Product Specs
- Accuracy:
- < 3%
- Cable Type:
- PVC
- Certifications:
- UL Listed
- Compliances:
- CE Marked
- Connection:
- 13.1 Ft. ( 4m ) Cable
- Contact Configuration:
- Normally Open PNP Open Collector
- Contact Rating:
- 500 mA at 6-30Vdc
- Cord Length:
- 157.2 FT
- Diameter:
- .71 IN
- Enclosure Material:
- Stainless Steel
- Environmental Rating:
- IP67, IP69K, UL Type 1, NEMA 6P, 4X
- Input Voltage:
- 6–48 Vdc
- Led Indicators:
- Red output status
- Maximum Dc Current:
- 500 mA
- Operating Mode:
- Un-shielded
- Operating Temperature:
- -13° to 158°F (-25° to 70°C)
- Product Height:
- 2.6 IN
- Product Length Depth:
- .71 IN
- Product Weight:
- .375 LB
- Product Width:
- .71 IN
- Protection:
- Short circuit protected
- Sensor Type:
- Inductive Proximity
- Series:
- E57
- Switch Type:
- Inductive Proximity
- Product Group:
- Electrical
