 12 and UL Listed ratings, giving panel builders a dependable, code-compliant operator interface. With flexible LED and incandescent lamp compatibility plus a 1 year warranty, the E30 series is engineered for consistent, long-term performance in professional electrical and industrial control applications.
Manufacturer Resources
Product Specs
- LED lamp number:
- 24PSB
- Light unit voltage:
- 18 Vac/dc at 60 Hz, 24 Vac/dc at 50 Hz
- Product Width:
- 2.1 in
- Catalog Notes:
- Light Unit will also accept LED lamp
- Performance Rating:
- NEMA 12
- Warranty:
- 1 year
- Series:
- E30
- Product Length/Depth:
- 2.4 in
- Product Height:
- 3.3 in
- Light unit type:
- Incandescent, full voltage
- Product Type:
- Pushbutton
- Actuator:
- Single unit, square multifunction
- Certifications:
- UL Listed
- Department:
- Electrical
- Product Material:
- Metallic
- Configuration:
- Single Unit, Square Multifunction
- Listing:
- UL Listed
- Standards:
- NEMA 12
- Product Group:
- Push Buttons
